Monsun® 11

Product typesConfiguration & data sheets

Reliable, robust and with retrofittable sensors. The Monsun® 11 is well prepared for harsh environments. It impresses with standard-compliant lighting and low operating costs, even with On/Off types, thanks to the intelligent CLOi luminous flux control. Thanks to multilumen technology and a large number of different equipment options, the luminaire family enables the necessary adaptability and is ready for a wide variety of lighting tasks - today and tomorrow.

Our performance solution: Monsun® 11 is our innovative luminaire with higher protection rating with maximum efficiency, service life and flexibility

Product types

Monsun® 11 | 1590mm | 70,000h at 35°C

Monsun® 11 | 1590mm | 100,000h at 25°C

Monsun® 11 Xtreme | 1590mm | 70,000h at up to 60°C

Monsun® 11 Emergency | 1590mm

Monsun® 11 Parking | 1590mm

Monsun® 11 Facade | 1590mm

Monsun® 11 | 1590mm - for livestock farming

mounting rail for Monsun® 11/21 | 1590mm

Monsun® 11 Emergency | 1590mm

Intro product family

Key data

Article damp-proof luminaire
Lighting effect direct symmetric wide distribution
Net luminous flux 3840lm to 6050lm
Colour temperature 4000K
Control ON/OFF; DALI 2
Cover PMMA; PC
Protection rating IP66
Insulation class insulation class I (protective earthing)
Protection symbol D
Impact resistance IK08; IK04
Emergency light operation on group/central battery; with self-contained supply
Halogen freeness internal wiring halogen-free
IFS corresponds to IFS (International Featured Standards) requirements for safety and quality in the food industry

Special features

Multilumen technology with luminous fluxes up to 12,000lm for maximum adaptability
Very robust with IP66 protection rating and suitable for outdoor use
in ambient temperatures up to 50°C
Simple maintenance and easy upgrading of sensors due to tool-free opening of the luminaire

Configuration & data sheets

Rated luminous flux (lm)

Control

Cover

Impact resistance

Operating ambient temperature

Emergency light

  • includes ceiling fixing element and chain hanger of V2A; surface-mounting to ceilings without further luminaire-specific mounting accessories; for further installation methods: please order mounting accessory separately
  • for chain suspension: please order chain separately
  • for wall mounting: please order anti-theft/wall mounting protection separately
  • for further installation methods: please order mounting accessory separately
  • for greater anti-theft safety for all types of installation: if required, please order anti-theft/wall mounting protection separately
  • Some luminaires with through-wiring as standard; for other luminaires: please order through-wiring separately if required

Results

Monsun® 11 emergency, wide distribution, ON/OFF, 3h, PMMA

Order No.: 51FP107P437L3G GTIN (EAN): 4069025280299
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlBattery durationtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 803840lm25W182lm/WON/OFF3h-35..+40°CIK0415902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 emergency, wide distribution, ON/OFF, 3h, PMMA

Order No.: 51FP107P467L3G GTIN (EAN): 4069025280336
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlBattery durationtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 806050lm37W179lm/WON/OFF3h+5..+35°CIK0415903.3
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 emergency, wide distribution, DALI 2, 3h, PMMA

Order No.: 51FP10DP467L3H GTIN (EAN): 4069025268716
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlBattery durationtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 806050lm35W192lm/WDALI 23h+5..+35°CIK0415903.3
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 emergency, wide distribution, DALI 2, PMMA

Order No.: 51FP10DP468L2 GTIN (EAN): 4069025268730
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlBattery durationtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 806050lm32W192lm/WDALI 2 -25..+40°CIK0415902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 emergency, wide distribution, ON/OFF, 3h, PC

Order No.: 51FP207P437L3G GTIN (EAN): 4069025280435
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlBattery durationtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 803990lm28W164lm/WON/OFF3h+5..+35°CIK0815903.3
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 emergency, wide distribution, ON/OFF, 3h, PC

Order No.: 51FP207P467L3G GTIN (EAN): 4069025280473
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlBattery durationtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 805450lm37W161lm/WON/OFF3h+5..+35°CIK0815903.3
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 emergency, wide distribution, DALI 2, 3h, PC

Order No.: 51FP20DP467L3H GTIN (EAN): 4069025268938
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlBattery durationtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 805450lm35W173lm/WDALI 23h+5..+35°CIK0815903.3
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 emergency, wide distribution, ON/OFF, 3h, PMMA

Order No.: 51FP107P437L3GGTIN (EAN): 4069025280299

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux3840lm
Connected load25W
Luminous efficacy182lm/W
ControlON/OFF
Battery duration3h
ta-35..+40°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11 emergency, wide distribution, ON/OFF, 3h, PMMA

Order No.: 51FP107P467L3GGTIN (EAN): 4069025280336

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux6050lm
Connected load37W
Luminous efficacy179lm/W
ControlON/OFF
Battery duration3h
ta+5..+35°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)3.3
Show all details

Monsun® 11 emergency, wide distribution, DALI 2, 3h, PMMA

Order No.: 51FP10DP467L3HGTIN (EAN): 4069025268716

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux6050lm
Connected load35W
Luminous efficacy192lm/W
ControlDALI 2
Battery duration3h
ta+5..+35°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)3.3
Show all details

Monsun® 11 emergency, wide distribution, DALI 2, PMMA

Order No.: 51FP10DP468L2GTIN (EAN): 4069025268730

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux6050lm
Connected load32W
Luminous efficacy192lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11 emergency, wide distribution, ON/OFF, 3h, PC

Order No.: 51FP207P437L3GGTIN (EAN): 4069025280435

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux3990lm
Connected load28W
Luminous efficacy164lm/W
ControlON/OFF
Battery duration3h
ta+5..+35°C
Impact resistanceIK08
L (mm)1590
Wt. (kg)3.3
Show all details

Monsun® 11 emergency, wide distribution, ON/OFF, 3h, PC

Order No.: 51FP207P467L3GGTIN (EAN): 4069025280473

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux5450lm
Connected load37W
Luminous efficacy161lm/W
ControlON/OFF
Battery duration3h
ta+5..+35°C
Impact resistanceIK08
L (mm)1590
Wt. (kg)3.3
Show all details

Monsun® 11 emergency, wide distribution, DALI 2, 3h, PC

Order No.: 51FP20DP467L3HGTIN (EAN): 4069025268938

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux5450lm
Connected load35W
Luminous efficacy173lm/W
ControlDALI 2
Battery duration3h
ta+5..+35°C
Impact resistanceIK08
L (mm)1590
Wt. (kg)3.3
Show all details

Optional accessories

Articlethrough-wiring, 3-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.1Order No.: 58FV003GTIN (EAN): 4058352409473Show all details
Articlethrough-wiring, 5-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.1Order No.: 58FV005GTIN (EAN): 4058352409503Show all details
Articlethrough-wiring, 7-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.3Order No.: 58FV007GTIN (EAN): 4058352409510Show all details
Articlethrough-wiring, 5-core, 2.5mm², L= 1.7m, with terminal, for continuous trunkingPU1 pc.Wt. (kg)0.2Order No.: 58FV009GTIN (EAN): 4058352409534Show all details
Articletwin cable gland, M25, rubber, for cables, Ø 8.4..12mmPU1 pc.Wt. (kg)0.1Order No.: 58FV00DGTIN (EAN): 4058352409558Show all details
Articlecable gland with climate membrane, M20, PA / EPDM / ePTFE / silicone, for cables, Ø 6..13mmPU1 pc.Wt. (kg)0.1Order No.: 58FT003GTIN (EAN): 4058352410332Show all details
Articlecable gland, M25, PA / silicone, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT004GTIN (EAN): 4058352410356Show all details
Articlecable gland with climate membrane, M25, PA / EPDM / ePTFE / silicone, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT005GTIN (EAN): 4058352410370Show all details
Articlelink chain, steel, galvanisedPUrun. m.Wt. (kg)0.1Order No.: 5LY9001GTIN (EAN): 4039806184290Show all details
Articlelink chain, stainless steel (V2A)PUrun. m.Wt. (kg)0.1Order No.: 5LY9002GTIN (EAN): 4039806184313Show all details
Articlequick-release link, stainless steel (V2A)PU1 pc.Wt. (kg)0.1Order No.: 5LY9004GTIN (EAN): 4039806184368Show all details
Articlewall fastening, inclinablePU2 pcs.Wt. (kg)0.2Order No.: 58FM002GTIN (EAN): 4058352410257Show all details
Articlepipe clip fixing, for pipe diameter 1.5"PU2 pcs.Wt. (kg)0.2Order No.: 58FM003GTIN (EAN): 4058352426500Show all details
Articlepipe clip fixing, for pipe diameter 2"PU2 pcs.Wt. (kg)0.2Order No.: 58FM004GTIN (EAN): 4058352426524Show all details
Articlewall fastening, horizontal mounting, vertical mountingPU2 pcs.Wt. (kg)0.1Order No.: 58FM007GTIN (EAN): 4058352410295Show all details
Articlefixing reinforcementPU2 pcs.Wt. (kg)0.1Order No.: 58FM006GTIN (EAN): 4058352410271Show all details
Articlespring clip, surface-mounted to the Licross® mounting railPU2 pcs.Wt. (kg)0.1Order No.: 58FM001GTIN (EAN): 4058352410233Show all details
Articlespring clip, surface-mounted to the DUS® mounting railPU2 pcs.Wt. (kg)0.1Order No.: 58FM008GTIN (EAN): 4058352426548Show all details
Articlecable infeed, M20, rubber, for cables, Ø 6..13mmPU1 pc.Wt. (kg)0.1Order No.: 59FT001GTIN (EAN): 4058352410394Show all details
Articlecable infeed, M25, rubber, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT002GTIN (EAN): 4058352410318Show all details
Articlemounting rail, for suspended mounting, surface-mounted, L= 1590mmPU1 pc.Wt. (kg)1.7Order No.: 58FS001GTIN (EAN): 4058352474945Show all details
Articlemounting rail, for suspended mounting, surface-mounted, L= 3180mmPU1 pc.Wt. (kg)3.5Order No.: 58FS002GTIN (EAN): 4058352474976Show all details
Articlemounting rail, for suspended mounting, surface-mounted, L= 4770mmPU1 pc.Wt. (kg)5.2Order No.: 58FS003GTIN (EAN): 4058352475799Show all details
Articleconnector, steel, galvanisedPU1 pc.Wt. (kg)0.3Order No.: 58FS005GTIN (EAN): 4058352477052Show all details
Articlecable holder, for supplementary wiring in the trunking railPU10 pcs.Wt. (kg)0.1Order No.: 59TR1HGTIN (EAN): 4058352476222Show all details
Articleend cap for rail, white, for IP20 protection ratingPU2 pcs.Wt. (kg)0.1Order No.: 59TL1SGTIN (EAN): 4058352272589Show all details
Articleblank cover, white, for IP20/IP40 protection ratingPU1 pc.Wt. (kg)0.2Order No.: 58FS006GTIN (EAN): 4058352466605Show all details
Articleenclosure, PMMA, L= 1590mmPU1 pc.Wt. (kg)0.5Order No.: 59FW001GTIN (EAN): 4058352409572Show all details
Articleenclosure, PC, UV-stabilised, L= 1590mmPU1 pc.Wt. (kg)0.5Order No.: 59FW002GTIN (EAN): 4058352409596Show all details
