Licross® 11
45 years of experience – trunking Made in Germany perfected in our Licross® trunking system. The one-for-all concept offers a variety of luminaire inserts and functional expansion options for maximum flexibility and future compatibility. With its unique 14 cores, the rail system becomes the backbone of the building infrastructure and is ready for a wide range of applications - today and tomorrow. The luminaire inserts offer outstanding lighting technology with up to 209lm/W or low operating costs as well as SITECO-typical optics technology for the best viewing conditions. Various extensions from sensor to cameras and data transmission open up a broad horizon of applications far from lighting, which create additional added value.
Our performance solution: Licross® 11 is our innovative trunking system with maximum efficiency (up to 209lm/W), service life (up to 100,000h) and flexibility

Recessed luminaire insert IP40/IP54
Intro to Productfamily
Data
Article luminaire insert
Protection rating IP40; IP54
Net luminous flux 2600lm to 27420lm
Colour temperature 2700…6500K; 3000K; 3500K; 4000K; 5000K; 6500K
Lighting effect direct asymmetric distribution; direct double asymmetric distribution; direct symmetric narrow distribution; direct symmetric medium distribution; direct symmetric wide distribution; direct symmetric diffuse distribution; direct symmetric ellipsoid, narrow distribution
Specials
Configuration & Datasheets
- please order Licross® trunking rail or trunking rail accessories separately
- with ceiling surface mounting: reducing of maximum allowable ambient temperature of 5°C
- luminaire inserts (AC/DC) suiatble for group and central battery systems according to EN60598-2-22 (even at AC operation)
- With AC/DC luminaire inserts, the power supply can be changed to either mains supply operation L1/L2/L3, emergency supply 1 L´/N´ or emergency supply 2 L´´/N´´ by moving the contacts on the connection block
- with luminaire inserts (AC/DC), luminaires use reduced luminous flux with DC operation (see photometric report for DC operation)
Results
Licross® 11 Recessed MO, with spring catch, symmetric diffuse distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8710 | 49W | 180lm/W | ON/OFF | -35..+35°C | IP54 | 1500 | 2.9 |
Licross® 11 Recessed MO, with spring catch, symmetric diffuse distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9050 | 49 | 55 | 184lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric diffuse distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9960 | 57W | 176lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric diffuse distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14930 | 84W | 178lm/W | DALI 2 | -25..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, symmetric diffuse distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10000 | 55W | 181lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 2.9 |
Licross® 11 Recessed MO, with spring catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8820 | 49W | 182lm/W | ON/OFF | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9060 | 49 | 55 | 186lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 12710 | 67 | 75 | 191lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10080 | 57W | 178lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14000 | 77W | 182lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15120 | 84W | 180lm/W | DALI 2 | -25..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 20300 | 108W | 188lm/W | DALI 2 | -40..+45°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 27080 | 151W | 180lm/W | DALI 2 | -40..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10130 | 55W | 184lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14070 | 75W | 189lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8950 | 49W | 185lm/W | ON/OFF | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9310 | 49 | 55 | 189lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 12740 | 67 | 75 | 192lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed extreme MO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9140 | 50W | 182lm/W | DALI 2 | -25..+45°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10240 | 57W | 181lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10240 | 61W | 169lm/W | DALI 2 (for two DALI lines) | +5..+35°C | IP54 | 1500 | 1.9 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10240 | 61W | 169lm/W | DALI 2 (for two DALI lines) | +5..+35°C | IP54 | 1500 | 1.9 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10240 | 61W | 169lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 1.9 |
Licross® 11 Recessed extreme MO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10240 | 57W | 181lm/W | DALI 2 | -40..+45°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14030 | 77W | 183lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14030 | 81W | 174lm/W | DALI 2 (for two DALI lines) | +5..+30°C | IP54 | 1500 | 1.9 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14030 | 81W | 174lm/W | DALI 2 (for two DALI lines) | +5..+30°C | IP54 | 1500 | 1.9 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14030 | 81W | 174lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 1.9 |
Licross® 11 Recessed extreme HO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14030 | 77W | 183lm/W | DALI 2 | -40..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 7640 | 40W | 191lm/W | DALI 2 | -25..+45°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15360 | 84W | 183lm/W | DALI 2 | -25..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15360 | 88W | 175lm/W | DALI 2 (for two DALI lines) | +5..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15360 | 88W | 175lm/W | DALI 2 (for two DALI lines) | +5..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15360 | 88W | 175lm/W | DALI 2 | +5..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed extreme MO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15360 | 84W | 183lm/W | DALI 2 | -40..+45°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 27150 | 151W | 180lm/W | DALI 2 | -40..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 27150 | 154W | 176lm/W | DALI 2 (for two DALI lines) | +5..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 27150 | 154W | 176lm/W | DALI 2 (for two DALI lines) | +5..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 27150 | 154W | 176lm/W | DALI 2 | +5..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10290 | 55W | 186lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14100 | 75W | 189lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, asymmetric distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8240 | 49W | 170lm/W | ON/OFF | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, asymmetric distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8570 | 49 | 55 | 174lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, asymmetric distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9430 | 57W | 166lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, asymmetric distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14140 | 84W | 168lm/W | DALI 2 | -25..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, asymmetric distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9470 | 55W | 172lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8700 | 49W | 179lm/W | ON/OFF | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9040 | 49 | 55 | 183lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 12610 | 67 | 75 | 190lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed extreme MO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8910 | 50W | 177lm/W | DALI 2 | -25..+45°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9950 | 57W | 175lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed extreme HO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 12830 | 71W | 182lm/W | DALI 2 | -25..+45°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13890 | 77W | 181lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14920 | 84W | 177lm/W | DALI 2 | -25..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed extreme MO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14980 | 85W | 177lm/W | DALI 2 | -25..+45°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 20760 | 112W | 186lm/W | DALI 2 | -40..+45°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 26870 | 151W | 179lm/W | DALI 2 | -40..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 25960 | 145W | 179lm/W | DALI 2 | -40..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9990 | 55W | 181lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric medium distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13950 | 75W | 187lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, double asymmetric distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8580 | 49W | 177lm/W | ON/OFF | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, double asymmetric distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8920 | 49 | 55 | 181lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, double asymmetric distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9810 | 57W | 173lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, double asymmetric distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14720 | 84W | 175lm/W | DALI 2 | -25..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, double asymmetric distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9860 | 55W | 179lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8660 | 49W | 179lm/W | ON/OFF | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9000 | 49 | 55 | 183lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 12420 | 67 | 75 | 187lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9900 | 57W | 175lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13670 | 77W | 178lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14850 | 84W | 177lm/W | DALI 2 | -25..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed extreme MO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14910 | 85W | 176lm/W | DALI 2 | -25..+45°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 20440 | 112W | 183lm/W | DALI 2 | -40..+45°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 26450 | 151W | 176lm/W | DALI 2 | -40..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 25560 | 145W | 177lm/W | DALI 2 | -40..+35°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed MO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9950 | 55W | 180lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed HO, with spring catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6760 | 35W | 195lm/W | DALI 2 | -25..+40°C | IP54 | 2250 | 2.5 |
Licross® 11 Recessed HO, with spring catch, symmetric ellipsoid narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13740 | 75W | 183lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8710 | 49W | 180lm/W | ON/OFF | -35..+35°C | IP40 | 1500 | 1.4 |
Licross® 11 Recessed MO, with spring catch, symmetric diffuse distribution, IP40, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9050 | 49 | 55 | 184lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP40 | 1500 | 1.4 |
