Silica 21 luminaire insert IP40 for Licross
Key data
Article luminaire insert
Protection rating IP40
Net luminous flux 5810lm to 6340lm
Colour temperature 4000K
Lighting effect direct symmetric wide distribution
Special features
Lens-reflector optical system: combination of lens with Fibonacci structure and reflector for homogeneous, perfectly mixed light and even lighting; with design specified darklight reflectors to avoid glare
Links
Configuration & data sheets
- please order Licross trunking rails and trunking rail accessories separately
- with ceiling surface mounting: reducing of maximum allowable ambient temperature of 5°C
Results
Delivery time on request
Licross 21 Silica, white, darklight reflector, white
Order No.: 51TS12DN4ZM00581XX GTIN (EAN): 4058352957462
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 5810 | 33W | 178lm/W | DALI 2 | -25..+50°C | IP40 | 1500 | 2.7 |
Delivery time on request
Licross 21 Silica, black, darklight reflector, black
Order No.: 51TS12DN4ZM00582XX GTIN (EAN): 4058352960011
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 6340 | 39W | 163lm/W | DALI 2 | -25..+45°C | IP40 | 1500 | 2.7 |
Delivery time on request
Licross 21 Silica, white, darklight reflector, white
Order No.: 51TS12DN4ZM00581XXGTIN (EAN): 4058352957462
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 5810 |
| Connected load | 33W |
| Luminous efficacy | 178lm/W |
| Control | DALI 2 |
| ta | -25..+50°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 2.7 |
Delivery time on request
Licross 21 Silica, black, darklight reflector, black
Order No.: 51TS12DN4ZM00582XXGTIN (EAN): 4058352960011
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 6340 |
| Connected load | 39W |
| Luminous efficacy | 163lm/W |
| Control | DALI 2 |
| ta | -25..+45°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 2.7 |
Mandatory accessories
| Order No.: 51TS1S0M5GTIN (EAN): 4069025157751 | Show all details |
| Order No.: 51TS3S0M5GTIN (EAN): 4069025157768 | Show all details |
| Order No.: 51TS6S0M5GTIN (EAN): 4069025157775 | Show all details |
