Floodlight FL 20

ProducttypesConfiguration & Datasheets

With the planar floodlight, evenly illuminating large areas is easy thanks to excellent asymmetric light distribution. With four sizes, the powerful Floodlight FL 20 is extremely flexible in use - from parking lots, loading ramps and container terminals to sports facilities and event arenas. Due to the design as a flat surface radiator with 0% light immission up to an inclination of 15°, maximum glare control is guaranteed. Optimized thermal management and a high degree of protection enable reliable operation even under adverse weather conditions.

Our core portfolio: Floodlight FL 20 is our floodlight with the highest standards of efficiency, quality and flexibility for your project

Producttypes

Floodlight FL 20 mini

Floodlight FL 20 mini | single components

Floodlight FL 20 midi

Floodlight FL 20 midi | single components

Floodlight FL 20 midi power

Floodlight FL 20 midi power | single components

SITECO Connect Sport

Floodlight FL 20 midi power

Intro to Productfamily

Data

Article floodlight
Lighting effect direct asymmetric distribution; direct rotationally symmetric distribution
Light distribution PL43; RS05
Net luminous flux 38380lm to 39000lm
Colour temperature 4000K; 5000K
Control Plus

Specials

Avoidance of light spill and glare due to design as a wide beam floodlight with 0% light immission up to an inclination of 15°
Very long service life of up to 100,000 hours thanks to optimal heat dissipation via cooling ribs
Optimized thermal management due to decoupling of module and housing for minimum luminous flux degradation and reliable operation
Very robust due to IP66 protection rating and vibration stability with over 250,000 strokes as well as ESD-protected plug&play modules for simple maintenance and low maintenance costs

Configuration & Datasheets

Lighting effect

Article

Light distribution

Colour temperature

Rated luminous flux (lm)

A complete luminaire consists of: LED unit + housing frame + connection variant (bracket, wall fixing or mast flange adapter). The functionality is only guaranteed with the use of matched components and with identical connected load
  • for combination with mast flange adapter: please order mast flange separately according to mast spigot diameter
  • please order mast flange for luminaires with mast connection according to spigot diameter separately

Results

Floodlight FL 20 midi, PL43, direct asymmetric distribution

Order No.: 5XA7682G2A1KCGTIN (EAN): 4058352234785
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 7038700lm306W127lm/WPlus/DALI15.6
Show details
Tender textData sheet (PDF, full)Photometric report / planning dataAll Downloads

Floodlight FL 20 midi, RS05, direct rotationally symmetric distribution

Order No.: 5XA7682G2H2ACGTIN (EAN): 4058352223710
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 7038380lm306W126lm/WPlus/DALI16.6
Show details
Tender textData sheet (PDF, full)Photometric report / planning dataAll Downloads

Floodlight FL 20 midi, RS05, direct rotationally symmetric distribution

Order No.: 5XA7682G3H2ACGTIN (EAN): 4058352223734
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlWt. (kg)
5000KCRI > 7039000lm306W128lm/WPlus/DALI16.5
Show details
Tender textData sheet (PDF, full)Photometric report / planning dataAll Downloads

Floodlight FL 20 midi, PL43, direct asymmetric distribution

Order No.: 5XA7682G2A1KCGTIN (EAN): 4058352234785

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux38700lm
Connected load306W
Luminous efficacy127lm/W
ControlPlus/DALI
Wt. (kg)15.6
Show details

Floodlight FL 20 midi, RS05, direct rotationally symmetric distribution

Order No.: 5XA7682G2H2ACGTIN (EAN): 4058352223710

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux38380lm
Connected load306W
Luminous efficacy126lm/W
ControlPlus/DALI
Wt. (kg)16.6
Show details

Floodlight FL 20 midi, RS05, direct rotationally symmetric distribution

Order No.: 5XA7682G3H2ACGTIN (EAN): 4058352223734

Colour temperature5000K
Colour renderingCRI > 70
Luminous flux39000lm
Connected load306W
Luminous efficacy128lm/W
ControlPlus/DALI
Wt. (kg)16.5
Show details

Optional accessory

Articleconnection cable, OZ-500, 5X 1.5mm², L= 8mPU1 pc.Wt. (kg)1.3Order No.: 5EA6Y00L09GTIN (EAN): 4050737056111Show details
Articleconnection cable, OZ-500, 5X 1.5mm², L= 10mPU1 pc.Wt. (kg)1.5Order No.: 5EA6Y00L10GTIN (EAN): 4050737071305Show details
Articleconnection cable, OZ-500, 5X 1.5mm², L= 12mPU1 pc.Wt. (kg)1.8Order No.: 5EA6Y00L12GTIN (EAN): 4050737936413Show details
Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 42mmPU1 pc.Wt. (kg)0.6Order No.: 5XA76800XM4GTIN (EAN): 4050737850740Show details
Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 60mmPU1 pc.Wt. (kg)0.6Order No.: 5XA76800XM2GTIN (EAN): 4050737850726Show details
Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 76mmPU1 pc.Wt. (kg)0.8Order No.: 5XA76800XM1GTIN (EAN): 4050737850702Show details
Articlecross-arm, single, galvanised, d_a= 76mmPU1 pc.Wt. (kg)2.2Order No.: 5NY74701XA11GTIN (EAN): 4039806199522Show details
Articlecross-arm, single, galvanised, d_a= 89mmPU1 pc.Wt. (kg)2.3Order No.: 5NY74701XA21GTIN (EAN): 4039806199546Show details
Articlecross-arm, twin, galvanised, d_a= 76mmPU1 pc.Wt. (kg)4.4Order No.: 5NY74802XA11GTIN (EAN): 4039806199447Show details
Articlecross-arm, twin, galvanised, d_a= 89mmPU1 pc.Wt. (kg)4.5Order No.: 5NY74802XA21GTIN (EAN): 4039806199454Show details
Articlecross-arm, single, DB 702S, d_a= 76mmPU1 pc.Wt. (kg)2.2Order No.: 5NY74701XA1108GTIN (EAN): 4050737956107Show details
Articlecross-arm, single, DB 702S, d_a= 89mmPU1 pc.Wt. (kg)2.3Order No.: 5NY74701XA2108GTIN (EAN): 4050737956138Show details
Articlecross-arm, twin, DB 702S, d_a= 76mmPU1 pc.Wt. (kg)4.2Order No.: 5NY74802XA1108GTIN (EAN): 4050737956183Show details
Articlecross-arm, twin, DB 702S, d_a= 89mmPU1 pc.Wt. (kg)4.5Order No.: 5NY74802XA2108GTIN (EAN): 4050737956206Show details
Articlemast arm, twin, galvanised, ɑ= 10°, a= 300mm, d_a= 76mmPU1 pc.Wt. (kg)3.0Order No.: 5NY50102XM10GTIN (EAN): 4039806383020Show details
Articlemast arm, triple, galvanised, ɑ= 10°, a= 300mm, d_a= 76mmPU1 pc.Wt. (kg)3.3Order No.: 5NY50103XM10GTIN (EAN): 4039806383037Show details
Articlemast arm, 4-fold, galvanised, ɑ= 10°, a= 300mm, d_a= 102/108mmPU1 pc.Wt. (kg)8.6Order No.: 5NY50114XM30GTIN (EAN): 4039806383075Show details
Articlemast arm, 5-fold, galvanised, ɑ= 10°, a= 300mm, d_a= 102/108mmPU1 pc.Wt. (kg)9.0Order No.: 5NY50115XM30GTIN (EAN): 4039806383082Show details
Articlemast arm, twin, DB 702S, ɑ= 10°, a= 300mm, d_a= 76mmPU1 pc.Wt. (kg)4.8Order No.: 5NY50102XM18GTIN (EAN): 4050737956008Show details
Articlemast arm, twin, DB 702S, ɑ= 1.5°, a= 300mm, d_a= 76mmPU1 pc.Wt. (kg)6.1Order No.: 5NY50212XM18GTIN (EAN): 4039806851642Show details
Articlemast arm, triple, DB 702S, ɑ= 10°, a= 300mm, d_a= 76mmPU1 pc.Wt. (kg)3.3Order No.: 5NY50103XM18GTIN (EAN): 4050737956022Show details
Articlemast arm, 4-fold, DB 702S, ɑ= 10°, a= 300mm, d_a= 102/108mmPU1 pc.Wt. (kg)8.6Order No.: 5NY50114XM38GTIN (EAN): 4050737956046Show details
