Licross® Interface, master, switchable

Close
Ordercode: 56TL1FAMA
Remember productRemember product

Article base module
Product name Licross® Interface
Protection rating IP20
Weight 0.5kg

Licross®, Interface MS, master,local controlinstallation location: to the Licross® trunking rail, of sheet steel, protection rating (complete): IP20, insulation class (complete): insulation class I (protective earthing), certification: CE, VDE, voltage: 230V, voltage type: AC, 1 x 1 x light control, packaging unit: 1 piece

Downloads

Technical product information
Data for application programs

Product details

Key data

Product type base module
Product name Licross® Interface
Order No. 56TL1FAMA

Lamps

Supplement halogen-free wiring

Operating device

Control ON/OFF

Certificates, Standards

Protection rating IP20
Insulation class insulation class I (protective earthing)
Temperature range (operation) -20..+50°C
Certification, designation CE, VDE

Material, Colour

trunking rail adapter set sheet steel, coil coated, white
Colour specification white

Mounting

Supplement for mounting in indoor and outdoor areas

Electrical connection

Connection plug, 4-pole, without phase selection
Nominal voltage 230V, 50Hz, AC

Dimensions, Weight

Length 500mm
Width 96mm
Height 97mm
Weight 0.5kg

Inputs

1x light control
Connection light sensor

Product type
base module

Product name
Licross® Interface

Order No.
56TL1FAMA

Supplement
halogen-free wiring

Control
ON/OFF

Protection rating
IP20

Insulation class
insulation class I (protective earthing)

Temperature range (operation)
-20..+50°C

Certification, designation
CE, VDE

trunking rail adapter set
sheet steel, coil coated, white

Colour specification
white

Supplement
for mounting in indoor and outdoor areas

Connection
plug, 4-pole, without phase selection

Nominal voltage
230V, 50Hz, AC

Length
500mm

Width
96mm

Height
97mm

Weight
0.5kg

1x light control

Connection
light sensor
