SITECO Connect 41

ProdukttyperKonfigurasjon og datablad

SITECO Connect for indoor use unlocks the full potential of your lighting system. Sensor-based control saves energy and extends luminaire service life through targeted dimming. In turn, increasing illuminance as needed creates greater visibility and safety when necessary. Lighting management systems automate control, create transparency, and optimize operations, allowing you to focus on what matters most

Users can adjust the brightness and light colour themselves – a simple solution for individual rooms, without the need for a central lighting or building management system

Luminaires can be switched on and off or dimmed using a push button (ECG DALI).

Introduksjon til produktfamilien

Hovedegenskaper

Varetekst lysadministrasjonskomponenter
Styring DALI

Spesielle egenskaper

Light only when and where and to the extent that it is actually needed
The user can control the lighting at any time using a push button (on/off/dimming)
The controller bundles the entire control intelligence for the room in one device
Significantly less installation and cabling effort than with central lighting or building management systems
Easy commissioning via push button - DALI knowledge is not necessary

Konfigurasjon og datablad

  • DALI, hovedfunksjon, kringkastingsadressering, maks. 32 DALI-HF-er
  • push button short press: On/Off, push button long press: dimming, push button double press: save switch-on setpoint

Resultater

kontroller, i taket

Bestillingsnummer: 5LZ904315 GTIN (EAN): 4058352559925
StyringMonteringstypeKapslingsklasseVekt (kg)
DALIinnfellingIP200,1

kontroller, i taket

Bestillingsnummer: 5LZ904315GTIN (EAN): 4058352559925

StyringDALI
Monteringstypeinnfelling
KapslingsklasseIP20
Vekt (kg)0,1

Nødvendig tilbehør

VaretekststrekkavlastningForpakningsenhet2 stykkVekt (kg)0,1Bestillingsnummer: 5LZ9047212GTIN (EAN): 4008321392091Elnummer: 4515534Vis alle detaljer
