Monsun® 11

Product typesConfiguration & data sheets

Reliable, robust and with retrofittable sensors. The Monsun® 11 is well prepared for harsh environments. It impresses with standard-compliant lighting and low operating costs, even with On/Off types, thanks to the intelligent CLOi luminous flux control. Thanks to multilumen technology and a large number of different equipment options, the luminaire family enables the necessary adaptability and is ready for a wide variety of lighting tasks - today and tomorrow.

Our performance solution: Monsun® 11 is our innovative luminaire with higher protection rating with maximum efficiency, service life and flexibility

Product types

Monsun® 11 | 1590mm | 70,000h at 35°C

Monsun® 11 | 1590mm | 100,000h at 25°C

Monsun® 11 Xtreme | 1590mm | 70,000h at up to 60°C

Monsun® 11 Emergency | 1590mm

Monsun® 11 Parking | 1590mm

Monsun® 11 Facade | 1590mm

Monsun® 11 | 1590mm - for livestock farming

mounting rail for Monsun® 11/21 | 1590mm

Monsun® 11 Facade | 1590mm

Intro product family

Key data

Article damp-proof luminaire
Lighting effect direct symmetric diffuse distribution
Net luminous flux 5790lm to 6190lm
Colour temperature 3000K; 4000K
Control ON/OFF Multilumen; DALI 2
Cover PMMA
Protection rating IP66
Insulation class insulation class I (protective earthing)
Protection symbol D
Impact resistance IK06
Halogen freeness internal wiring halogen-free

Special features

Multilumen technology with luminous fluxes up to 12,000lm for maximum adaptability
Very robust with IP66 protection rating and suitable for outdoor use
in ambient temperatures up to 50°C
Simple maintenance and easy upgrading of sensors due to tool-free opening of the luminaire

Configuration & data sheets

  • includes ceiling fixing element and chain hanger of V2A; surface-mounting to ceilings without further luminaire-specific mounting accessories; for further installation methods: please order mounting accessory separately
  • for chain suspension: please order chain separately
  • for wall mounting: please order anti-theft/wall mounting protection separately
  • for further installation methods: please order mounting accessory separately
  • for greater anti-theft safety for all types of installation: if required, please order anti-theft/wall mounting protection separately
  • Some luminaires with through-wiring as standard; for other luminaires: please order through-wiring separately if required

Results

Monsun® 11 facade, diffuse distribution, ON/OFF Multilumen, PMMA

Order No.: 51FF40MP460H GTIN (EAN): 4058352376188
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 806110lm34W182lm/WON/OFF Multilumen -35..+50°CIK0615902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 facade, diffuse distribution, ON/OFF Multilumen, PMMA

Order No.: 51FF40MP360H GTIN (EAN): 4058352820209
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
3000KCRI > 805790lm34W172lm/WON/OFF Multilumen -35..+50°CIK0615902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 facade, diffuse distribution, DALI 2, PMMA

Order No.: 51FF40DP460L007 GTIN (EAN): 4069025268617
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 806190lm32W195lm/WDALI 27x 2.5mm²-25..+30°CIK0615902.8
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 facade, diffuse distribution, ON/OFF Multilumen, PMMA

Order No.: 51FF40MP460HGTIN (EAN): 4058352376188

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux6110lm
Connected load34W
Luminous efficacy182lm/W
ControlON/OFF Multilumen
Through-wiring
ta-35..+50°C
Impact resistanceIK06
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11 facade, diffuse distribution, ON/OFF Multilumen, PMMA

Order No.: 51FF40MP360HGTIN (EAN): 4058352820209

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux5790lm
Connected load34W
Luminous efficacy172lm/W
ControlON/OFF Multilumen
Through-wiring
ta-35..+50°C
Impact resistanceIK06
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11 facade, diffuse distribution, DALI 2, PMMA

Order No.: 51FF40DP460L007GTIN (EAN): 4069025268617

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux6190lm
Connected load32W
Luminous efficacy195lm/W
ControlDALI 2
Through-wiring7x 2.5mm²
ta-25..+30°C
Impact resistanceIK06
L (mm)1590
Wt. (kg)2.8
Show all details

Optional accessories

Articlethrough-wiring, 3-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.1Order No.: 58FV003GTIN (EAN): 4058352409473Show all details
Articlethrough-wiring, 5-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.1Order No.: 58FV005GTIN (EAN): 4058352409503Show all details
Articlethrough-wiring, 7-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.3Order No.: 58FV007GTIN (EAN): 4058352409510Show all details
Articlethrough-wiring, 5-core, 2.5mm², L= 1.7m, with terminal, for continuous trunkingPU1 pc.Wt. (kg)0.2Order No.: 58FV009GTIN (EAN): 4058352409534Show all details
Articletwin cable gland, M25, rubber, for cables, Ø 8.4..12mmPU1 pc.Wt. (kg)0.1Order No.: 58FV00DGTIN (EAN): 4058352409558Show all details
Articleclimate membrane, screwable, M20, PA / EPDM / ePTFE / silicone, for cables, Ø 6..13mmPU1 pc.Wt. (kg)0.1Order No.: 58FT003GTIN (EAN): 4058352410332Show all details
Articlecable gland, M25, PA / silicone, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT004GTIN (EAN): 4058352410356Show all details
Articleclimate membrane, screwable, M25, PA / EPDM / ePTFE / silicone, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT005GTIN (EAN): 4058352410370Show all details
Articlelink chain, steel, galvanisedPUrun. m.Wt. (kg)0.1Order No.: 5LY9001GTIN (EAN): 4039806184290Show all details
Articlelink chain, stainless steel (V2A)PUrun. m.Wt. (kg)0.1Order No.: 5LY9002GTIN (EAN): 4039806184313Show all details
Articlequick-release link, stainless steel (V2A)PU1 pc.Wt. (kg)0.1Order No.: 5LY9004GTIN (EAN): 4039806184368Show all details
Articlewall fastening, inclinablePU2 pcs.Wt. (kg)0.2Order No.: 58FM002GTIN (EAN): 4058352410257Show all details
Articleceiling mountingPU2 pcs.Wt. (kg)0.1Order No.: 58FM012GTIN (EAN): 4069025193957Show all details
Articlepipe clip fixing, for pipe diameter 1.5"PU2 pcs.Wt. (kg)0.2Order No.: 58FM003GTIN (EAN): 4058352426500Show all details
Articlepipe clip fixing, for pipe diameter 2"PU2 pcs.Wt. (kg)0.2Order No.: 58FM004GTIN (EAN): 4058352426524Show all details
Articlewall fastening, horizontal mounting, vertical mountingPU2 pcs.Wt. (kg)0.1Order No.: 58FM007GTIN (EAN): 4058352410295Show all details
Articlefixing reinforcementPU2 pcs.Wt. (kg)0.1Order No.: 58FM006GTIN (EAN): 4058352410271Show all details
Articlespring clip, surface-mounted to the Licross® mounting railPU2 pcs.Wt. (kg)0.1Order No.: 58FM001GTIN (EAN): 4058352410233Show all details
Articlespring clip, surface-mounted to the DUS® mounting railPU2 pcs.Wt. (kg)0.1Order No.: 58FM008GTIN (EAN): 4058352426548Show all details
Articlecable infeed, M20, rubber, for cables, Ø 6..13mmPU1 pc.Wt. (kg)0.1Order No.: 59FT001GTIN (EAN): 4058352410394Show all details
Articlecable infeed, M25, rubber, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT002GTIN (EAN): 4058352410318Show all details
Articlemounting rail, for suspended mounting, surface-mounted, L= 1590mmPU1 pc.Wt. (kg)1.7Order No.: 58FS001GTIN (EAN): 4058352474945Show all details
Articlemounting rail, for suspended mounting, surface-mounted, L= 3180mmPU1 pc.Wt. (kg)3.5Order No.: 58FS002GTIN (EAN): 4058352474976Show all details
Articlemounting rail, for suspended mounting, surface-mounted, L= 4770mmPU1 pc.Wt. (kg)5.2Order No.: 58FS003GTIN (EAN): 4058352475799Show all details
Articleconnector, steel, galvanisedPU1 pc.Wt. (kg)0.3Order No.: 58FS005GTIN (EAN): 4058352477052Show all details
Articlecable holder, for supplementary wiring in the trunking railPU10 pcs.Wt. (kg)0.1Order No.: 59TR1HGTIN (EAN): 4058352476222Show all details
Articleend cap for rail, white, for IP20 protection ratingPU2 pcs.Wt. (kg)0.1Order No.: 59TL1SGTIN (EAN): 4058352272589Show all details
Articleblank cover, white, for IP20/IP40 protection ratingPU1 pc.Wt. (kg)0.2Order No.: 58FS006GTIN (EAN): 4058352466605Show all details
Articleenclosure, PMMA, L= 1590mmPU1 pc.Wt. (kg)0.5Order No.: 59FW004GTIN (EAN): 4058352409640Show all details
