Article amplifier
Product name SITECO Connect Audio
Rated input power 120W
Weight 3.6kg

SITECO Connect Audio, amplifier, installation type: for table mounting, desktop mixer power amplifier,mains connection: 100..240V, AC, 50/60Hz, rated input power: 120W, housing, of metal/plastic, coated, black, length: 375 mm, width: 210 mm, height: 53mm, certification: CE, packaging unit: 1 piece

Downloads

Technical product information
Data for application programs

Product details


Key data

System family Licross®
Product type amplifier
Product name SITECO Connect Audio
Order No. 59UA3VT


Rated input power


Supplement


Certificates, Standards

Certification, designation CE


Material, Colour

housing metal/plastic, coated, black
Colour specification black


Mounting

Mounting method, mounting location for table mounting


Electrical connection

Nominal voltage 100..240V, 50/60Hz, AC


Dimensions, Weight

Length 375mm
Width 210mm
Height 53mm
Weight 3.6kg


Inputs

MIC -60dBV, LINE -20dBV
Feature MIC/LINE selectable, 2.2kΩ, electronically balanced

MIC -60dBV, LINE -20dBV
Feature MIC/LINE selectable, 2.2kΩ, electronically balanced

LINE -20dBV, 10kΩ
Connection Cinch

LINE -20dBV, 10kΩ
Connection Cinch

System family
Licross®

Product type
amplifier

Product name
SITECO Connect Audio

Order No.
59UA3VT

Certification, designation
CE

housing
metal/plastic, coated, black

Colour specification
black

Mounting method, mounting location
for table mounting

Nominal voltage
100..240V, 50/60Hz, AC

Length
375mm

Width
210mm

Height
53mm

Weight
3.6kg

MIC -60dBV, LINE -20dBV

Feature
MIC/LINE selectable, 2.2kΩ, electronically balanced

MIC -60dBV, LINE -20dBV

Feature
MIC/LINE selectable, 2.2kΩ, electronically balanced

LINE -20dBV, 10kΩ

Connection
Cinch

LINE -20dBV, 10kΩ

Connection
Cinch
