Monsun® 11

Product typesConfiguration & data sheets

Reliable, robust and with retrofittable sensors. The Monsun® 11 is well prepared for harsh environments. It impresses with standard-compliant lighting and low operating costs, even with On/Off types, thanks to the intelligent CLOi luminous flux control. Thanks to multilumen technology and a large number of different equipment options, the luminaire family enables the necessary adaptability and is ready for a wide variety of lighting tasks - today and tomorrow.

Our performance solution: Monsun® 11 is our innovative luminaire with higher protection rating with maximum efficiency, service life and flexibility

Product types

Monsun® 11 | 1590mm | 70,000h at 35°C

Monsun® 11 | 1590mm | 100,000h at 25°C

Monsun® 11 Xtreme | 1590mm | 70,000h at up to 60°C

Monsun® 11 Emergency | 1590mm

Monsun® 11 Parking | 1590mm

Monsun® 11 Facade | 1590mm

Monsun® 11 | 1590mm - for livestock farming

mounting rail for Monsun® 11/21 | 1590mm

Monsun® 11 | 1590mm - for livestock farming

Intro product family

Key data

Article damp-proof luminaire
Lighting effect direct symmetric medium distribution; direct symmetric wide distribution
Net luminous flux 3970lm to 8070lm
Colour temperature 4000K
Control ON/OFF; ON/OFF Multilumen; ON/OFF, CLOi
Cover PMMA
Protection rating IP66
Insulation class insulation class I (protective earthing)
Protection symbol D
Impact resistance IK04
Halogen freeness internal wiring halogen-free
IFS corresponds to IFS (International Featured Standards) requirements for safety and quality in the food industry

Special features

The requirements regarding ammonia resistance, cleaning distance and freedom from flicker for issuing the DLG Approved mark are met
Multilumen technology with luminous fluxes up to 12,000lm for maximum adaptability

Configuration & data sheets

Beam angle

Rated luminous flux (lm)

Control

  • includes ceiling fixing element and chain hanger of V2A; surface-mounting to ceilings without further luminaire-specific mounting accessories; for further installation methods: please order mounting accessory separately
  • for chain suspension: please order chain separately
  • for wall mounting: please order anti-theft/wall mounting protection separately
  • for further installation methods: please order mounting accessory separately
  • for greater anti-theft safety for all types of installation: if required, please order anti-theft/wall mounting protection separately
  • Some luminaires with through-wiring as standard; for other luminaires: please order through-wiring separately if required

Results

Monsun® 11, wide distribution, ON/OFF, PMMA

Order No.: 51FP107P430H GTIN (EAN): 4058352391365
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControltaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 803970lm22W179lm/WON/OFF-35..+40°CIK0415902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11, wide distribution, ON/OFF, PMMA

Order No.: 51FP107P460H GTIN (EAN): 4058352377048
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControltaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 805800lm33W178lm/WON/OFF-35..+40°CIK0415902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11, wide distribution, ON/OFF, PMMA

Order No.: 51FP108P430H GTIN (EAN): 4058352391396
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControltaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 803970lm22W179lm/WON/OFF-35..+40°CIK0415902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11, wide distribution, ON/OFF, PMMA

Order No.: 51FP108P460H GTIN (EAN): 4058352389713
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControltaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 806100lm34W180lm/WON/OFF-35..+40°CIK0415902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11, wide distribution, ON/OFF, CLOi, PMMA

Order No.: 51FP109P440H GTIN (EAN): 4058352392904
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControltaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 804120lm 180lm/WON/OFF, CLOi-35..+40°CIK0415902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11, wide distribution, ON/OFF, CLOi, PMMA

Order No.: 51FP109P460H GTIN (EAN): 4058352376300
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControltaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 806100lm 179lm/WON/OFF, CLOi-35..+40°CIK0415902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11, wide distribution, ON/OFF Multilumen, PMMA

Order No.: 51FP10MP480H GTIN (EAN): 4058352389737
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControltaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 808070lm45W178lm/WON/OFF Multilumen-35..+40°CIK0415902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11, medium distribution, ON/OFF Multilumen, PMMA

Order No.: 51FP12MP480H GTIN (EAN): 4058352376461
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControltaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 807990lm45W176lm/WON/OFF Multilumen-35..+40°CIK0415902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11, wide distribution, ON/OFF, PMMA

Order No.: 51FP107P430HGTIN (EAN): 4058352391365

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux3970lm
Connected load22W
Luminous efficacy179lm/W
ControlON/OFF
ta-35..+40°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11, wide distribution, ON/OFF, PMMA

Order No.: 51FP107P460HGTIN (EAN): 4058352377048

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux5800lm
Connected load33W
Luminous efficacy178lm/W
ControlON/OFF
ta-35..+40°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11, wide distribution, ON/OFF, PMMA

Order No.: 51FP108P430HGTIN (EAN): 4058352391396

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux3970lm
Connected load22W
Luminous efficacy179lm/W
ControlON/OFF
ta-35..+40°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11, wide distribution, ON/OFF, PMMA

Order No.: 51FP108P460HGTIN (EAN): 4058352389713

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux6100lm
Connected load34W
Luminous efficacy180lm/W
ControlON/OFF
ta-35..+40°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11, wide distribution, ON/OFF, CLOi, PMMA

Order No.: 51FP109P440HGTIN (EAN): 4058352392904

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux4120lm
Connected load
Luminous efficacy180lm/W
ControlON/OFF, CLOi
ta-35..+40°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11, wide distribution, ON/OFF, CLOi, PMMA

Order No.: 51FP109P460HGTIN (EAN): 4058352376300

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux6100lm
Connected load
Luminous efficacy179lm/W
ControlON/OFF, CLOi
ta-35..+40°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11, wide distribution, ON/OFF Multilumen, PMMA

Order No.: 51FP10MP480HGTIN (EAN): 4058352389737

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux8070lm
Connected load45W
Luminous efficacy178lm/W
ControlON/OFF Multilumen
ta-35..+40°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11, medium distribution, ON/OFF Multilumen, PMMA

Order No.: 51FP12MP480HGTIN (EAN): 4058352376461

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux7990lm
Connected load45W
Luminous efficacy176lm/W
ControlON/OFF Multilumen
ta-35..+40°C
Impact resistanceIK04
L (mm)1590
Wt. (kg)2.5
Show all details

Optional accessories

Articlethrough-wiring, 3-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.1Order No.: 58FV003GTIN (EAN): 4058352409473Show all details
Articlethrough-wiring, 5-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.1Order No.: 58FV005GTIN (EAN): 4058352409503Show all details
Articlethrough-wiring, 7-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.3Order No.: 58FV007GTIN (EAN): 4058352409510Show all details
Articlethrough-wiring, 5-core, 2.5mm², L= 1.7m, with terminal, for continuous trunkingPU1 pc.Wt. (kg)0.2Order No.: 58FV009GTIN (EAN): 4058352409534Show all details
Articletwin cable gland, M25, rubber, for cables, Ø 8.4..12mmPU1 pc.Wt. (kg)0.1Order No.: 58FV00DGTIN (EAN): 4058352409558Show all details
Articlecable gland with climate membrane, M20, PA / EPDM / ePTFE / silicone, for cables, Ø 6..13mmPU1 pc.Wt. (kg)0.1Order No.: 58FT003GTIN (EAN): 4058352410332Show all details
Articlecable gland, M25, PA / silicone, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT004GTIN (EAN): 4058352410356Show all details
Articlecable gland with climate membrane, M25, PA / EPDM / ePTFE / silicone, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT005GTIN (EAN): 4058352410370Show all details
Articlelink chain, steel, galvanisedPUrun. m.Wt. (kg)0.1Order No.: 5LY9001GTIN (EAN): 4039806184290Show all details
Articlelink chain, stainless steel (V2A)PUrun. m.Wt. (kg)0.1Order No.: 5LY9002GTIN (EAN): 4039806184313Show all details
Articlequick-release link, stainless steel (V2A)PU1 pc.Wt. (kg)0.1Order No.: 5LY9004GTIN (EAN): 4039806184368Show all details
Articlewall fastening, inclinablePU2 pcs.Wt. (kg)0.2Order No.: 58FM002GTIN (EAN): 4058352410257Show all details
Articlepipe clip fixing, for pipe diameter 1.5"PU2 pcs.Wt. (kg)0.2Order No.: 58FM003GTIN (EAN): 4058352426500Show all details
Articlepipe clip fixing, for pipe diameter 2"PU2 pcs.Wt. (kg)0.2Order No.: 58FM004GTIN (EAN): 4058352426524Show all details
Articlewall fastening, horizontal mounting, vertical mountingPU2 pcs.Wt. (kg)0.1Order No.: 58FM007GTIN (EAN): 4058352410295Show all details
Articlefixing reinforcementPU2 pcs.Wt. (kg)0.1Order No.: 58FM006GTIN (EAN): 4058352410271Show all details
Articlecable infeed, M20, rubber, for cables, Ø 6..13mmPU1 pc.Wt. (kg)0.1Order No.: 59FT001GTIN (EAN): 4058352410394Show all details
Articlecable infeed, M25, rubber, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT002GTIN (EAN): 4058352410318Show all details
Articleenclosure, PMMA, L= 1590mmPU1 pc.Wt. (kg)0.5Order No.: 59FW001GTIN (EAN): 4058352409572Show all details
