SITECO Connect Sport, luminaire controller, Supply voltage 230V

Close
Order No.: 5XA769SCS5
Remember articleRemember article

Article luminaire controller
Product name SITECO Connect Sport
Rated input power 3W
Protection rating IP66
Weight 0.7kg

SITECO Connect Sportluminaire controller, local control - self-sufficient standalone sensors, configuration via Casambi app, dimmable, installation type: surface-mounted, installation location: to mast, of plastic, protection rating (complete): IP66, insulation class (complete): insulation class II (safety insulation), certification: CE, voltage: 230V, voltage type: AC, cable length: 1 m, ECG DALI, Bluetooth®, packaging unit: 1 piece

Downloads

Technical product information
Data for applications

Product details

Key data

Product type luminaire controller
Product name SITECO Connect Sport
Order No. 5XA769SCS5

Lamps

Rated input power 3W

Operating device

Control DALI, dimmable, configuration via Casambi app

Certificates, Standards

Protection rating IP66
Insulation class insulation class II (safety insulation)
Certification, designation CE

Material, Colour

housing plastic, black
Colour specification black

Mounting

Mounting method, mounting location surface-mounted, to mast

Electrical connection

Connection cable, 5x 0.75mm²
Nominal voltage 230V, 50/60Hz, AC

Dimensions, Weight

Weight 0.7kg

Outputs

ECG DALI
Feature for maximal four DALI ECGs

Bluetooth®
Range max. 100m in open field

Product type
luminaire controller

Product name
SITECO Connect Sport

Order No.
5XA769SCS5

Rated input power
3W

Control
DALI, dimmable, configuration via Casambi app

Protection rating
IP66

Insulation class
insulation class II (safety insulation)

Certification, designation
CE

housing
plastic, black

Colour specification
black

Mounting method, mounting location
surface-mounted, to mast

Connection
cable, 5x 0.75mm²

Nominal voltage
230V, 50/60Hz, AC

Weight
0.7kg

ECG DALI

Feature
for maximal four DALI ECGs

Bluetooth®

Range
max. 100m in open field
