One for all - a module for a wide variety of applications and at the same time efficient and elegant. The Module 540 iQ combines high visual comfort and innovative LED technology with a unique optical guide. Different luminaire designs offer maximum flexibility for a wide variety of architectural requirements and functional applications. Installation and electrical connection on the mast can be done in a few simple steps and without special tools. With its high light output, low energy consumption is already guaranteed. The patented luminous flux tracking system CLO 2.0 ensures even more efficiency.
Flexible and modular into the future of city lighting
Module 540 iQ
Intro to Productfamily
Data
Article electrics components group
Lighting effect asymmetric wide distribution; highly asymmetric extremely wide distribution; symmetric wide distribution
Light distribution ST1.2a; P1.0a; PL1.2s
Net luminous flux 1510lm to 5180lm
Colour temperature 2700K; 2200K; 3000K; 4000K
Control iQ Street-Remote
Insulation class insulation class II (safety insulation)
Configuration & Datasheets
Results
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405EF04FGTIN (EAN): 4058352633502
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1610lm | ST1.2a | iQ Street-Remote | 11 | 11 | 5 | 2.7 | 798.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405EF008GTIN (EAN): 4058352721360
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1530lm | ST1.2a | iQ Street-Remote | 11 | 11 | 5 | 2.7 | 833.70 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405EF04FPGTIN (EAN): 4058352721414
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4950lm | ST1.2a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405EF008PGTIN (EAN): 4058352721384
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4680lm | ST1.2a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 905.40 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405FF04FGTIN (EAN): 4058352633526
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1590lm | P1.0a | iQ Street-Remote | 11 | 11 | 5 | 2.7 | 798.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405FF008GTIN (EAN): 4058352721421
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 1510lm | P1.0a | iQ Street-Remote | 11 | 11 | 5 | 2.7 | 833.70 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405FF04FPGTIN (EAN): 4058352721469
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4920lm | P1.0a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405FF008PGTIN (EAN): 4058352721445
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4700lm | P1.0a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 905.40 |
Module 540 iQ, traffic white (RAL 9016), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405JF04FGTIN (EAN): 4058352633540
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 3110lm | PL1.2s | iQ Street-Remote | 19 | 21 | 10 | 2.7 | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405JF008GTIN (EAN): 4058352721483
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 70 | 2960lm | PL1.2s | iQ Street-Remote | 19 | 21 | 10 | 2.7 | 905.40 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405AF04FGTIN (EAN): 4058352721247
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 1610lm | ST1.2a | iQ Street-Remote | 13 | 13 | 6 | 2.7 | 833.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405AF008GTIN (EAN): 4058352721209
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 1530lm | ST1.2a | iQ Street-Remote | 13 | 13 | 6 | 2.7 | 869.40 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405BF04FGTIN (EAN): 4058352721308
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 1590lm | P1.0a | iQ Street-Remote | 13 | 13 | 6 | 2.7 | 833.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405BF008GTIN (EAN): 4058352721261
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 1510lm | P1.0a | iQ Street-Remote | 13 | 13 | 6 | 2.7 | 869.40 |
Module 540 iQ, traffic white (RAL 9016), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405CF04FGTIN (EAN): 4058352721346
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 3110lm | PL1.2s | iQ Street-Remote | 24 | 26 | 11 | 2.7 | 905.40 |
Module 540 iQ, Siteco® metallic grey (DB 702S), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405CF008GTIN (EAN): 4058352721322
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 2960lm | PL1.2s | iQ Street-Remote | 24 | 26 | 12 | 2.7 | 941.10 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405AF04FPGTIN (EAN): 4058352707289
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 4100lm | ST1.2a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 905.40 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405AF008PGTIN (EAN): 4058352721230
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 3900lm | ST1.2a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 941.10 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405BF04FPGTIN (EAN): 4058352707296
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 4070lm | P1.0a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 905.40 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405BF008PGTIN (EAN): 4058352721285
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2200K | CRI > 70 | 3870lm | P1.0a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 941.10 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405KF04FGTIN (EAN): 4058352721544
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 1610lm | ST1.2a | iQ Street-Remote | 10 | 10 | 5 | 2.7 | 798.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405KF008GTIN (EAN): 4058352721506
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 1530lm | ST1.2a | iQ Street-Remote | 10 | 10 | 5 | 2.7 | 833.70 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405LF04FGTIN (EAN): 4058352721629
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 1590lm | P1.0a | iQ Street-Remote | 10 | 10 | 5 | 2.7 | 798.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405LF008GTIN (EAN): 4058352721599
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 1510lm | P1.0a | iQ Street-Remote | 10 | 10 | 5 | 2.7 | 833.70 |
Module 540 iQ, traffic white (RAL 9016), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405RF04FGTIN (EAN): 4058352678329
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 3110lm | PL1.2s | iQ Street-Remote | 19 | 19 | 9 | 2.7 | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405RF008GTIN (EAN): 4058352721667
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 2960lm | PL1.2s | iQ Street-Remote | 19 | 20 | 9 | 2.7 | 905.40 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405KF04FPGTIN (EAN): 4058352721568
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 5180lm | ST1.2a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405KF008PGTIN (EAN): 4058352721520
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 4920lm | ST1.2a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 905.40 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405LF04FPGTIN (EAN): 4058352721643
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 5150lm | P1.0a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405LF008PGTIN (EAN): 4058352721605
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 70 | 4890lm | P1.0a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 905.40 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405MF04FGTIN (EAN): 4058352831991
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 1610lm | ST1.2a | iQ Street-Remote | 12 | 12 | 6 | 2.7 | 834.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405MF008GTIN (EAN): 4058352831953
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 1530lm | ST1.2a | iQ Street-Remote | 12 | 12 | 6 | 2.7 | 869.00 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405MF04FPGTIN (EAN): 4058352832011
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 4100lm | ST1.2a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 905.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405MF008PGTIN (EAN): 4058352831977
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 3900lm | ST1.2a | iQ Street-Remote | 34 | 36 | 15 | 2.7 | 941.00 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405NF04FGTIN (EAN): 4058352832073
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 1590lm | P1.0a | iQ Street-Remote | 12 | 12 | 6 | 2.7 | 834.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405NF008GTIN (EAN): 4058352832042
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 1510lm | P1.0a | iQ Street-Remote | 12 | 12 | 6 | 2.7 | 869.00 |
Module 540 iQ, traffic white (RAL 9016), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405OF04FGTIN (EAN): 4058352832134
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 3110lm | PL1.2s | iQ Street-Remote | 24 | 26 | 11 | 2.7 | 977.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405OF008GTIN (EAN): 4058352832110
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Pnom begin service life | Pnom end service life | Pred at 50% lumin. flux | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|
| 2700K | CRI > 70 | 2960lm | PL1.2s | iQ Street-Remote | 24 | 26 | 11 | 2.7 | 1013.00 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405EF04FGTIN (EAN): 4058352633502
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1610lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 11 |
| Pnom end service life | 11 |
| Pred at 50% lumin. flux | 5 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 798.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405EF008GTIN (EAN): 4058352721360
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1530lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 11 |
| Pnom end service life | 11 |
| Pred at 50% lumin. flux | 5 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 833.70 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405EF04FPGTIN (EAN): 4058352721414
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4950lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405EF008PGTIN (EAN): 4058352721384
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4680lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 905.40 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405FF04FGTIN (EAN): 4058352633526
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1590lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 11 |
| Pnom end service life | 11 |
| Pred at 50% lumin. flux | 5 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 798.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405FF008GTIN (EAN): 4058352721421
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1510lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 11 |
| Pnom end service life | 11 |
| Pred at 50% lumin. flux | 5 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 833.70 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405FF04FPGTIN (EAN): 4058352721469
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4920lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405FF008PGTIN (EAN): 4058352721445
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4700lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 905.40 |
Module 540 iQ, traffic white (RAL 9016), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405JF04FGTIN (EAN): 4058352633540
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 3110lm |
| Light distribution | PL1.2s |
| Control | iQ Street-Remote |
| Pnom begin service life | 19 |
| Pnom end service life | 21 |
| Pred at 50% lumin. flux | 10 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405JF008GTIN (EAN): 4058352721483
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 2960lm |
| Light distribution | PL1.2s |
| Control | iQ Street-Remote |
| Pnom begin service life | 19 |
| Pnom end service life | 21 |
| Pred at 50% lumin. flux | 10 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 905.40 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405AF04FGTIN (EAN): 4058352721247
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1610lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 13 |
| Pnom end service life | 13 |
| Pred at 50% lumin. flux | 6 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 833.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405AF008GTIN (EAN): 4058352721209
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1530lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 13 |
| Pnom end service life | 13 |
| Pred at 50% lumin. flux | 6 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 869.40 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405BF04FGTIN (EAN): 4058352721308
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1590lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 13 |
| Pnom end service life | 13 |
| Pred at 50% lumin. flux | 6 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 833.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405BF008GTIN (EAN): 4058352721261
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1510lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 13 |
| Pnom end service life | 13 |
| Pred at 50% lumin. flux | 6 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 869.40 |
Module 540 iQ, traffic white (RAL 9016), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405CF04FGTIN (EAN): 4058352721346
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 3110lm |
| Light distribution | PL1.2s |
| Control | iQ Street-Remote |
| Pnom begin service life | 24 |
| Pnom end service life | 26 |
| Pred at 50% lumin. flux | 11 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 905.40 |
Module 540 iQ, Siteco® metallic grey (DB 702S), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405CF008GTIN (EAN): 4058352721322
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 2960lm |
| Light distribution | PL1.2s |
| Control | iQ Street-Remote |
| Pnom begin service life | 24 |
| Pnom end service life | 26 |
| Pred at 50% lumin. flux | 12 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 941.10 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405AF04FPGTIN (EAN): 4058352707289
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4100lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 905.40 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405AF008PGTIN (EAN): 4058352721230
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 3900lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 941.10 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405BF04FPGTIN (EAN): 4058352707296
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4070lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 905.40 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405BF008PGTIN (EAN): 4058352721285
| Colour temperature | 2200K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 3870lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 941.10 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405KF04FGTIN (EAN): 4058352721544
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1610lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 10 |
| Pnom end service life | 10 |
| Pred at 50% lumin. flux | 5 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 798.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405KF008GTIN (EAN): 4058352721506
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1530lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 10 |
| Pnom end service life | 10 |
| Pred at 50% lumin. flux | 5 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 833.70 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405LF04FGTIN (EAN): 4058352721629
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1590lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 10 |
| Pnom end service life | 10 |
| Pred at 50% lumin. flux | 5 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 798.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405LF008GTIN (EAN): 4058352721599
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1510lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 10 |
| Pnom end service life | 10 |
| Pred at 50% lumin. flux | 5 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 833.70 |
Module 540 iQ, traffic white (RAL 9016), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405RF04FGTIN (EAN): 4058352678329
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 3110lm |
| Light distribution | PL1.2s |
| Control | iQ Street-Remote |
| Pnom begin service life | 19 |
| Pnom end service life | 19 |
| Pred at 50% lumin. flux | 9 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405RF008GTIN (EAN): 4058352721667
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 2960lm |
| Light distribution | PL1.2s |
| Control | iQ Street-Remote |
| Pnom begin service life | 19 |
| Pnom end service life | 20 |
| Pred at 50% lumin. flux | 9 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 905.40 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405KF04FPGTIN (EAN): 4058352721568
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 5180lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405KF008PGTIN (EAN): 4058352721520
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4920lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 905.40 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405LF04FPGTIN (EAN): 4058352721643
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 5150lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 869.70 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, Power
Order No.: 5XA5405LF008PGTIN (EAN): 4058352721605
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4890lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 905.40 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405MF04FGTIN (EAN): 4058352831991
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1610lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 12 |
| Pnom end service life | 12 |
| Pred at 50% lumin. flux | 6 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 834.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, standard
Order No.: 5XA5405MF008GTIN (EAN): 4058352831953
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1530lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 12 |
| Pnom end service life | 12 |
| Pred at 50% lumin. flux | 6 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 869.00 |
Module 540 iQ, traffic white (RAL 9016), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405MF04FPGTIN (EAN): 4058352832011
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4100lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 905.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), asymmetric wide distribution, ST1.2a, Power
Order No.: 5XA5405MF008PGTIN (EAN): 4058352831977
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 3900lm |
| Light distribution | ST1.2a |
| Control | iQ Street-Remote |
| Pnom begin service life | 34 |
| Pnom end service life | 36 |
| Pred at 50% lumin. flux | 15 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 941.00 |
Module 540 iQ, traffic white (RAL 9016), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405NF04FGTIN (EAN): 4058352832073
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1590lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 12 |
| Pnom end service life | 12 |
| Pred at 50% lumin. flux | 6 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 834.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), highly asymmetric extremely wide distribution, P1.0a, standard
Order No.: 5XA5405NF008GTIN (EAN): 4058352832042
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 1510lm |
| Light distribution | P1.0a |
| Control | iQ Street-Remote |
| Pnom begin service life | 12 |
| Pnom end service life | 12 |
| Pred at 50% lumin. flux | 6 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 869.00 |
Module 540 iQ, traffic white (RAL 9016), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405OF04FGTIN (EAN): 4058352832134
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 3110lm |
| Light distribution | PL1.2s |
| Control | iQ Street-Remote |
| Pnom begin service life | 24 |
| Pnom end service life | 26 |
| Pred at 50% lumin. flux | 11 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 977.00 |
Module 540 iQ, Siteco® metallic grey (DB 702S), symmetric wide distribution, PL1.2s, standard
Order No.: 5XA5405OF008GTIN (EAN): 4058352832110
| Colour temperature | 2700K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 2960lm |
| Light distribution | PL1.2s |
| Control | iQ Street-Remote |
| Pnom begin service life | 24 |
| Pnom end service life | 26 |
| Pred at 50% lumin. flux | 11 |
| Wt. (kg) | 2.7 |
| Price (EUR) | 1013.00 |
Optional accessory
| Order No.: 5XA54000XSGTIN (EAN): 4050737730073 | Show details |
| Order No.: 5XA54000XSAGTIN (EAN): 4058352161326 | Show details |
| Order No.: 5XA54000XBSGTIN (EAN): 4050737971445 | Show details |
| Order No.: 5XA54000XBLGTIN (EAN): 4050737971421 | Show details |
| Order No.: 5XA54000XBXLGTIN (EAN): 4058352415573 | Show details |
| Order No.: 5XA54001XSGTIN (EAN): 4050737754895 | Show details |
