Monsun® 21

Product typesConfiguration & data sheets

Reliable, robust and with sensors that can be retrofitted for flexible control: That is Monsun® 21. The moisture-proof luminaire is prepared for use in exposed outdoor areas and in harsh environments such as in industry and multi-storey car parks. Thanks to excellent glare limitation, Monsun® 21 is also an optimal lighting solution for industrial and manual work.

Our core portfolio: Monsun® 21 is our luminaire with higher protection rating with the highest standards of efficiency, quality and flexibility for your project

Product types

Monsun® 21 | 50,000h at 25°C

Monsun® 21 Emergency

Monsun® 21 Parking

mounting rail for Monsun® 11/21 | 1590mm

Monsun® 21 Parking

Intro product family

Key data

Article damp-proof luminaire
Lighting effect direct symmetric wide distribution
Net luminous flux 3850lm to 5180lm
Colour temperature 4000K
Control ON/OFF; DALI 2
Cover PC
Protection rating IP66
Insulation class insulation class I (protective earthing)
Protection symbol D
Impact resistance IK08
Halogen freeness internal wiring halogen-free
IFS corresponds to IFS (International Featured Standards) requirements for safety and quality in the food industry

Special features

Multilumen technology with luminous fluxes up to 12,000lm for maximum adaptability
Very robust with IP66 protection rating and suitable for outdoor use
in ambient temperatures up to 50°C
Simple maintenance and easy upgrading of sensors due to tool-free opening of the luminaire
CLOi also with On/Off models for standard-compliant lighting over the complete service life without over-planning and for optimised energy consumption

Configuration & data sheets

Rated luminous flux (lm)

Control

Type of input

Through-wiring

Operating ambient temperature

Length (mm)

  • Some luminaires with through-wiring as standard; for other luminaires: please order through-wiring separately if required
  • supplementary through-wiring suitable for luminaire length 1590mm (form loop for luminaire length 1299mm)
  • includes ceiling fixing element and chain hanger of V2A; surface-mounting to ceilings without further luminaire-specific mounting accessories; for further installation methods: please order mounting accessory separately
  • for chain suspension: please order chain separately
  • for wall mounting: please order anti-theft/wall mounting protection separately
  • for further installation methods: please order mounting accessory separately
  • for greater anti-theft safety for all types of installation: if required, please order anti-theft/wall mounting protection separately

Results

Monsun® 21 parking, wide distribution, DALI 2, PC

Order No.: 51FG20DL430K GTIN (EAN): 4069025131805
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 803850lm24W160lm/WDALI 2 -25..+35°CIK0812992.1
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 21 parking, wide distribution, ON/OFF, PC

Order No.: 51FG207L430K GTIN (EAN): 4069025131782
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 803930lm25W159lm/WON/OFF -25..+35°CIK0812992.1
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 21 parking, wide distribution, ON/OFF, PC

Order No.: 51FG207P440C GTIN (EAN): 4069025178589
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 805180lm32W160lm/WON/OFF -25..+35°CIK0815902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 11 parking, wide distribution, ON/OFF, PC

Order No.: 51FG207P440L GTIN (EAN): 4069025280251
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 805010lm30W168lm/WON/OFF -35..+45°CIK0815902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 21 parking, wide distribution, DALI 2, PC

Order No.: 51FG20DP440C GTIN (EAN): 4069025178602
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 804810lm29W166lm/WDALI 2 -25..+35°CIK0815902.5
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 21 parking, wide distribution, DALI 2, PC

Order No.: 51FG20DP440C007 GTIN (EAN): 4069025178626
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 804810lm29W166lm/WDALI 27x 2.5mm²-25..+35°CIK0815902.8
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 21 parking, wide distribution, DALI 2, PC

Order No.: 51FG20DP440CHQ GTIN (EAN): 4069025178640
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 804810lm29W166lm/WDALI 2 -25..+35°CIK0815902.7
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 21 parking, wide distribution, DALI 2, PC

Order No.: 51FG20DP440CHR GTIN (EAN): 4069025178664
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlThrough-wiringtaImpact resistanceL (mm)Wt. (kg)
4000KCRI > 804810lm29W166lm/WDALI 2 -25..+35°CIK0815902.7
Show all details
Tender textData sheet (PDF, full)Photometric report / planning dataComplete download list

Monsun® 21 parking, wide distribution, DALI 2, PC

Order No.: 51FG20DL430KGTIN (EAN): 4069025131805

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux3850lm
Connected load24W
Luminous efficacy160lm/W
ControlDALI 2
Through-wiring
ta-25..+35°C
Impact resistanceIK08
L (mm)1299
Wt. (kg)2.1
Show all details

Monsun® 21 parking, wide distribution, ON/OFF, PC

Order No.: 51FG207L430KGTIN (EAN): 4069025131782

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux3930lm
Connected load25W
Luminous efficacy159lm/W
ControlON/OFF
Through-wiring
ta-25..+35°C
Impact resistanceIK08
L (mm)1299
Wt. (kg)2.1
Show all details

Monsun® 21 parking, wide distribution, ON/OFF, PC

Order No.: 51FG207P440CGTIN (EAN): 4069025178589

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux5180lm
Connected load32W
Luminous efficacy160lm/W
ControlON/OFF
Through-wiring
ta-25..+35°C
Impact resistanceIK08
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 11 parking, wide distribution, ON/OFF, PC

Order No.: 51FG207P440LGTIN (EAN): 4069025280251

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux5010lm
Connected load30W
Luminous efficacy168lm/W
ControlON/OFF
Through-wiring
ta-35..+45°C
Impact resistanceIK08
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 21 parking, wide distribution, DALI 2, PC

Order No.: 51FG20DP440CGTIN (EAN): 4069025178602

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux4810lm
Connected load29W
Luminous efficacy166lm/W
ControlDALI 2
Through-wiring
ta-25..+35°C
Impact resistanceIK08
L (mm)1590
Wt. (kg)2.5
Show all details

Monsun® 21 parking, wide distribution, DALI 2, PC

Order No.: 51FG20DP440C007GTIN (EAN): 4069025178626

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux4810lm
Connected load29W
Luminous efficacy166lm/W
ControlDALI 2
Through-wiring7x 2.5mm²
ta-25..+35°C
Impact resistanceIK08
L (mm)1590
Wt. (kg)2.8
Show all details

Monsun® 21 parking, wide distribution, DALI 2, PC

Order No.: 51FG20DP440CHQGTIN (EAN): 4069025178640

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux4810lm
Connected load29W
Luminous efficacy166lm/W
ControlDALI 2
Through-wiring
ta-25..+35°C
Impact resistanceIK08
L (mm)1590
Wt. (kg)2.7
Show all details

Monsun® 21 parking, wide distribution, DALI 2, PC

Order No.: 51FG20DP440CHRGTIN (EAN): 4069025178664

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux4810lm
Connected load29W
Luminous efficacy166lm/W
ControlDALI 2
Through-wiring
ta-25..+35°C
Impact resistanceIK08
L (mm)1590
Wt. (kg)2.7
Show all details

Optional accessories

Articlethrough-wiring, 3-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.1Order No.: 58FV003GTIN (EAN): 4058352409473Show all details
Articlethrough-wiring, 5-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.1Order No.: 58FV005GTIN (EAN): 4058352409503Show all details
Articlethrough-wiring, 7-core, 2.5mm², L= 1.4m, with terminal, for interrupted trunkingPU1 pc.Wt. (kg)0.3Order No.: 58FV007GTIN (EAN): 4058352409510Show all details
Articlethrough-wiring, 5-core, 2.5mm², L= 1.7m, with terminal, for continuous trunkingPU1 pc.Wt. (kg)0.2Order No.: 58FV009GTIN (EAN): 4058352409534Show all details
Articletwin cable gland, M25, rubber, for cables, Ø 8.4..12mmPU1 pc.Wt. (kg)0.1Order No.: 58FV00DGTIN (EAN): 4058352409558Show all details
Articlecable gland with climate membrane, M20, PA / EPDM / ePTFE / silicone, for cables, Ø 6..13mmPU1 pc.Wt. (kg)0.1Order No.: 58FT003GTIN (EAN): 4058352410332Show all details
Articlecable gland, M25, PA / silicone, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT004GTIN (EAN): 4058352410356Show all details
Articlecable gland with climate membrane, M25, PA / EPDM / ePTFE / silicone, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT005GTIN (EAN): 4058352410370Show all details
Articlelink chain, steel, galvanisedPUrun. m.Wt. (kg)0.1Order No.: 5LY9001GTIN (EAN): 4039806184290Show all details
Articlelink chain, stainless steel (V2A)PUrun. m.Wt. (kg)0.1Order No.: 5LY9002GTIN (EAN): 4039806184313Show all details
Articlequick-release link, stainless steel (V2A)PU1 pc.Wt. (kg)0.1Order No.: 5LY9004GTIN (EAN): 4039806184368Show all details
Articlewall fastening, inclinablePU2 pcs.Wt. (kg)0.2Order No.: 58FM002GTIN (EAN): 4058352410257Show all details
Articleceiling mountingPU2 pcs.Wt. (kg)0.1Order No.: 58FM012GTIN (EAN): 4069025193957Show all details
Articlepipe clip fixing, for pipe diameter 1.5"PU2 pcs.Wt. (kg)0.2Order No.: 58FM003GTIN (EAN): 4058352426500Show all details
Articlepipe clip fixing, for pipe diameter 2"PU2 pcs.Wt. (kg)0.2Order No.: 58FM004GTIN (EAN): 4058352426524Show all details
Articlewall fastening, horizontal mounting, vertical mountingPU2 pcs.Wt. (kg)0.1Order No.: 58FM007GTIN (EAN): 4058352410295Show all details
Articlefixing reinforcementPU2 pcs.Wt. (kg)0.1Order No.: 58FM006GTIN (EAN): 4058352410271Show all details
Articlespring clip, surface-mounted to the Licross® mounting railPU2 pcs.Wt. (kg)0.1Order No.: 58FM001GTIN (EAN): 4058352410233Show all details
Articlespring clip, surface-mounted to the DUS® mounting railPU2 pcs.Wt. (kg)0.1Order No.: 58FM008GTIN (EAN): 4058352426548Show all details
Articlecable infeed, M20, rubber, for cables, Ø 6..13mmPU1 pc.Wt. (kg)0.1Order No.: 59FT001GTIN (EAN): 4058352410394Show all details
Articlecable infeed, M25, rubber, for cables, Ø 9..17mmPU1 pc.Wt. (kg)0.1Order No.: 58FT002GTIN (EAN): 4058352410318Show all details
Articlemounting rail, for suspended mounting, surface-mounted, L= 1590mmPU1 pc.Wt. (kg)1.7Order No.: 58FS001GTIN (EAN): 4058352474945Show all details
Articlemounting rail, for suspended mounting, surface-mounted, L= 3180mmPU1 pc.Wt. (kg)3.5Order No.: 58FS002GTIN (EAN): 4058352474976Show all details
Articlemounting rail, for suspended mounting, surface-mounted, L= 4770mmPU1 pc.Wt. (kg)5.2Order No.: 58FS003GTIN (EAN): 4058352475799Show all details
Articleconnector, steel, galvanisedPU1 pc.Wt. (kg)0.3Order No.: 58FS005GTIN (EAN): 4058352477052Show all details
Articlecable holder, for supplementary wiring in the trunking railPU10 pcs.Wt. (kg)0.1Order No.: 59TR1HGTIN (EAN): 4058352476222Show all details
Articleend cap for rail, white, for IP20 protection ratingPU2 pcs.Wt. (kg)0.1Order No.: 59TL1SGTIN (EAN): 4058352272589Show all details
Articleblank cover, white, for IP20/IP40 protection ratingPU1 pc.Wt. (kg)0.2Order No.: 58FS006GTIN (EAN): 4058352466605Show all details
