Article base module
Product name Licross® Interface
Protection rating IP20
Weight 0.5kg

Licross®, Interface S, slave,local controlcentral controlinstallation location: to the Licross® trunking rail, of sheet steel, protection rating (complete): IP20, insulation class (complete): insulation class I (protective earthing), certification: CE, VDE, 1 x DALI-2, packaging unit: 1 piece

Product details


Key data

System family Siteco Connect 11, SITECO Connect 22
Product type base module
Product name Licross® Interface
Order No. 56TL1FCSA


Lamps

Supplement halogen-free wiring


Operating device

Control DALI 2


Certificates, Standards

Protection rating IP20
Insulation class insulation class I (protective earthing)
Temperature range (operation) -20..+50°C
Certification, designation CE, VDE


Material, Colour

trunking rail adapter set sheet steel, coil coated, white
Colour specification white


Mounting

Supplement only suitable for indoor use


Electrical connection

Connection plug, 5-pole, with phase selection


Dimensions, Weight

Length 500mm
Width 96mm
Height 97mm
Weight 0.5kg


Outputs

DALI-2
Feature DALI, slave function, DALI current max. 6mA

System family
Siteco Connect 11, SITECO Connect 22

Product type
base module

Product name
Licross® Interface

Order No.
56TL1FCSA

Supplement
halogen-free wiring

Control
DALI 2

Protection rating
IP20

Insulation class
insulation class I (protective earthing)

Temperature range (operation)
-20..+50°C

Certification, designation
CE, VDE

trunking rail adapter set
sheet steel, coil coated, white

Colour specification
white

Supplement
only suitable for indoor use

Connection
plug, 5-pole, with phase selection

Length
500mm

Width
96mm

Height
97mm

Weight
0.5kg

DALI-2

Feature
DALI, slave function, DALI current max. 6mA
