Monsun® 21 Eco, DALI, PC
Close
Article damp-proof luminaire
Product name Monsun® 21 Eco
Lamp LED
Rated luminous flux 4900lm
Luminous efficacy 132lm/W
Colour temperature 4000K
Colour rendering CRI > 80
Rated input power 36W
Service life 50000h (L80/B50) at AT = 25°C
Protection rating IP66
Impact resistance IK08
Weight 1.8kg
Monsun® 21 Eco, damp-proof luminaire, primary optical cover: diffuser, of PC, UV-stabilised, frosted, light emission: direct distribution, primary light characteristic: symmetric, installation type: suspended mounting, surface-mounted, LED, rated luminous flux: 4.900lm, luminous efficacy: 132lm/W, light colour: 840, colour temperature: 4000K, control gear: DALI, with terminal, 5-pole, max. 2.5mm², mains connection: 220..240V, AC, 50/60Hz, rated input power: 36W, housing, of glass-fibre reinforced polyester, light grey (RAL 7035), length: 1.277mm, width: 90mm, height: 95mm, clip for enclosure, of spring steel V2A, protection rating (complete): IP66, insulation class (complete): insulation class I (protective earthing), certification: CE, UKCA, protection symbol: D, impact resistance: IK08, permissible operating ambient temperature: -20..+35°C, corresponds to IFS (International Featured Standards) requirements for safety and quality in the food industry, contact your sales advisor before using the luminaires in applications with unclear chemical exposure, large temperature fluctuations or condensation-forming humidity, packaging unit: 1 piece
Downloads
Technical product information
Data for application programs
Product details
Photometric report / planning data
Monsun® 21 Eco
LED, ECG DALI, diffuser, suspended mounting, surface-mounted, L= 1277mm
Lamps: 1x LED
Ordercode: 51FJ20DL45A
