Silica® 21
The Silica® 21 offers maximum flexibility in use and is suitable for all mounting situations thanks to its modular design. It is the ideal basis for a smart office through flexible expansion with intelligent sensors, for example for room data acquisition with an open interface. As a sustainable luminaire thanks to easily exchangeable components, the Silica® 21 is the perfect solution for individual projects thanks to the modular principle.
Our open solution: modular, networked, adaptable and open in design
with opal cover
Intro product family
Key data
Article office luminaire
Light emission direct distribution
Beam angle extremely wide distribution
Net luminous flux 1200lm to 7200lm
Colour temperature 2700…6500K; 3000K; 4000K
Control DALI DT8; DALI 2
Protection rating IP20
Insulation class insulation class I (protective earthing)
Special features
Opal diffuse cover with pleasant glare limitation for very large luminaire spacing - for very large areas to be illuminated
High design freedom thanks to a variety of lengths, colours and optics
Configuration & data sheets
- incl. quick-fit mounting brackets; mounting into system ceilings or recessing into cut ceiling apertures possible without luminaire-specific mounting accessories
- for continuous row: please order the required number of luminaire connectors separately; wiring from luminaire to luminaire on site in the ceiling void
Results
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DA32WB GTIN (EAN): 4058352898468
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 2400lm | 16.1W | 149lm/W | DALI 2 | 1228 | 3.2 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 840, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DA42WB GTIN (EAN): 4058352898482
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 2400lm | 15.2W | 158lm/W | DALI 2 | 1228 | 3.2 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DB32WB GTIN (EAN): 4058352907047
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 3000lm | 20.2W | 149lm/W | DALI 2 | 1528 | 3.8 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 840, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DB42WB GTIN (EAN): 4058352907061
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 3000lm | 19W | 158lm/W | DALI 2 | 1528 | 3.8 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DC35WB GTIN (EAN): 4058352907085
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 6000lm | 42.6W | 141lm/W | DALI 2 | 3028 | 6.0 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 840, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DC45WB GTIN (EAN): 4058352907108
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 6000lm | 40.1W | 150lm/W | DALI 2 | 3028 | 6.0 |
Silica® 21, extremely wide distribution, cover, opal, 2700..6500K, UGR ≤ 22, DALI DT8, traffic white (RAL 9016)
Order No.: 51MX10TAT2W GTIN (EAN): 4058352753408
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 2700..6500K | CRI > 80 | 2400lm | 21.5W | 112lm/W | DALI DT8 | 1228 | 3.2 |
Silica® 21, extremely wide distribution, cover, opal, 2700..6500K, UGR ≤ 22, DALI DT8, traffic white (RAL 9016)
Order No.: 51MX10TBT2W GTIN (EAN): 4058352754696
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 2700..6500K | CRI > 80 | 3000lm | 26.9W | 112lm/W | DALI DT8 | 1504 | 3.8 |
Silica® 21, extremely wide distribution, cover, opal, 2700..6500K, UGR ≤ 22, DALI DT8, traffic white (RAL 9016)
Order No.: 51MX10TCT5W GTIN (EAN): 4058352808924
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 2700..6500K | CRI > 80 | 6000lm | 53.8W | 112lm/W | DALI DT8 | 3028 | 6.0 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DH31WB GTIN (EAN): 4069025254696
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 1200lm | 9.7W | 124lm/W | DALI 2 | 628 | 2.4 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DJ31WB GTIN (EAN): 4069025204103
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 1800lm | 13.5W | 133lm/W | DALI 2 | 900 | 2.7 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DK33WB GTIN (EAN): 4058352033708
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 3600lm | 24.7W | 146lm/W | DALI 2 | 1800 | 4.5 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DL34WB GTIN (EAN): 4069025000026
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 4200lm | 31.6W | 133lm/W | DALI 2 | 2100 | 4.8 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DP36WB GTIN (EAN): 4069025129956
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 6600lm | 45.2W | 146lm/W | DALI 2 | 3300 | 6.5 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DR37WB GTIN (EAN): 4069025174536
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 7200lm | 49.1W | 147lm/W | DALI 2 | 3628 | 7.0 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DA32WBGTIN (EAN): 4058352898468
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 2400lm |
| Connected load | 16.1W |
| Luminous efficacy | 149lm/W |
| Control | DALI 2 |
| L (mm) | 1228 |
| Wt. (kg) | 3.2 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 840, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DA42WBGTIN (EAN): 4058352898482
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 2400lm |
| Connected load | 15.2W |
| Luminous efficacy | 158lm/W |
| Control | DALI 2 |
| L (mm) | 1228 |
| Wt. (kg) | 3.2 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DB32WBGTIN (EAN): 4058352907047
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 3000lm |
| Connected load | 20.2W |
| Luminous efficacy | 149lm/W |
| Control | DALI 2 |
| L (mm) | 1528 |
| Wt. (kg) | 3.8 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 840, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DB42WBGTIN (EAN): 4058352907061
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 3000lm |
| Connected load | 19W |
| Luminous efficacy | 158lm/W |
| Control | DALI 2 |
| L (mm) | 1528 |
| Wt. (kg) | 3.8 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DC35WBGTIN (EAN): 4058352907085
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 6000lm |
| Connected load | 42.6W |
| Luminous efficacy | 141lm/W |
| Control | DALI 2 |
| L (mm) | 3028 |
| Wt. (kg) | 6.0 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 840, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DC45WBGTIN (EAN): 4058352907108
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 6000lm |
| Connected load | 40.1W |
| Luminous efficacy | 150lm/W |
| Control | DALI 2 |
| L (mm) | 3028 |
| Wt. (kg) | 6.0 |
Silica® 21, extremely wide distribution, cover, opal, 2700..6500K, UGR ≤ 22, DALI DT8, traffic white (RAL 9016)
Order No.: 51MX10TAT2WGTIN (EAN): 4058352753408
| Colour temperature | 2700..6500K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 2400lm |
| Connected load | 21.5W |
| Luminous efficacy | 112lm/W |
| Control | DALI DT8 |
| L (mm) | 1228 |
| Wt. (kg) | 3.2 |
Silica® 21, extremely wide distribution, cover, opal, 2700..6500K, UGR ≤ 22, DALI DT8, traffic white (RAL 9016)
Order No.: 51MX10TBT2WGTIN (EAN): 4058352754696
| Colour temperature | 2700..6500K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 3000lm |
| Connected load | 26.9W |
| Luminous efficacy | 112lm/W |
| Control | DALI DT8 |
| L (mm) | 1504 |
| Wt. (kg) | 3.8 |
Silica® 21, extremely wide distribution, cover, opal, 2700..6500K, UGR ≤ 22, DALI DT8, traffic white (RAL 9016)
Order No.: 51MX10TCT5WGTIN (EAN): 4058352808924
| Colour temperature | 2700..6500K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 6000lm |
| Connected load | 53.8W |
| Luminous efficacy | 112lm/W |
| Control | DALI DT8 |
| L (mm) | 3028 |
| Wt. (kg) | 6.0 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DH31WBGTIN (EAN): 4069025254696
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 1200lm |
| Connected load | 9.7W |
| Luminous efficacy | 124lm/W |
| Control | DALI 2 |
| L (mm) | 628 |
| Wt. (kg) | 2.4 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DJ31WBGTIN (EAN): 4069025204103
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 1800lm |
| Connected load | 13.5W |
| Luminous efficacy | 133lm/W |
| Control | DALI 2 |
| L (mm) | 900 |
| Wt. (kg) | 2.7 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DK33WBGTIN (EAN): 4058352033708
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 3600lm |
| Connected load | 24.7W |
| Luminous efficacy | 146lm/W |
| Control | DALI 2 |
| L (mm) | 1800 |
| Wt. (kg) | 4.5 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DL34WBGTIN (EAN): 4069025000026
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 4200lm |
| Connected load | 31.6W |
| Luminous efficacy | 133lm/W |
| Control | DALI 2 |
| L (mm) | 2100 |
| Wt. (kg) | 4.8 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DP36WBGTIN (EAN): 4069025129956
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 6600lm |
| Connected load | 45.2W |
| Luminous efficacy | 146lm/W |
| Control | DALI 2 |
| L (mm) | 3300 |
| Wt. (kg) | 6.5 |
Silica® 21, extremely wide distribution, cover, opal, Light colour 830, UGR ≤ 22, DALI 2, traffic white (RAL 9016)
Order No.: 51MX10DR37WBGTIN (EAN): 4069025174536
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 7200lm |
| Connected load | 49.1W |
| Luminous efficacy | 147lm/W |
| Control | DALI 2 |
| L (mm) | 3628 |
| Wt. (kg) | 7.0 |
Optional accessories
| Order No.: 59MX700V50XGTIN (EAN): 4058352772416 | Show all details |
