Licross® 11
45 years of experience – trunking Made in Germany perfected in our Licross® trunking system. The one-for-all concept offers a variety of luminaire inserts and functional expansion options for maximum flexibility and future compatibility. With its unique 14 cores, the rail system becomes the backbone of the building infrastructure and is ready for a wide range of applications - today and tomorrow. The luminaire inserts offer outstanding lighting technology with up to 209lm/W or low operating costs as well as SITECO-typical optics technology for the best viewing conditions. Various extensions from sensor to cameras and data transmission open up a broad horizon of applications far from lighting, which create additional added value.
Our performance solution: Licross® 11 is our innovative trunking system with maximum efficiency (up to 209lm/W), service life (up to 100,000h) and flexibility
Opal luminaire insert IP40/IP54
Intro to ProductfamilyData
Article luminaire insert
Protection rating IP40
Net luminous flux 2750lm to 26350lm
Colour temperature 4000K
Lighting effect direct symmetric diffuse distribution, with ceiling illumination
Specials
Configuration & Datasheets
- please order Licross® trunking rail or trunking rail accessories separately
- with ceiling surface mounting: reducing of maximum allowable ambient temperature of 5°C
- luminaire inserts (AC/DC) suiatble for group and central battery systems according to EN60598-2-22 (even at AC operation)
- With AC/DC luminaire inserts, the power supply can be changed to either mains supply operation L1/L2/L3, emergency supply 1 L´/N´ or emergency supply 2 L´´/N´´ by moving the contacts on the connection block
- with luminaire inserts (AC/DC), luminaires use reduced luminous flux with DC operation (see photometric report for DC operation)
Results
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 4480 | 25W | 181lm/W | ON/OFF | -35..+45°C | IP40 | 1500 | 1.4 | 238.30 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6300 | 35W | 180lm/W | ON/OFF | -35..+45°C | IP40 | 1500 | 1.4 | 238.30 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8490 | 49W | 175lm/W | ON/OFF | -35..+35°C | IP40 | 1500 | 1.4 | 238.30 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8820 | 49 | 55 | 160lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP40 | 1500 | 1.4 | 258.50 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 12370 | 67 | 75 | 166lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP40 | 1500 | 1.4 | 319.10 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 2750 | 16W | 175lm/W | DALI 2 | -25..+50°C | IP40 | 1500 | 1.4 | 270.60 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 4500 | 25W | 179lm/W | DALI 2 | -25..+45°C | IP40 | 1500 | 1.4 | 270.60 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6320 | 35W | 180lm/W | DALI 2 | -25..+40°C | IP40 | 1500 | 1.4 | 270.60 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6320 | 34W | 189lm/W | DALI 2 | -25..+45°C | IP40 | 1500 | 1.4 | 331.20 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9710 | 57W | 171lm/W | DALI 2 | -25..+35°C | IP40 | 1500 | 1.4 | 270.60 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13620 | 77W | 177lm/W | DALI 2 | -25..+30°C | IP40 | 1500 | 1.4 | 331.20 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 4120 | 22W | 185lm/W | DALI 2 | -25..+45°C | IP40 | 2250 | 2.2 | 381.70 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9500 | 53W | 181lm/W | DALI 2 | -25..+40°C | IP40 | 2250 | 2.2 | 381.70 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14560 | 84W | 173lm/W | DALI 2 | -25..+35°C | IP40 | 2250 | 2.2 | 381.70 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 26350 | 151W | 175lm/W | DALI 2 | -40..+35°C | IP40 | 2250 | 2.2 | 429.20 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 4320 | 34W | 184lm/W | ON/OFF Multilumen | -35..+50°C | IP40 | 1500 | 1.4 | 258.50 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9750 | 55W | 177lm/W | ON/OFF Multilumen | -35..+40°C | IP40 | 1500 | 1.4 | 258.50 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13690 | 75W | 184lm/W | ON/OFF Multilumen | -35..+35°C | IP40 | 1500 | 1.4 | 319.10 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 16760 | 89W | 188lm/W | ON/OFF Multilumen | -35..+35°C | IP40 | 2250 | 2.2 | 411.00 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1D7N44XGGTIN (EAN): 4058352055151
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 4480 |
Connected load | 25W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 181lm/W |
Control | ON/OFF |
ta | -35..+45°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 238.30 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1D7N46XGGTIN (EAN): 4058352055175
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 6300 |
Connected load | 35W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 180lm/W |
Control | ON/OFF |
ta | -35..+45°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 238.30 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1D7N48XGGTIN (EAN): 4058352055205
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8490 |
Connected load | 49W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 175lm/W |
Control | ON/OFF |
ta | -35..+35°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 238.30 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DCN485GGTIN (EAN): 4058352056639
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8820 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 55 |
Luminous efficacy | 160lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 258.50 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DCN4CXMGTIN (EAN): 4069025021656
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 12370 |
Connected load | |
Pnom (W) begin service life | 67 |
Pnom (W) end service life | 75 |
Luminous efficacy | 166lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+35°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 319.10 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DDN425GGTIN (EAN): 4058352049754
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 2750 |
Connected load | 16W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 175lm/W |
Control | DALI 2 |
ta | -25..+50°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 270.60 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DDN445GGTIN (EAN): 4058352049778
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 4500 |
Connected load | 25W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 179lm/W |
Control | DALI 2 |
ta | -25..+45°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 270.60 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DDN46XGGTIN (EAN): 4058352049792
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 6320 |
Connected load | 35W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 180lm/W |
Control | DALI 2 |
ta | -25..+40°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 270.60 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DDN46XMGTIN (EAN): 4058352049815
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 6320 |
Connected load | 34W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 189lm/W |
Control | DALI 2 |
ta | -25..+45°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 331.20 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DDN495GGTIN (EAN): 4058352049839
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9710 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 171lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 270.60 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DDN4D5MGTIN (EAN): 4058352049860
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13620 |
Connected load | 77W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 177lm/W |
Control | DALI 2 |
ta | -25..+30°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 331.20 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DDV44XGGTIN (EAN): 4058352054291
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 4120 |
Connected load | 22W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 185lm/W |
Control | DALI 2 |
ta | -25..+45°C |
Protection rating | IP40 |
L (mm) | 2250 |
Wt. (kg) | 2.2 |
Price (EUR) | 381.70 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DDV495GGTIN (EAN): 4058352054314
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9500 |
Connected load | 53W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 181lm/W |
Control | DALI 2 |
ta | -25..+40°C |
Protection rating | IP40 |
L (mm) | 2250 |
Wt. (kg) | 2.2 |
Price (EUR) | 381.70 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DDV4E5GGTIN (EAN): 4058352054338
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14560 |
Connected load | 84W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 173lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP40 |
L (mm) | 2250 |
Wt. (kg) | 2.2 |
Price (EUR) | 381.70 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DDV4M1MGTIN (EAN): 4058352055212
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 26350 |
Connected load | 151W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 175lm/W |
Control | DALI 2 |
ta | -40..+35°C |
Protection rating | IP40 |
L (mm) | 2250 |
Wt. (kg) | 2.2 |
Price (EUR) | 429.20 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DMN46XGGTIN (EAN): 4058352051931
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 4320 |
Connected load | 34W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 184lm/W |
Control | ON/OFF Multilumen |
ta | -35..+50°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 258.50 |
Licross® 11 recessed opal MO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DMN495GGTIN (EAN): 4058352055236
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9750 |
Connected load | 55W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 177lm/W |
Control | ON/OFF Multilumen |
ta | -35..+40°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 258.50 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DMN4D5MGTIN (EAN): 4058352056653
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13690 |
Connected load | 75W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 184lm/W |
Control | ON/OFF Multilumen |
ta | -35..+35°C |
Protection rating | IP40 |
L (mm) | 1500 |
Wt. (kg) | 1.4 |
Price (EUR) | 319.10 |
Licross® 11 recessed opal HO, with spring catch, symmetric diffuse distribution, IP40, AC
Order No.: 51TL1DMV4G5MGTIN (EAN): 4058352056677
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 16760 |
Connected load | 89W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 188lm/W |
Control | ON/OFF Multilumen |
ta | -35..+35°C |
Protection rating | IP40 |
L (mm) | 2250 |
Wt. (kg) | 2.2 |
Price (EUR) | 411.00 |
