Streetlight SL 31 Area
If you want the maximum, you have to focus on the essentials. And that's exactly what Streetlight SL 31 does. With its special light distribution for areas, the Streetlight SL 31 Area impresses with perfect light, high comfort, and optimal energy efficiency. Thanks to various interfaces, it offers flexibility, both today and tomorrow. Environmental protection and sustainability are evident in every detail, and on-site development and production in Traunreut ensure short delivery times and routes.
Focused on what matters. For maximum results in area lighting. That's Streetlight SL 31 Area
Streetlight SL 31 midi Area
Intro to Productfamily
Data
Article mast luminaire
Net luminous flux 10460lm to 19840lm
Colour temperature 2200K; 3000K; 4000K
Lighting effect direct asymmetric wide distribution
Light distribution PL52
Protection rating IP66
Insulation class insulation class I (protective earthing); insulation class II (safety insulation)
Specials
Long service life of more than 100,000h, also thanks to future-proof product concept and long-life components
Light distributions are based on our non-yellowing PMMA lens platform. Mixing and rotating the lens plates for other light distributions is possible on request if required.
Easy installation thanks to pre-assembled connection cable as standard
Mast flange for spigot size 60/76mm with inclination adjustment (-15°…+20° (post-top), -20°…+20° (side-entry) included in delivery
All variants of the Streetlight SL 31 can be individually parameterized either with our SITECO® Service Box (5EA6TEF03) or wirelessly and without voltage with our Desk-Remote variant via our SITECO® Handheld (5EA6HBR02)
Easy and Easy LST variants are the basic variants of the new Streetlight SL 31. The variants can be operated as an ON/OFF luminaire, with a Night-Set profile or Lumen-Switch. The Easy LST variant also has the function of being controlled via a reducing wire
Smart-City-ready: future-proof thanks to two optional Zhaga or NEMA interfaces (7pin) for state-of-the-art lighting control, wireless networking and versatile sensors
Desk-Remote: voltage-free transmission of data to the luminaire via application-optimized NFC function/RFID function, even through the packaging
Configuration & Datasheets
- mast flange for mast spigot diameter 76mm and 60mm contained in product
- mast flange 60/48/42mm or 76…34mm available on request
- Pre-assembled connection cable (H07RN-F)
- Other connection cable types and lengths available on request
Results
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52, with Smart Interface below and above, opened without tools
Order No.: 5XH7H31T08LA GTIN (EAN): 4069025099877
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 12940lm | PL52 | D4i, Desk-Remote | 87 | 90 | 40 | 9.3 | 943.60 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52, with Smart Interface below and above, opened without tools
Order No.: 5XH7H31T08MA GTIN (EAN): 4069025099884
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 18970lm | PL52 | D4i, Desk-Remote | 143 | 159 | 60 | 9.5 | 992.60 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52, with Smart Interface above, opened without tools
Order No.: 5XH7H75N08LA GTIN (EAN): 4069025099907
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 10460lm | PL52 | NEMA (7pin), Desk-Remote | 87 | 90 | 40 | 9.7 | 906.90 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52, opened without tools
Order No.: 5XH7H4AA08MA GTIN (EAN): 4069025096487
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 19840lm | PL52 | Easy LST | 145 | 162 | 61 | 9.5 | 877.50 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52, with Smart Interface above, opened without tools
Order No.: 5XH7H75N08MA GTIN (EAN): 4069025099921
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 15480lm | PL52 | NEMA (7pin), Desk-Remote | 145 | 162 | 61 | 10.0 | 955.90 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52
Order No.: 5XH3H4AA08MA GTIN (EAN): 4069025128096
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 19840lm | PL52 | Easy LST | 145 | 162 | 61 | 9.5 | 860.30 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52, with Smart Interface below and above, opened without tools
Order No.: 5XH7H31T08LAGTIN (EAN): 4069025099877
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 12940lm |
| Light distribution | PL52 |
| Control | D4i, Desk-Remote |
| Pnom begin service life | 87 |
| Pnom end service life | 90 |
| Pred at 50% lumin. flux | 40 |
| Wt. (kg) | 9.3 |
| Price (EUR) | 943.60 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52, with Smart Interface below and above, opened without tools
Order No.: 5XH7H31T08MAGTIN (EAN): 4069025099884
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 18970lm |
| Light distribution | PL52 |
| Control | D4i, Desk-Remote |
| Pnom begin service life | 143 |
| Pnom end service life | 159 |
| Pred at 50% lumin. flux | 60 |
| Wt. (kg) | 9.5 |
| Price (EUR) | 992.60 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52, with Smart Interface above, opened without tools
Order No.: 5XH7H75N08LAGTIN (EAN): 4069025099907
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 10460lm |
| Light distribution | PL52 |
| Control | NEMA (7pin), Desk-Remote |
| Pnom begin service life | 87 |
| Pnom end service life | 90 |
| Pred at 50% lumin. flux | 40 |
| Wt. (kg) | 9.7 |
| Price (EUR) | 906.90 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52, opened without tools
Order No.: 5XH7H4AA08MAGTIN (EAN): 4069025096487
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 19840lm |
| Light distribution | PL52 |
| Control | Easy LST |
| Pnom begin service life | 145 |
| Pnom end service life | 162 |
| Pred at 50% lumin. flux | 61 |
| Wt. (kg) | 9.5 |
| Price (EUR) | 877.50 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52, with Smart Interface above, opened without tools
Order No.: 5XH7H75N08MAGTIN (EAN): 4069025099921
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 15480lm |
| Light distribution | PL52 |
| Control | NEMA (7pin), Desk-Remote |
| Pnom begin service life | 145 |
| Pnom end service life | 162 |
| Pred at 50% lumin. flux | 61 |
| Wt. (kg) | 10.0 |
| Price (EUR) | 955.90 |
Streetlight SL 31 midi, direct asymmetric wide distribution, PL52
Order No.: 5XH3H4AA08MAGTIN (EAN): 4069025128096
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 19840lm |
| Light distribution | PL52 |
| Control | Easy LST |
| Pnom begin service life | 145 |
| Pnom end service life | 162 |
| Pred at 50% lumin. flux | 61 |
| Wt. (kg) | 9.5 |
| Price (EUR) | 860.30 |
Optional accessory
| Order No.: 5XEBLC30AGTIN (EAN): 4069025237941 | Show details |
