Floodlight FL 11
With the Floodlight FL 11 from SITECO you don't have to make any compromises. Regardless of whether it is a soccer field, sports arena, airport or logistics area, this floodlight offers completely new possibilities for illuminating areas down to the last detail and always reacting flexibly to all eventualities. With our power solution you save money, electricity and CO2. It manages with fewer floodlights than a comparable LED solution, but illuminates surfaces even more precisely thanks to new light distributions. Stay flexible in planning, installation, alignment and control. This also includes the flexible placement of the ECG, 360° rotatable LED modules and two construction sizes.
Our performance solution: Floodlight FL 11 is our innovative floodlight with maximum efficiency, service life and flexibility
Floodlight FL 11 maxi Remote for remote ECG mounting
Intro to Productfamily
Data
Article floodlight
Lighting effect direct asymmetric distribution; direct rotationally symmetric distribution
Light distribution PL43; PL52; PL61; RS07; RS12; PL64; PL33T; PL33TBLC; PL64BLC
Net luminous flux 70980lm to 120710lm
Colour temperature 3000K; 4000K; 5000K; 5700K
Control DMX+RDM
Specials
Avoidance of light spill and glare due to design as a wide beam floodlight with 0% light immission
Maximum flexibility in planning through individually adjustable, continuously adjustable single modules
Rear shielding by internal panels (BLC) and warm white light colours for insect-friendly lighting
Variable ECG for connection voltages from 230 to 400V
Detached ECG for installation e.g. in the control cabinet, possible cable lengths of up to 150m
Very long service life of up to 100,000 hours thanks to optimum heat dissipation via cooling ribs
Future security through ESD-protected, exchangeable LED modules and ECGs
Very robust due to IP66 protection rating and vibration stability with over 250,000 strokes as well as ESD-protected plug&play modules for simple maintenance and low maintenance costs
Configuration & Datasheets
- net luminous flux specification based on annual average ambient temperature of 10°C
Results
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution
Order No.: 5XA779412A01AAGTIN (EAN): 4058352573570
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 117880lm | 947W | 124lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution
Order No.: 5XA779412E01AAGTIN (EAN): 4058352573617
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 116480lm | 947W | 123lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution
Order No.: 5XA779412F01AAGTIN (EAN): 4058352573655
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 114400lm | 947W | 121lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution
Order No.: 5XA779413A01AAGTIN (EAN): 4058352573693
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 120710lm | 967W | 125lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution
Order No.: 5XA779413E01AAGTIN (EAN): 4058352573730
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 119270lm | 967W | 123lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution
Order No.: 5XA779413F01AAGTIN (EAN): 4058352573778
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 117140lm | 967W | 121lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779514A01AAGTIN (EAN): 4058352574041
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5700K | CRI > 90 | 89050lm | 917W | 97lm/W | DMX+RDM | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779514E01AAGTIN (EAN): 4058352574072
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5700K | CRI > 90 | 87990lm | 917W | 96lm/W | DMX+RDM | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, RS07, rotationally symmetric distribution, Anti Glow
Order No.: 5XA779514K01AAGTIN (EAN): 4058352574119
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5700K | CRI > 90 | 88570lm | 917W | 97lm/W | DMX+RDM | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, RS12, rotationally symmetric distribution, Anti Glow
Order No.: 5XA779514M01AAGTIN (EAN): 4058352574157
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5700K | CRI > 90 | 90180lm | 917W | 98lm/W | DMX+RDM | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution
Order No.: 5XA779412A01BAGTIN (EAN): 4058352573594
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 102380lm | 748W | 137lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution
Order No.: 5XA779412E01BAGTIN (EAN): 4058352573631
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 92860lm | 664W | 140lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution
Order No.: 5XA779412F01BAGTIN (EAN): 4058352573679
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 91200lm | 664W | 137lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution
Order No.: 5XA779413A01BAGTIN (EAN): 4058352573723
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 104660lm | 758W | 138lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution
Order No.: 5XA779413E01BAGTIN (EAN): 4058352573754
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 92980lm | 654W | 142lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution
Order No.: 5XA779413F01BAGTIN (EAN): 4058352573792
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 91320lm | 654W | 140lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779514A01BAGTIN (EAN): 4058352574058
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5700K | CRI > 90 | 75700lm | 708W | 107lm/W | DMX+RDM | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779514E01BAGTIN (EAN): 4058352574096
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5700K | CRI > 90 | 74800lm | 708W | 106lm/W | DMX+RDM | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, RS07, rotationally symmetric distribution, Anti Glow
Order No.: 5XA779514K01BAGTIN (EAN): 4058352574133
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5700K | CRI > 90 | 75300lm | 708W | 106lm/W | DMX+RDM | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, RS12, rotationally symmetric distribution, Anti Glow
Order No.: 5XA779514M01BAGTIN (EAN): 4058352574171
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5700K | CRI > 90 | 76600lm | 708W | 108lm/W | DMX+RDM | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779415A01AAGTIN (EAN): 4058352607626
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 111140lm | 917W | 121lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779415C01BAGTIN (EAN): 4058352607695
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 94640lm | 708W | 134lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779415C01AAGTIN (EAN): 4058352607664
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 111360lm | 917W | 121lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779415D01BAGTIN (EAN): 4058352607725
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 92460lm | 708W | 131lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779415D01AAGTIN (EAN): 4058352607701
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 108800lm | 917W | 119lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779415E01BAGTIN (EAN): 4058352607763
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 93330lm | 708W | 132lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779415E01AAGTIN (EAN): 4058352607749
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 109820lm | 917W | 120lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution, Anti Glow
Order No.: 5XA779415F01AAGTIN (EAN): 4058352607787
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 107860lm | 917W | 118lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779415A01BAGTIN (EAN): 4058352607640
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 94450lm | 708W | 133lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779416A01AAGTIN (EAN): 4058352607800
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 117880lm | 947W | 124lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779416C01BAGTIN (EAN): 4058352607848
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 102580lm | 748W | 137lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779416C01AAGTIN (EAN): 4058352597286
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 118100lm | 947W | 125lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779416D01BAGTIN (EAN): 4058352607862
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 100220lm | 748W | 134lm/W | DALI 2 (1 DALI address) | 29.6 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779416D01AAGTIN (EAN): 4058352597309
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 115390lm | 947W | 122lm/W | DALI 2 (1 DALI address) | 29.6 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779416E01BAGTIN (EAN): 4058352607909
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 92860lm | 664W | 140lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779416E01AAGTIN (EAN): 4058352607886
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 116480lm | 947W | 123lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution, Anti Glow
Order No.: 5XA779416F01AAGTIN (EAN): 4058352607923
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 114400lm | 947W | 121lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779416A01BAGTIN (EAN): 4058352607831
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 102380lm | 748W | 137lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779417A01AAGTIN (EAN): 4058352607947
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 120710lm | 967W | 125lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779417C01BAGTIN (EAN): 4058352608005
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 104860lm | 758W | 138lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779417C01AAGTIN (EAN): 4058352607992
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 120490lm | 967W | 125lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779417D01BAGTIN (EAN): 4058352608043
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 102450lm | 758W | 135lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779417D01AAGTIN (EAN): 4058352608029
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 118160lm | 967W | 122lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779417E01BAGTIN (EAN): 4058352608081
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 92980lm | 654W | 142lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779417E01AAGTIN (EAN): 4058352608067
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 119270lm | 967W | 123lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution, Anti Glow
Order No.: 5XA779417F01AAGTIN (EAN): 4058352608104
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 117140lm | 967W | 121lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779417A01BAGTIN (EAN): 4058352607961
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 104660lm | 758W | 138lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64BLC, asymmetric distribution, Anti Glow
Order No.: 5XA779411B01AAGTIN (EAN): 4058352607480
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 70980lm | 918W | 77lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33TBLC, asymmetric distribution, Anti Glow
Order No.: 5XA779411H01AAGTIN (EAN): 4058352607527
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 80050lm | 918W | 87lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64BLC, asymmetric distribution
Order No.: 5XA779412B01AAGTIN (EAN): 4058352607558
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 948W | 74lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33TBLC, asymmetric distribution
Order No.: 5XA779412H01AAGTIN (EAN): 4058352607565
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 948W | 90lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64BLC, asymmetric distribution
Order No.: 5XA779413B01AAGTIN (EAN): 4058352607589
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 77090lm | 968W | 80lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33TBLC, asymmetric distribution
Order No.: 5XA779413H01AAGTIN (EAN): 4058352607602
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 5000K | CRI > 70 | 86950lm | 968W | 90lm/W | DALI 2 (1 DALI address) | 35.1 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution
Order No.: 5XA779411F01BAGTIN (EAN): 4058352607503
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | Wt. (kg) |
|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 91670lm | 708W | 129lm/W | DALI 2 (1 DALI address) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution
Order No.: 5XA779412A01AAGTIN (EAN): 4058352573570
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 117880lm |
| Connected load | 947W |
| Luminous efficacy | 124lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution
Order No.: 5XA779412E01AAGTIN (EAN): 4058352573617
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 116480lm |
| Connected load | 947W |
| Luminous efficacy | 123lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution
Order No.: 5XA779412F01AAGTIN (EAN): 4058352573655
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 114400lm |
| Connected load | 947W |
| Luminous efficacy | 121lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution
Order No.: 5XA779413A01AAGTIN (EAN): 4058352573693
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 120710lm |
| Connected load | 967W |
| Luminous efficacy | 125lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution
Order No.: 5XA779413E01AAGTIN (EAN): 4058352573730
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 119270lm |
| Connected load | 967W |
| Luminous efficacy | 123lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution
Order No.: 5XA779413F01AAGTIN (EAN): 4058352573778
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 117140lm |
| Connected load | 967W |
| Luminous efficacy | 121lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779514A01AAGTIN (EAN): 4058352574041
| Colour temperature | 5700K |
|---|---|
| Colour rendering | CRI > 90 |
| Luminous flux | 89050lm |
| Connected load | 917W |
| Luminous efficacy | 97lm/W |
| Control | DMX+RDM |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779514E01AAGTIN (EAN): 4058352574072
| Colour temperature | 5700K |
|---|---|
| Colour rendering | CRI > 90 |
| Luminous flux | 87990lm |
| Connected load | 917W |
| Luminous efficacy | 96lm/W |
| Control | DMX+RDM |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, RS07, rotationally symmetric distribution, Anti Glow
Order No.: 5XA779514K01AAGTIN (EAN): 4058352574119
| Colour temperature | 5700K |
|---|---|
| Colour rendering | CRI > 90 |
| Luminous flux | 88570lm |
| Connected load | 917W |
| Luminous efficacy | 97lm/W |
| Control | DMX+RDM |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, RS12, rotationally symmetric distribution, Anti Glow
Order No.: 5XA779514M01AAGTIN (EAN): 4058352574157
| Colour temperature | 5700K |
|---|---|
| Colour rendering | CRI > 90 |
| Luminous flux | 90180lm |
| Connected load | 917W |
| Luminous efficacy | 98lm/W |
| Control | DMX+RDM |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution
Order No.: 5XA779412A01BAGTIN (EAN): 4058352573594
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 102380lm |
| Connected load | 748W |
| Luminous efficacy | 137lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution
Order No.: 5XA779412E01BAGTIN (EAN): 4058352573631
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 92860lm |
| Connected load | 664W |
| Luminous efficacy | 140lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution
Order No.: 5XA779412F01BAGTIN (EAN): 4058352573679
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 91200lm |
| Connected load | 664W |
| Luminous efficacy | 137lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution
Order No.: 5XA779413A01BAGTIN (EAN): 4058352573723
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 104660lm |
| Connected load | 758W |
| Luminous efficacy | 138lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution
Order No.: 5XA779413E01BAGTIN (EAN): 4058352573754
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 92980lm |
| Connected load | 654W |
| Luminous efficacy | 142lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution
Order No.: 5XA779413F01BAGTIN (EAN): 4058352573792
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 91320lm |
| Connected load | 654W |
| Luminous efficacy | 140lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779514A01BAGTIN (EAN): 4058352574058
| Colour temperature | 5700K |
|---|---|
| Colour rendering | CRI > 90 |
| Luminous flux | 75700lm |
| Connected load | 708W |
| Luminous efficacy | 107lm/W |
| Control | DMX+RDM |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779514E01BAGTIN (EAN): 4058352574096
| Colour temperature | 5700K |
|---|---|
| Colour rendering | CRI > 90 |
| Luminous flux | 74800lm |
| Connected load | 708W |
| Luminous efficacy | 106lm/W |
| Control | DMX+RDM |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, RS07, rotationally symmetric distribution, Anti Glow
Order No.: 5XA779514K01BAGTIN (EAN): 4058352574133
| Colour temperature | 5700K |
|---|---|
| Colour rendering | CRI > 90 |
| Luminous flux | 75300lm |
| Connected load | 708W |
| Luminous efficacy | 106lm/W |
| Control | DMX+RDM |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, RS12, rotationally symmetric distribution, Anti Glow
Order No.: 5XA779514M01BAGTIN (EAN): 4058352574171
| Colour temperature | 5700K |
|---|---|
| Colour rendering | CRI > 90 |
| Luminous flux | 76600lm |
| Connected load | 708W |
| Luminous efficacy | 108lm/W |
| Control | DMX+RDM |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779415A01AAGTIN (EAN): 4058352607626
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 111140lm |
| Connected load | 917W |
| Luminous efficacy | 121lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779415C01BAGTIN (EAN): 4058352607695
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 94640lm |
| Connected load | 708W |
| Luminous efficacy | 134lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779415C01AAGTIN (EAN): 4058352607664
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 111360lm |
| Connected load | 917W |
| Luminous efficacy | 121lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779415D01BAGTIN (EAN): 4058352607725
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 92460lm |
| Connected load | 708W |
| Luminous efficacy | 131lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779415D01AAGTIN (EAN): 4058352607701
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 108800lm |
| Connected load | 917W |
| Luminous efficacy | 119lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779415E01BAGTIN (EAN): 4058352607763
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 93330lm |
| Connected load | 708W |
| Luminous efficacy | 132lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779415E01AAGTIN (EAN): 4058352607749
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 109820lm |
| Connected load | 917W |
| Luminous efficacy | 120lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution, Anti Glow
Order No.: 5XA779415F01AAGTIN (EAN): 4058352607787
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 107860lm |
| Connected load | 917W |
| Luminous efficacy | 118lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779415A01BAGTIN (EAN): 4058352607640
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 94450lm |
| Connected load | 708W |
| Luminous efficacy | 133lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779416A01AAGTIN (EAN): 4058352607800
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 117880lm |
| Connected load | 947W |
| Luminous efficacy | 124lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779416C01BAGTIN (EAN): 4058352607848
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 102580lm |
| Connected load | 748W |
| Luminous efficacy | 137lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779416C01AAGTIN (EAN): 4058352597286
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 118100lm |
| Connected load | 947W |
| Luminous efficacy | 125lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779416D01BAGTIN (EAN): 4058352607862
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 100220lm |
| Connected load | 748W |
| Luminous efficacy | 134lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 29.6 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779416D01AAGTIN (EAN): 4058352597309
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 115390lm |
| Connected load | 947W |
| Luminous efficacy | 122lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 29.6 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779416E01BAGTIN (EAN): 4058352607909
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 92860lm |
| Connected load | 664W |
| Luminous efficacy | 140lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779416E01AAGTIN (EAN): 4058352607886
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 116480lm |
| Connected load | 947W |
| Luminous efficacy | 123lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL33T, asymmetric distribution, Anti Glow
Order No.: 5XA779416F01AAGTIN (EAN): 4058352607923
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 114400lm |
| Connected load | 947W |
| Luminous efficacy | 121lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779416A01BAGTIN (EAN): 4058352607831
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 102380lm |
| Connected load | 748W |
| Luminous efficacy | 137lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL43, asymmetric distribution, Anti Glow
Order No.: 5XA779417A01AAGTIN (EAN): 4058352607947
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 120710lm |
| Connected load | 967W |
| Luminous efficacy | 125lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779417C01BAGTIN (EAN): 4058352608005
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 104860lm |
| Connected load | 758W |
| Luminous efficacy | 138lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL61, asymmetric distribution, Anti Glow
Order No.: 5XA779417C01AAGTIN (EAN): 4058352607992
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 120490lm |
| Connected load | 967W |
| Luminous efficacy | 125lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779417D01BAGTIN (EAN): 4058352608043
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 102450lm |
| Connected load | 758W |
| Luminous efficacy | 135lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL52, asymmetric distribution, Anti Glow
Order No.: 5XA779417D01AAGTIN (EAN): 4058352608029
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 118160lm |
| Connected load | 967W |
| Luminous efficacy | 122lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
Floodlight FL 11 maxi Remote, floodlight, PL64, asymmetric distribution, Anti Glow
Order No.: 5XA779417E01BAGTIN (EAN): 4058352608081
| Colour temperature | 5000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 92980lm |
| Connected load | 654W |
| Luminous efficacy | 142lm/W |
| Control | DALI 2 (1 DALI address) |
| Wt. (kg) | 23.2 |
