SITECO Connect DALI2 components
SITECO Connect sensors with a DALI2 interface can be connected to a wide variety of control systems such as SITECO Connect 11, 21, 31 or other lighting and building control systems available on the market. The future-proof sensors can be retrofitted thanks to open and standardized interfaces. Remain as flexible as possible, even if your individual requirements change: the sensors can be relocated at any time.
Open interfaces enable modularity, flexibility and future safety
for shipping areas (2…4m) and car parks
Intro to Productfamily
Data
Opis senzor; osnovni modul
Upravljanje DALI 2
Specials
DALI2 standard guarantees future safety through an open interface and flexibility in the event of later changes
Any connection to SITECO Connect 11, 21 and 31 gen2 or to any other LMS or BMS system with a certified DALI2 interface according to part 101, 103, 303 and 304
Multi-sensor for use in shipping areas and roofed car parks (mounting height 2…4m)
Very high detection quality for high work safety and low follow-up times
Separate and powerful localization LED for quick and safe commissioning
Sensor planning in Relux saves time and gives you the security of planning sensor detection correctly
Large detection area for a low number of sensors required and low investment
Cut-off option for the detection range for even more precise control
Configuration & Datasheets
- a sensor unit consists of sensor head and interface
- DALI2 certified according to part 101,103,303,304
- DALI current I= 6mA
Results
External Interface S, slave
Oznaka za naročilo: 59US1FCSAGTIN (EAN): 4058352361948
| Opis | Območje zaznavanja gibanja | Montažna višina | Masa (kg) |
|---|---|---|---|
| External Interface S | 0,1 |
Sensor-Head PC1-S, slave
Oznaka za naročilo: 59US1HXSPC1AGTIN (EAN): 4058352363911
| Opis | Območje zaznavanja gibanja | Montažna višina | Masa (kg) |
|---|---|---|---|
| Sensor-Head PC1-S | D maks. 40m | 2,5..4m | 0,1 |
Interface S, slave
Oznaka za naročilo: 56TL1FCSAGTIN (EAN): 4058352373880
| Opis | Območje zaznavanja gibanja | Montažna višina | Masa (kg) |
|---|---|---|---|
| Interface S | 0,5 |
Interface S, slave
Oznaka za naročilo: 5TR305FCSAGTIN (EAN): 4058352635711
| Opis | Območje zaznavanja gibanja | Montažna višina | Masa (kg) |
|---|---|---|---|
| Interface S | 0,4 |
External Interface S, slave
Oznaka za naročilo: 59US1FCSAGTIN (EAN): 4058352361948
| Opis | External Interface S |
|---|---|
| Območje zaznavanja gibanja | |
| Montažna višina | |
| Masa (kg) | 0,1 |
Sensor-Head PC1-S, slave
Oznaka za naročilo: 59US1HXSPC1AGTIN (EAN): 4058352363911
| Opis | Sensor-Head PC1-S |
|---|---|
| Območje zaznavanja gibanja | D maks. 40m |
| Montažna višina | 2,5..4m |
| Masa (kg) | 0,1 |
Interface S, slave
Oznaka za naročilo: 56TL1FCSAGTIN (EAN): 4058352373880
| Opis | Interface S |
|---|---|
| Območje zaznavanja gibanja | |
| Montažna višina | |
| Masa (kg) | 0,5 |
Interface S, slave
Oznaka za naročilo: 5TR305FCSAGTIN (EAN): 4058352635711
| Opis | Interface S |
|---|---|
| Območje zaznavanja gibanja | |
| Montažna višina | |
| Masa (kg) | 0,4 |
Mandatory accessory
| Oznaka za naročilo: 5LZ930101GTIN (EAN): 4058352385913 | Show details |
| Oznaka za naročilo: 5LZ930103GTIN (EAN): 4058352385937 | Show details |
| Oznaka za naročilo: 5LZ930100GTIN (EAN): 4058352385906 | Show details |
| Oznaka za naročilo: 5LZ930102GTIN (EAN): 4058352385920 | Show details |
Optional accessory
| Oznaka za naročilo: 5LZ925BSKGTIN (EAN): 4050737767512 | Show details |
| Oznaka za naročilo: 59US3HGTIN (EAN): 4058352364000 | Show details |
| Oznaka za naročilo: 59US6HGTIN (EAN): 4058352364017 | Show details |
