Stationary retail is the place for shopping experiences. Crucial for customer satisfaction and business success: the perfect environment. SITECO lighting technology creates atmosphere, supports optimal product presentation and forms the basis for outstanding service.

SITECO Connect solution kit

Product types

SITECO Connect 11

SITECO Connect 21 O

SITECO Connect 31 Retail

SITECO Connect 21 O

Intro product family

Key data

Article control unit
Control DALI 2

Special features

Controller available as DIN rail PC
Future-proof: through open and standardized DALI2 interface
Easy commissioning: all function via commissioning software
Manual intervention: possible at any time by users
Future-proofing and flexibility: through individual addressing and grouping of luminaires and sensors
Cost efficiency: accelerating payback through sensors (daylight and motion)
SITECO HCLlive: light influences our body visually, emotionally and biologically. It sets the pace for our internal clock
Intelligence: intelligent control of luminaires depending on partition walls (e.g. sports halls, meeting rooms, etc.)
Maintenance assistant: easy and quick access to the individual operating hours of the luminaires for better planning of the maintenance calendar; technical requirement: DALI2-certified ECGs according to IEC62386, parts 251, 252, 253; possible on request
Energy monitoring: display of energy consumption; identification of optimization opportunities; technical requirement: DALI2-certified ECGs according to IEC62386, parts 251, 252, 253; possible on request
Dashboard: provides an overview of the status of the lighting system; technical requirement DALI2-certified ECGs according to IEC62386, parts 251, 252, 253; possible on request

Configuration & data sheets

With SITECO Connect 21O, the complete control intelligence is combined in one device
Incl. 2 DALI lines
Per DALI line max. 250mA power supply
Per DALI line max. 64 ECG and 64 sensor addresses
DALI2 certified according to part 101, 103, 303 and 304
Max. 8 controllers can be networked
Compatible DALI 2 sensors and DALI2 push button couplers see "SITECO Connect DALI2 components"
Maintenance assistant: technical requirement DALI 2-certified ECGs according to IEC62386, parts 251, 252, 253
Energy monitoring: technical requirement DALI 2-certified ECGs according to IEC62386, parts 251, 252, 253; possible on request
Dashboard: technical requirement DALI 2-certified ECGs according to IEC62386, parts 251, 252, 253; possible on request

Results

controller

Order No.: 5LZ904712A GTIN (EAN): 4058352548448
FamilyArticleEquipmentControlColourInstallation locationWt. (kg)
SITECO Connect 21-OcontrollermasterDALI 2greyin an electrical distributor0.2
Show all details
Tender textData sheet (PDF, full)Complete download list

controller

Order No.: 5LZ904712AGTIN (EAN): 4058352548448

FamilySITECO Connect 21-O
Articlecontroller
Equipmentmaster
ControlDALI 2
Colourgrey
Installation locationin an electrical distributor
Wt. (kg)0.2
Show all details

Mandatory accessories

Articlemulti-sensor, matt pure white (RAL 9010)PU1 pc.Wt. (kg)0.1Order No.: 5LZ935202AGTIN (EAN): 4058352838105Show all details
Articlesensor module PC3-S, h= 2.5..5m, to the Licross® trunking railPU1 pc.Wt. (kg)0.3Order No.: 56TL1MDSPC3AGTIN (EAN): 4058352407615Show all details
Articlesensor module PC3-S, h= 2.5..5m, to the Licross® trunking railPU1 pc.Wt. (kg)0.3Order No.: 56TL3MDSPC3AGTIN (EAN): 4058352407639Show all details
Articlesensor module PC3-S, h= 2.5..5m, to the Licross® trunking railPU1 pc.Wt. (kg)0.3Order No.: 56TL6MDSPC3AGTIN (EAN): 4058352407653Show all details
Articlesensor module PS2-S, h= 2.5..10m, to the Licross® trunking railPU1 pc.Wt. (kg)0.7Order No.: 56TL1MDSPS2AGTIN (EAN): 4058352400685Show all details
Articlepush button interface, slave, DALI 2PU1 pc.Wt. (kg)0.1Order No.: 5LZ904731AGTIN (EAN): 4058352580318Show all details
