City-Light iQ
Every city is different - but each wants to be attractive and welcoming. SITECO town and park luminaires can make a decisive contribution to giving your town that certain flair. Our luminaires are effective day and night, set aesthetic accents and can be perfectly combined with designer masts. But the best thing is their inner workings: All luminaires contain the latest generation of Module 540, which is also perfectly suited as a refurbishment solution for old systems. Because this module has it all: for example iQ, our new, patented luminaire electronics, which equips your light with a multitude of new functions and future-oriented control options. In this way, SITECO not only transports cherished design classics into the LED age, but directly into the future.
Flexible and modular into the future of city lighting
City-Light Elegance with Module 540 iQ (pre-assembled, incl. connection cable)
Intro product family
Key data
Article mast luminaire
Lighting effect direct asymmetric wide distribution; direct highly asymmetric extremely wide distribution; direct symmetric wide distribution
Light distribution ST1.2a; P1.0a; PL1.2s
Net luminous flux 1440lm to 2840lm
Colour temperature 3000K
Control iQ Street-Remote; iQ-Street Remote, D4i with power reduction
Special features
Easy installation and low maintenance due to future-oriented modular design for exchangeable LED module and gear tray
Luminous module body as a visual guidance element with decorative day/night time effect
Low energy consumption due to high luminous efficacy and avoidance of overplanning thanks to the patented CLO 2.0 luminous flux tracking
High visual comfort due to uniform illumination and very good glare control – can be further improved with spreader element
Configuration & data sheets
- further light colours and connection cable variants on request
- please order mast reducer separately if required
- luminaire incl. pre-installed connection cable, l = 5.0m
- Setting the luminaire with Street-Remote: with the SITECO iQ app on the SITECO iQ handheld (5EA6HBR02) or your own smart phone
- SITECO offers the SITECO Connect Group Control (230V or 12/24V) product to use the Smart Wire function '10 levels'. A communication module is also available with which remote access is possible and radio clock functionality is provided.
- Smart Interface luminaires currently without iQ functionality
Results
City-Light Elegance iQ, direct highly asymmetric extremely wide distribution, iQ Street-Remote, for post-top
Order No.: 5XA5265FF14H000022 GTIN (EAN): 4058352636053
| Colour temperature | Colour rendering | Luminous flux | Pnom (W) begin service life | Pnom (W) end service life | Pred (W) at 50% lumin. flux | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1440lm | 11 | 11 | 5 | 137lm/W | iQ Street-Remote | 9.0 |
City-Light Elegance iQ, direct asymmetric wide distribution, iQ Street-Remote, for post-top
Order No.: 5XA5265EF14H000022 GTIN (EAN): 4058352635216
| Colour temperature | Colour rendering | Luminous flux | Pnom (W) begin service life | Pnom (W) end service life | Pred (W) at 50% lumin. flux | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1470lm | 11 | 11 | 5 | 140lm/W | iQ Street-Remote | 9.0 |
City-Light Elegance iQ, direct symmetric wide distribution, iQ Street-Remote, for post-top
Order No.: 5XA5265JF14H000022 GTIN (EAN): 4058352636107
| Colour temperature | Colour rendering | Luminous flux | Pnom (W) begin service life | Pnom (W) end service life | Pred (W) at 50% lumin. flux | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 2840lm | 19 | 21 | 10 | 147lm/W | iQ Street-Remote | 9.0 |
City-Light Elegance iQ, direct asymmetric wide distribution, iQ-Street Remote, D4i with power reduction, for post-top
Order No.: 5XA5265EU14H000022 GTIN (EAN): 4058352024003
| Colour temperature | Colour rendering | Luminous flux | Pnom (W) begin service life | Pnom (W) end service life | Pred (W) at 50% lumin. flux | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1460lm | 11 | 11 | 6 | 136lm/W | iQ-Street Remote, D4i with power reduction | 9.0 |
City-Light Elegance iQ, direct asymmetric wide distribution, iQ-Street Remote, D4i with power reduction, for post-top
Order No.: 5XA5265EV14H000022 GTIN (EAN): 4058352024027
| Colour temperature | Colour rendering | Luminous flux | Pnom (W) begin service life | Pnom (W) end service life | Pred (W) at 50% lumin. flux | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1460lm | 11 | 11 | 6 | 136lm/W | iQ-Street Remote, D4i with power reduction | 9.0 |
City-Light Elegance iQ, direct asymmetric wide distribution, iQ-Street Remote, D4i with power reduction, for post-top
Order No.: 5XA5265EY14H000022 GTIN (EAN): 4058352024041
| Colour temperature | Colour rendering | Luminous flux | Pnom (W) begin service life | Pnom (W) end service life | Pred (W) at 50% lumin. flux | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1460lm | 11 | 11 | 6 | 136lm/W | iQ-Street Remote, D4i with power reduction | 9.0 |
City-Light Elegance iQ, direct highly asymmetric extremely wide distribution, iQ Street-Remote, for post-top
Order No.: 5XA5265FF14H000022GTIN (EAN): 4058352636053
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1440lm |
| Pnom (W) begin service life | 11 |
| Pnom (W) end service life | 11 |
| Pred (W) at 50% lumin. flux | 5 |
| Luminous efficacy | 137lm/W |
| Control | iQ Street-Remote |
| Wt. (kg) | 9.0 |
City-Light Elegance iQ, direct asymmetric wide distribution, iQ Street-Remote, for post-top
Order No.: 5XA5265EF14H000022GTIN (EAN): 4058352635216
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1470lm |
| Pnom (W) begin service life | 11 |
| Pnom (W) end service life | 11 |
| Pred (W) at 50% lumin. flux | 5 |
| Luminous efficacy | 140lm/W |
| Control | iQ Street-Remote |
| Wt. (kg) | 9.0 |
City-Light Elegance iQ, direct symmetric wide distribution, iQ Street-Remote, for post-top
Order No.: 5XA5265JF14H000022GTIN (EAN): 4058352636107
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 2840lm |
| Pnom (W) begin service life | 19 |
| Pnom (W) end service life | 21 |
| Pred (W) at 50% lumin. flux | 10 |
| Luminous efficacy | 147lm/W |
| Control | iQ Street-Remote |
| Wt. (kg) | 9.0 |
City-Light Elegance iQ, direct asymmetric wide distribution, iQ-Street Remote, D4i with power reduction, for post-top
Order No.: 5XA5265EU14H000022GTIN (EAN): 4058352024003
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1460lm |
| Pnom (W) begin service life | 11 |
| Pnom (W) end service life | 11 |
| Pred (W) at 50% lumin. flux | 6 |
| Luminous efficacy | 136lm/W |
| Control | iQ-Street Remote, D4i with power reduction |
| Wt. (kg) | 9.0 |
City-Light Elegance iQ, direct asymmetric wide distribution, iQ-Street Remote, D4i with power reduction, for post-top
Order No.: 5XA5265EV14H000022GTIN (EAN): 4058352024027
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1460lm |
| Pnom (W) begin service life | 11 |
| Pnom (W) end service life | 11 |
| Pred (W) at 50% lumin. flux | 6 |
| Luminous efficacy | 136lm/W |
| Control | iQ-Street Remote, D4i with power reduction |
| Wt. (kg) | 9.0 |
City-Light Elegance iQ, direct asymmetric wide distribution, iQ-Street Remote, D4i with power reduction, for post-top
Order No.: 5XA5265EY14H000022GTIN (EAN): 4058352024041
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1460lm |
| Pnom (W) begin service life | 11 |
| Pnom (W) end service life | 11 |
| Pred (W) at 50% lumin. flux | 6 |
| Luminous efficacy | 136lm/W |
| Control | iQ-Street Remote, D4i with power reduction |
| Wt. (kg) | 9.0 |
Optional accessories
| Order No.: 5XA54000XSGTIN (EAN): 4050737730073 | Show all details |
| Order No.: 5XA54000XSAGTIN (EAN): 4058352161326 | Show all details |
| Order No.: 5XA54000XBSGTIN (EAN): 4050737971445 | Show all details |
| Order No.: 5XA54000XBLGTIN (EAN): 4050737971421 | Show all details |
| Order No.: 5XA54000XBXLGTIN (EAN): 4058352415573 | Show all details |
| Order No.: 5XA54001XSGTIN (EAN): 4050737754895 | Show all details |
| Order No.: 5LA52201XRGTIN (EAN): 4039806232175 | Show all details |
| Order No.: 5NY70062DKGTIN (EAN): 4058352552247 | Show all details |
| Order No.: 5NY52660XG18GTIN (EAN): 4039806215932 | Show all details |
| Order No.: 5NY52650XG18GTIN (EAN): 4039806216694 | Show all details |
| Order No.: 5NY52650XG28GTIN (EAN): 4039806215833 | Show all details |
| Order No.: 5NY52660XN18GTIN (EAN): 4039806216014 | Show all details |
| Order No.: 5NY52650XN18GTIN (EAN): 4039806215857 | Show all details |
| Order No.: 5NY52650XN28GTIN (EAN): 4039806215895 | Show all details |
| Order No.: 5NA54900XGGTIN (EAN): 4039806059666 | Show all details |
| Order No.: 5NA54903XGGTIN (EAN): 4039806210357 | Show all details |
