Article lighting management components
Product name SITECO Connect Wireless
Protection rating IP20
Weight 0.2kg

SITECO Connect Wireless, controller, master,local controlinstallation type: lay-in mounting, installation location: in the ceiling, protection rating (complete): IP20, insulation class (complete): insulation class II (safety insulation), certification: CE, voltage: 230V, 1 x DALI, 1 x Bluetooth® interface, 1 x switching contact, packaging unit: 1 piece

Product details


Key data

System family SITECO Connect Wireless
Product type lighting management components
Product name SITECO Connect Wireless
Order No. 5LZ980301


Control


Certificates, Standards

Protection rating IP20
Insulation class insulation class II (safety insulation)
Temperature range (operation) -20..+40°C
Certification, designation CE


Mounting

Mounting method, mounting location lay-in mounting, in the ceiling
Supplement only suitable for indoor use


Electrical connection

Nominal voltage 230V


Dimensions, Weight

Weight 0.2kg


Outputs

1x DALI
Limiting maximum 2x ECG DALI or 2x ECG DALI DT8 and 1 sensor PS3 DALI2 controllable

1x Bluetooth® interface
Feature operating frequency 2.4..2.483GHz, +4dBm

1x switching contact
Feature number of ECG's depends of the ECG type

System family
SITECO Connect Wireless

Product type
lighting management components

Product name
SITECO Connect Wireless

Order No.
5LZ980301

Protection rating
IP20

Insulation class
insulation class II (safety insulation)

Temperature range (operation)
-20..+40°C

Certification, designation
CE

Mounting method, mounting location
lay-in mounting, in the ceiling

Supplement
only suitable for indoor use

Nominal voltage
230V

Weight
0.2kg

1x DALI

Limiting
maximum 2x ECG DALI or 2x ECG DALI DT8 and 1 sensor PS3 DALI2 controllable

1x Bluetooth® interface

Feature
operating frequency 2.4..2.483GHz, +4dBm

1x switching contact

Feature
number of ECG's depends of the ECG type
