Silica 21 Prismatic Linear
learn more
Product selection
Silica 21 Floor Linear Prismatic
Key data
Article floorstanding luminaire
Lighting effect indirect/direct symmetric wide distribution
Net luminous flux 13280lm
Colour temperature 3000K; 4000K
Control DALI 2
Supplement with ambient light and presence detector
Special features
Very homogeneous and standard-compliant illumination of two workplaces in accordance with DIN EN 12464-1
Pleasant room atmosphere due to very wide ceiling illumination
Ideal basis for a smart office thanks to the flexible extension of the luminaire with intelligent sensors, e.g. B. for spatial data acquisition with an open interface
Floorstanding luminaire to complete the luminaire family in Silica 21 design for a uniform lighting solution & attractive room design thanks to an indirect light component
Configuration & data sheets
- luminaires with intelligent sensors (spatial data acquisition) on request
- luminaire for four workstations on request
- luminaires with colour rendering CRI > 90 on request
- luminaire partly premounted, luminaire head with electrical plug connector
Results
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA3ZM00990XX GTIN (EAN): 4069025333759
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 13280lm | 89.8W | 148lm/W | DALI 2 | traffic white (RAL 9016) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA3ZM00991XX GTIN (EAN): 4069025333773
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 13280lm | 89.8W | 148lm/W | DALI 2 | jet black (RAL 9005) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA3ZM00992XX GTIN (EAN): 4069025333797
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 13280lm | 89.8W | 148lm/W | DALI 2 | metallic grey (RAL 9006) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA4ZM00980XX GTIN (EAN): 4069025333810
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 13280lm | 84.7W | 157lm/W | DALI 2 | traffic white (RAL 9016) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA4ZM00981XX GTIN (EAN): 4069025333834
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 13280lm | 84.7W | 157lm/W | DALI 2 | jet black (RAL 9005) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA4ZM00982XX GTIN (EAN): 4069025333858
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Colour | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 13280lm | 84.7W | 157lm/W | DALI 2 | metallic grey (RAL 9006) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA3ZM00990XXGTIN (EAN): 4069025333759
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 13280lm |
| Connected load | 89.8W |
| Luminous efficacy | 148lm/W |
| Control | DALI 2 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA3ZM00991XXGTIN (EAN): 4069025333773
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 13280lm |
| Connected load | 89.8W |
| Luminous efficacy | 148lm/W |
| Control | DALI 2 |
| Colour | jet black (RAL 9005) |
| Wt. (kg) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA3ZM00992XXGTIN (EAN): 4069025333797
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 13280lm |
| Connected load | 89.8W |
| Luminous efficacy | 148lm/W |
| Control | DALI 2 |
| Colour | metallic grey (RAL 9006) |
| Wt. (kg) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA4ZM00980XXGTIN (EAN): 4069025333810
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 13280lm |
| Connected load | 84.7W |
| Luminous efficacy | 157lm/W |
| Control | DALI 2 |
| Colour | traffic white (RAL 9016) |
| Wt. (kg) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA4ZM00981XXGTIN (EAN): 4069025333834
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 13280lm |
| Connected load | 84.7W |
| Luminous efficacy | 157lm/W |
| Control | DALI 2 |
| Colour | jet black (RAL 9005) |
| Wt. (kg) | 13.7 |
Delivery time on request
Silica 21 Floor L, with ambient light and presence detector, for daylight-dependent control, direct and indirect component separately switchable
Order No.: 51MX53DA4ZM00982XXGTIN (EAN): 4069025333858
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 13280lm |
| Connected load | 84.7W |
| Luminous efficacy | 157lm/W |
| Control | DALI 2 |
| Colour | metallic grey (RAL 9006) |
| Wt. (kg) | 13.7 |
Optional accessories
| Order No.: 5LZ904307GTIN (EAN): 4052899195967 | Show all details |
