SITECO Connect DALI-2 components
SITECO Connect for indoor use unlocks the full potential of your lighting system. Sensor-based control saves energy and extends luminaire service life through targeted dimming. In turn, increasing illuminance as needed creates greater visibility and safety when necessary. Lighting management systems automate control, create transparency, and optimize operations, allowing you to focus on what matters most.
Sensors, user interfaces and gateways with an open and standardized DALI-2 interface can be combined to suit specific applications and requirements – for example with SITECO Connect 11 or SITECO Connect 21
Product types
SITECO Connect DALI-2 components
Intro product familyKey data
Article repeater; sensor; relay unit; push button interface; Gateway
Control DALI 2; Bluetooth® Mesh
Special features
DALI-2 ensures greater compatibility, as all certified devices work together across manufacturers
Installation is easier because sensors, switches and luminaires communicate via a common interface
DALI-2 offers more functions, for example for daylight-dependent control or presence detection
The control is more flexible and individually adaptable, which reduces energy consumption and increases comfort
Thanks to standardization, the system is future-proof, easily expandable and easier to maintain
Configuration & data sheets
- a complete slave sensor consists of Interface S and Sensor-Head PR1-S, PR2-S, PC1-S or PC5-S
Results
sensor HE1
Order No.: 56TL1MBSHE1B GTIN (EAN): 4058352542392
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Licross® trunking rail | white | 2.5..6m | ellipsoid detection area | daylight sensor, HF movement sensor | max. ø25m (radial) | shelving system with grid floor, Picktower, data centre | IP20 | 0.5 |
sensor PE1
Order No.: 56TN1SDSPE1B GTIN (EAN): 4058352596326
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Licross® trunking rail | white | 5..14m | ellipsoid detection area | 1 PIR movement sensor, daylight sensor | max. 30x19m | manufacturing hall, for rack and highbay storage, shipping area high rooms | IP54 | 0.6 |
sensor PE1
Order No.: 5LZ912600 GTIN (EAN): 4058352559956
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the ceiling | pure white (RAL 9010) | 5..14m | ellipsoid detection area | 1 PIR movement sensor, daylight sensor | max. 30x19m | manufacturing hall, for rack and highbay storage, shipping area high rooms | IP54 | 0.2 |
sensor D1
Order No.: 5LZ904722A GTIN (EAN): 4058352541524
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the ceiling | white | 4..12m | daylight sensor | manufacturing hall | IP20 | 0.1 |
sensor D1
Order No.: 56TL1MDSD1B GTIN (EAN): 4058352542422
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Licross® trunking rail | white | 4..12m | daylight sensor | manufacturing hall | IP20 | 0.5 |
sensor PS2
Order No.: 5LZ925601 GTIN (EAN): 4058352362020
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in the ceiling | pure white (RAL 9010) | 2.5..10m | square detection area | 1 PIR movement sensor, daylight sensor | radial min./max. 5x 5m/11x 11m, tangential min./max. 6x 6m/28x 28m | office, shipping area high rooms, training room and classroom, sports hall | IP20 | 0.2 |
sensor PS2
Order No.: 56TL1MDSPS2A GTIN (EAN): 4058352400685
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Licross® trunking rail | white | 2.5..10m | square detection area | 1 PIR movement sensor, daylight sensor | radial min./max. 5x 5m/11x 11m, tangential min./max. 6x 6m/28x 28m | office, shipping area high rooms, training room and classroom | IP20 | 0.7 |
sensor PC4
Order No.: 5LZ935202A GTIN (EAN): 4058352838105
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in the ceiling | matt pure white (RAL 9010) | 2..5m | circular detection area | 1 PIR movement sensor, daylight sensor | radial min. ø5m, max. ø7m; tangential min. ø6.5m, max. ø8.5m | for displaying initialization | office, training room and classroom | IP20 | 0.1 |
push button interface
Order No.: 5LZ904731A GTIN (EAN): 4058352580318
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in the switch box | grey | maximum of 4 potential-free push buttons can be connected | IP20 | 0.1 |
Interface S
Order No.: 56TL1FCSA GTIN (EAN): 4058352373880
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Licross® trunking rail | white | corridor and magazine, for rack and highbay storage, parking garage and underground car park, shipping area high rooms | IP20 | 0.8 |
Interface S
Order No.: 5TR305FCSA GTIN (EAN): 4058352635711
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Modario® trunking rail | white | corridor and magazine, for rack and highbay storage, parking garage and underground car park, shipping area high rooms | IP20 | 0.4 |
External Interface S
Order No.: 59US1FCSA GTIN (EAN): 4058352361948
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the ceiling | white | corridor and magazine, for rack and highbay storage, parking garage and underground car park, shipping area high rooms | IP54 | 0.1 |
Sensor-Head PR1-S
Order No.: 59US1HXSPR1A GTIN (EAN): 4058352363997
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the ceiling, to the Modario® trunking rail, to the Licross® trunking rail | white | 2.5..5m | rectangular detection area | 1 PIR movement sensor, daylight sensor | max. 23x6m | light sensor with 'local control' without function | corridor and magazine | IP54 | 0.1 |
Sensor-Head PR2-S
Order No.: 59US1HXSPR2A GTIN (EAN): 4058352361979
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the ceiling, to the Modario® trunking rail, to the Licross® trunking rail | white | 4..14m | rectangular detection area | 1 PIR movement sensor, daylight sensor | max. 30x4m | light sensor with 'local control' without function | for rack and highbay storage | IP54 | 0.1 |
Sensor-Head PC1-S
Order No.: 59US1HXSPC1A GTIN (EAN): 4058352363911
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the ceiling, to the Modario® trunking rail, to the Licross® trunking rail | white | 2.5..4m | circular detection area | 1 PIR movement sensor, daylight sensor | max. ø40m | light sensor with 'local control' without function | shipping area low height | IP54 | 0.1 |
Sensor-Head PC5-S
Order No.: 59US1HXSPC5A GTIN (EAN): 4058352363942
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the ceiling, to the Modario® trunking rail, to the Licross® trunking rail | white | 4..14m | circular detection area | 1 PIR movement sensor, daylight sensor | max. ø36m | light sensor with 'local control' without function | shipping area high rooms | IP54 | 0.1 |
sensor PR3
Order No.: 59MX2BD000WA GTIN (EAN): 4058352602782
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | traffic white (RAL 9016) | 2.5..5m | rectangular detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x4m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with darklight reflector | IP20 | 0.2 |
sensor PR3
Order No.: 59MX2BD000SA GTIN (EAN): 4058352605967
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | metallic grey (RAL 9006) | 2.5..5m | rectangular detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x4m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with darklight reflector | IP20 | 0.2 |
sensor PC3
Order No.: 59MX2CD000WA GTIN (EAN): 4058352605998
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | traffic white (RAL 9016) | 2.5..5m | square detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x5m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with darklight reflector | IP20 | 0.2 |
sensor PC3
Order No.: 59MX2CD000BA GTIN (EAN): 4058352605974
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | jet black (RAL 9005) | 2.5..5m | square detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x5m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with darklight reflector | IP20 | 0.2 |
sensor PC3
Order No.: 59MX2CD000SA GTIN (EAN): 4058352605981
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | metallic grey (RAL 9006) | 2.5..5m | square detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x5m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with darklight reflector | IP20 | 0.2 |
sensor PR3
Order No.: 59MX2BD100WA GTIN (EAN): 4058352760352
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | traffic white (RAL 9016) | 2.5..5m | rectangular detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x4m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with opal or prismatic cover | IP20 | 0.2 |
sensor PR3
Order No.: 59MX2BD100BA GTIN (EAN): 4058352760314
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | jet black (RAL 9005) | 2.5..5m | rectangular detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x4m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with opal or prismatic cover | IP20 | 0.2 |
sensor PR3
Order No.: 59MX2BD100SA GTIN (EAN): 4058352760338
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | metallic grey (RAL 9006) | 2.5..5m | rectangular detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x4m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with opal or prismatic cover | IP20 | 0.2 |
sensor PC3
Order No.: 59MX2CD100WA GTIN (EAN): 4058352760475
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | traffic white (RAL 9016) | 2.5..5m | square detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x5m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with opal or prismatic cover | IP20 | 0.2 |
sensor PC3
Order No.: 59MX2CD100BA GTIN (EAN): 4058352760444
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | jet black (RAL 9005) | 2.5..5m | square detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x5m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with opal or prismatic cover | IP20 | 0.2 |
sensor PC3
Order No.: 59MX2CD100SA GTIN (EAN): 4058352760451
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Silica® luminaire | metallic grey (RAL 9006) | 2.5..5m | square detection area | 1 PIR movement sensor, daylight sensor | tangential max. 4x5m | for surface-mounted luminaires | for pendant luminaires | office | for luminaires with opal or prismatic cover | IP20 | 0.2 |
sensor PC3
Order No.: 56TL1MDSPC3A GTIN (EAN): 4058352407615
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Licross® trunking rail | white | 2.5..5m | 1 PIR movement sensor, daylight sensor | tangential max. 4x5m | office, training room and classroom, shipping area low height | IP20 | 0.3 |
sensor PC3
Order No.: 56TL3MDSPC3A GTIN (EAN): 4058352407639
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Licross® trunking rail | black | 2.5..5m | 1 PIR movement sensor, daylight sensor | tangential max. 4x5m | office, training room and classroom, shipping area low height | IP20 | 0.3 |
sensor PC3
Order No.: 56TL6MDSPC3A GTIN (EAN): 4058352407653
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the Licross® trunking rail | silver | 2.5..5m | 1 PIR movement sensor, daylight sensor | tangential max. 4x5m | office, training room and classroom, shipping area low height | IP20 | 0.3 |
relay unit
Order No.: 5LZ975200A GTIN (EAN): 4069025427991
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in an electrical distributor | grey | 4 relays, 12A each | IP20 | 0.2 |
sensor PR3
Order No.: 5LZ904350A GTIN (EAN): 4069025427014
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in the luminaire | matt pure white (RAL 9010) | 2..5m | rectangular detection area | tangential max. 4x4m | for displaying initialization | office, training room and classroom | IP20 | 0.1 |
Gateway DALI wireless
Order No.: 5LZ950701A GTIN (EAN): 4069025243065
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| to the ceiling, in the ceiling | white | for connection to a DALI-2 application controller | IP20 | 0.2 |
repeater
Order No.: 5LZ904001A GTIN (EAN): 4069025312198
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in an electrical distributor | grey | IP20 | 0.2 |
repeater
Order No.: 5LZ904002A GTIN (EAN): 4069025312204
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in the luminaire | grey | IP20 | 0.1 |
sensor PC14
Order No.: 5LZ910200A GTIN (EAN): 4058352489994
| Installation location | Colour | Mounting height | Feature | Sensor technology | Detection range movement | Feature | Feature | Supplement | Supplement | Application area | Supplement | Protection rating | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in the ceiling | pure white (RAL 9010) | 2..5m | circular detection area | 1 PIR movement sensor, daylight sensor | radial min. ø5m, max. ø7m; tangential min. ø6.5m, max. ø8.5m | office | IP20 | 0.1 |
sensor HE1
Order No.: 56TL1MBSHE1BGTIN (EAN): 4058352542392
| Installation location | to the Licross® trunking rail |
|---|---|
| Colour | white |
| Mounting height | 2.5..6m |
| Feature | ellipsoid detection area |
| Sensor technology | daylight sensor, HF movement sensor |
| Detection range movement | max. ø25m (radial) |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | shelving system with grid floor, Picktower, data centre |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.5 |
sensor PE1
Order No.: 56TN1SDSPE1BGTIN (EAN): 4058352596326
| Installation location | to the Licross® trunking rail |
|---|---|
| Colour | white |
| Mounting height | 5..14m |
| Feature | ellipsoid detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | max. 30x19m |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | manufacturing hall, for rack and highbay storage, shipping area high rooms |
| Supplement | |
| Protection rating | IP54 |
| Wt. (kg) | 0.6 |
sensor PE1
Order No.: 5LZ912600GTIN (EAN): 4058352559956
| Installation location | to the ceiling |
|---|---|
| Colour | pure white (RAL 9010) |
| Mounting height | 5..14m |
| Feature | ellipsoid detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | max. 30x19m |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | manufacturing hall, for rack and highbay storage, shipping area high rooms |
| Supplement | |
| Protection rating | IP54 |
| Wt. (kg) | 0.2 |
sensor D1
Order No.: 5LZ904722AGTIN (EAN): 4058352541524
| Installation location | to the ceiling |
|---|---|
| Colour | white |
| Mounting height | 4..12m |
| Feature | |
| Sensor technology | daylight sensor |
| Detection range movement | |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | manufacturing hall |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.1 |
sensor D1
Order No.: 56TL1MDSD1BGTIN (EAN): 4058352542422
| Installation location | to the Licross® trunking rail |
|---|---|
| Colour | white |
| Mounting height | 4..12m |
| Feature | |
| Sensor technology | daylight sensor |
| Detection range movement | |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | manufacturing hall |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.5 |
sensor PS2
Order No.: 5LZ925601GTIN (EAN): 4058352362020
| Installation location | in the ceiling |
|---|---|
| Colour | pure white (RAL 9010) |
| Mounting height | 2.5..10m |
| Feature | square detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | radial min./max. 5x 5m/11x 11m, tangential min./max. 6x 6m/28x 28m |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | office, shipping area high rooms, training room and classroom, sports hall |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PS2
Order No.: 56TL1MDSPS2AGTIN (EAN): 4058352400685
| Installation location | to the Licross® trunking rail |
|---|---|
| Colour | white |
| Mounting height | 2.5..10m |
| Feature | square detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | radial min./max. 5x 5m/11x 11m, tangential min./max. 6x 6m/28x 28m |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | office, shipping area high rooms, training room and classroom |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.7 |
sensor PC4
Order No.: 5LZ935202AGTIN (EAN): 4058352838105
| Installation location | in the ceiling |
|---|---|
| Colour | matt pure white (RAL 9010) |
| Mounting height | 2..5m |
| Feature | circular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | radial min. ø5m, max. ø7m; tangential min. ø6.5m, max. ø8.5m |
| Feature | for displaying initialization |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | office, training room and classroom |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.1 |
push button interface
Order No.: 5LZ904731AGTIN (EAN): 4058352580318
| Installation location | in the switch box |
|---|---|
| Colour | grey |
| Mounting height | |
| Feature | |
| Sensor technology | |
| Detection range movement | |
| Feature | |
| Feature | maximum of 4 potential-free push buttons can be connected |
| Supplement | |
| Supplement | |
| Application area | |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.1 |
Interface S
Order No.: 56TL1FCSAGTIN (EAN): 4058352373880
| Installation location | to the Licross® trunking rail |
|---|---|
| Colour | white |
| Mounting height | |
| Feature | |
| Sensor technology | |
| Detection range movement | |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | corridor and magazine, for rack and highbay storage, parking garage and underground car park, shipping area high rooms |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.8 |
Interface S
Order No.: 5TR305FCSAGTIN (EAN): 4058352635711
| Installation location | to the Modario® trunking rail |
|---|---|
| Colour | white |
| Mounting height | |
| Feature | |
| Sensor technology | |
| Detection range movement | |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | corridor and magazine, for rack and highbay storage, parking garage and underground car park, shipping area high rooms |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.4 |
External Interface S
Order No.: 59US1FCSAGTIN (EAN): 4058352361948
| Installation location | to the ceiling |
|---|---|
| Colour | white |
| Mounting height | |
| Feature | |
| Sensor technology | |
| Detection range movement | |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | corridor and magazine, for rack and highbay storage, parking garage and underground car park, shipping area high rooms |
| Supplement | |
| Protection rating | IP54 |
| Wt. (kg) | 0.1 |
Sensor-Head PR1-S
Order No.: 59US1HXSPR1AGTIN (EAN): 4058352363997
| Installation location | to the ceiling, to the Modario® trunking rail, to the Licross® trunking rail |
|---|---|
| Colour | white |
| Mounting height | 2.5..5m |
| Feature | rectangular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | max. 23x6m |
| Feature | |
| Feature | light sensor with 'local control' without function |
| Supplement | |
| Supplement | |
| Application area | corridor and magazine |
| Supplement | |
| Protection rating | IP54 |
| Wt. (kg) | 0.1 |
Sensor-Head PR2-S
Order No.: 59US1HXSPR2AGTIN (EAN): 4058352361979
| Installation location | to the ceiling, to the Modario® trunking rail, to the Licross® trunking rail |
|---|---|
| Colour | white |
| Mounting height | 4..14m |
| Feature | rectangular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | max. 30x4m |
| Feature | |
| Feature | light sensor with 'local control' without function |
| Supplement | |
| Supplement | |
| Application area | for rack and highbay storage |
| Supplement | |
| Protection rating | IP54 |
| Wt. (kg) | 0.1 |
Sensor-Head PC1-S
Order No.: 59US1HXSPC1AGTIN (EAN): 4058352363911
| Installation location | to the ceiling, to the Modario® trunking rail, to the Licross® trunking rail |
|---|---|
| Colour | white |
| Mounting height | 2.5..4m |
| Feature | circular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | max. ø40m |
| Feature | |
| Feature | light sensor with 'local control' without function |
| Supplement | |
| Supplement | |
| Application area | shipping area low height |
| Supplement | |
| Protection rating | IP54 |
| Wt. (kg) | 0.1 |
Sensor-Head PC5-S
Order No.: 59US1HXSPC5AGTIN (EAN): 4058352363942
| Installation location | to the ceiling, to the Modario® trunking rail, to the Licross® trunking rail |
|---|---|
| Colour | white |
| Mounting height | 4..14m |
| Feature | circular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | max. ø36m |
| Feature | |
| Feature | light sensor with 'local control' without function |
| Supplement | |
| Supplement | |
| Application area | shipping area high rooms |
| Supplement | |
| Protection rating | IP54 |
| Wt. (kg) | 0.1 |
sensor PR3
Order No.: 59MX2BD000WAGTIN (EAN): 4058352602782
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | traffic white (RAL 9016) |
| Mounting height | 2.5..5m |
| Feature | rectangular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x4m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with darklight reflector |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PR3
Order No.: 59MX2BD000SAGTIN (EAN): 4058352605967
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | metallic grey (RAL 9006) |
| Mounting height | 2.5..5m |
| Feature | rectangular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x4m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with darklight reflector |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PC3
Order No.: 59MX2CD000WAGTIN (EAN): 4058352605998
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | traffic white (RAL 9016) |
| Mounting height | 2.5..5m |
| Feature | square detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x5m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with darklight reflector |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PC3
Order No.: 59MX2CD000BAGTIN (EAN): 4058352605974
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | jet black (RAL 9005) |
| Mounting height | 2.5..5m |
| Feature | square detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x5m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with darklight reflector |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PC3
Order No.: 59MX2CD000SAGTIN (EAN): 4058352605981
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | metallic grey (RAL 9006) |
| Mounting height | 2.5..5m |
| Feature | square detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x5m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with darklight reflector |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PR3
Order No.: 59MX2BD100WAGTIN (EAN): 4058352760352
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | traffic white (RAL 9016) |
| Mounting height | 2.5..5m |
| Feature | rectangular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x4m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with opal or prismatic cover |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PR3
Order No.: 59MX2BD100BAGTIN (EAN): 4058352760314
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | jet black (RAL 9005) |
| Mounting height | 2.5..5m |
| Feature | rectangular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x4m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with opal or prismatic cover |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PR3
Order No.: 59MX2BD100SAGTIN (EAN): 4058352760338
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | metallic grey (RAL 9006) |
| Mounting height | 2.5..5m |
| Feature | rectangular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x4m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with opal or prismatic cover |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PC3
Order No.: 59MX2CD100WAGTIN (EAN): 4058352760475
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | traffic white (RAL 9016) |
| Mounting height | 2.5..5m |
| Feature | square detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x5m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with opal or prismatic cover |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PC3
Order No.: 59MX2CD100BAGTIN (EAN): 4058352760444
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | jet black (RAL 9005) |
| Mounting height | 2.5..5m |
| Feature | square detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x5m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with opal or prismatic cover |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PC3
Order No.: 59MX2CD100SAGTIN (EAN): 4058352760451
| Installation location | to the Silica® luminaire |
|---|---|
| Colour | metallic grey (RAL 9006) |
| Mounting height | 2.5..5m |
| Feature | square detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x5m |
| Feature | |
| Feature | |
| Supplement | for surface-mounted luminaires |
| Supplement | for pendant luminaires |
| Application area | office |
| Supplement | for luminaires with opal or prismatic cover |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PC3
Order No.: 56TL1MDSPC3AGTIN (EAN): 4058352407615
| Installation location | to the Licross® trunking rail |
|---|---|
| Colour | white |
| Mounting height | 2.5..5m |
| Feature | |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x5m |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | office, training room and classroom, shipping area low height |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.3 |
sensor PC3
Order No.: 56TL3MDSPC3AGTIN (EAN): 4058352407639
| Installation location | to the Licross® trunking rail |
|---|---|
| Colour | black |
| Mounting height | 2.5..5m |
| Feature | |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x5m |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | office, training room and classroom, shipping area low height |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.3 |
sensor PC3
Order No.: 56TL6MDSPC3AGTIN (EAN): 4058352407653
| Installation location | to the Licross® trunking rail |
|---|---|
| Colour | silver |
| Mounting height | 2.5..5m |
| Feature | |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | tangential max. 4x5m |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | office, training room and classroom, shipping area low height |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.3 |
relay unit
Order No.: 5LZ975200AGTIN (EAN): 4069025427991
| Installation location | in an electrical distributor |
|---|---|
| Colour | grey |
| Mounting height | |
| Feature | |
| Sensor technology | |
| Detection range movement | |
| Feature | 4 relays, 12A each |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
sensor PR3
Order No.: 5LZ904350AGTIN (EAN): 4069025427014
| Installation location | in the luminaire |
|---|---|
| Colour | matt pure white (RAL 9010) |
| Mounting height | 2..5m |
| Feature | rectangular detection area |
| Sensor technology | |
| Detection range movement | tangential max. 4x4m |
| Feature | for displaying initialization |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | office, training room and classroom |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.1 |
Gateway DALI wireless
Order No.: 5LZ950701AGTIN (EAN): 4069025243065
| Installation location | to the ceiling, in the ceiling |
|---|---|
| Colour | white |
| Mounting height | |
| Feature | for connection to a DALI-2 application controller |
| Sensor technology | |
| Detection range movement | |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
repeater
Order No.: 5LZ904001AGTIN (EAN): 4069025312198
| Installation location | in an electrical distributor |
|---|---|
| Colour | grey |
| Mounting height | |
| Feature | |
| Sensor technology | |
| Detection range movement | |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.2 |
repeater
Order No.: 5LZ904002AGTIN (EAN): 4069025312204
| Installation location | in the luminaire |
|---|---|
| Colour | grey |
| Mounting height | |
| Feature | |
| Sensor technology | |
| Detection range movement | |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.1 |
sensor PC14
Order No.: 5LZ910200AGTIN (EAN): 4058352489994
| Installation location | in the ceiling |
|---|---|
| Colour | pure white (RAL 9010) |
| Mounting height | 2..5m |
| Feature | circular detection area |
| Sensor technology | 1 PIR movement sensor, daylight sensor |
| Detection range movement | radial min. ø5m, max. ø7m; tangential min. ø6.5m, max. ø8.5m |
| Feature | |
| Feature | |
| Supplement | |
| Supplement | |
| Application area | office |
| Supplement | |
| Protection rating | IP20 |
| Wt. (kg) | 0.1 |
Mandatory accessories
| Order No.: 5LZ904307GTIN (EAN): 4052899195967 | Show all details |
Optional accessories
| Order No.: 5LZ9047212GTIN (EAN): 4008321392091 | Show all details |
| Order No.: 5LZ904320GTIN (EAN): 4052899173385 | Show all details |
| Order No.: 5LZ904322GTIN (EAN): 4052899920293 | Show all details |
| Order No.: 5LZ925APGTIN (EAN): 4050737767505 | Show all details |
| Order No.: 5LZ925BSKGTIN (EAN): 4050737767512 | Show all details |
