Streetlight 11 iQ

ProducttypesConfiguration & Datasheets

Our performance solution: Streetlight SL 11 iQ is our innovative road luminaire with maximum efficiency, service life and flexibility

Streetlight 11 from SITECO – highly gifted light in its best form with new performance

Streetlight 11 micro

Intro to Productfamily

Data

Article mast luminaire
Net luminous flux 1560lm to 3860lm
Colour temperature 2200K; 3000K; 4000K
Lighting effect direct asymmetric wide distribution
Light distribution ST0.5a; ST1.2a; P1.0a
Protection rating IP66
Insulation class insulation class II (safety insulation)

Specials

Especially durable thanks to robust diecast aluminum housing (IP66/IK09) with optimum heat dissipation, ensuring more than 90% residual luminous flux after 100,000 hours of service life
Highly efficient LED technology up to 164lm/W with uniform and glare-free illumination thanks to HD faceted reflectors with a patented silver coating
Siteco iQ: Auto-Match: spare parts exchange with automatic data exchange without manual reading out and transmission of the data; Desk Remote: voltage-free transmission of data to the luminaire via NFC, even through the packaging; Smart Wire: activation of preset dimming values or dimming profiles and many other functions
Siteco iQ Street-Remote (iQ-SR): Transmission of all parameters without tools or cable connection via a stable Bluetooth connection
Smart Interface (Zhaga & D4i) for smart city applications with a simultaneous modular design for component upgrades
On request: Siteco iQ Colour-Switch (adaptation of the light colour) and Siteco iQ Light-Switch (adaptation of the light distribution), as well as individual luminous flux settings

Configuration & Datasheets

Light distribution

Colour temperature

Control

Smart City

  • please order mast flange according to spigot diameter separately
  • luminaire includes pre-assembled connection cable, l = 5.5m (low luminous flux levels), l = 6.5m (high luminous flux levels)
  • Setting the luminaire with Desk-Remote: with the SITECO iQ app on the SITECO iQ handheld (5EA6HBR01) or your own smart phone (RFID dongle 5EA6ABR01 is also required for transferring smartphone/luminaire)
  • Setting the luminaire with Street-Remote: with the SITECO iQ app on the SITECO iQ handheld (5EA6HBR01) or your own smart phone
  • SITECO offers the SITECO Connect Group Control (230V or 12/24V) product to use the Smart Wire function '10 levels'. A communication module is also available with which remote access is possible and radio clock functionality is provided.
  • please order Siteco® Service Box for configuring additionally if required
  • for smart interface luminaires, please order 'OSRAM DALI magic' or 'PRH 101 (NFC)' to transfer the configuration separately if required
  • DALI and Smart Interface luminaires currently still without iQ functionality

Results

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41E08CEGTIN (EAN): 4058352557259
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701960lmST1.2aiQ-Comfort131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41E08DEGTIN (EAN): 4058352557273
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703860lmST1.2aiQ-Comfort2626125.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41F08CEGTIN (EAN): 4058352557297
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701960lmST1.2aiQ Street-Remote131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41F08CEGTIN (EAN): 4058352557419
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701940lmST0.5aiQ Street-Remote131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C41F08CEGTIN (EAN): 4058352557556
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701660lmP1.0aiQ Street-Remote131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41F08DEGTIN (EAN): 4058352557327
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703860lmST1.2aiQ Street-Remote2626125.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41F08DEGTIN (EAN): 4058352557440
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703820lmST0.5aiQ Street-Remote2626125.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A42T08CEGTIN (EAN): 4058352561195
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701960lmST1.2aD4i141485.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A42T08DEGTIN (EAN): 4058352561201
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703860lmST1.2aD4i2727145.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A42Y08CEGTIN (EAN): 4058352561218
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701960lmST1.2aD4i with power reduction141485.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A42Y08DEGTIN (EAN): 4058352561225
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703860lmST1.2aD4i with power reduction2727145.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51E08CEGTIN (EAN): 4058352557334
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701880lmST1.2aiQ-Comfort131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51E08DEGTIN (EAN): 4058352557358
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703700lmST1.2aiQ-Comfort2626125.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51F08CEGTIN (EAN): 4058352557372
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701880lmST1.2aiQ Street-Remote131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51F08CEGTIN (EAN): 4058352557457
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701860lmST0.5aiQ Street-Remote131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C51F08CEGTIN (EAN): 4058352557587
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701600lmP1.0aiQ Street-Remote131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51F08DEGTIN (EAN): 4058352557396
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703700lmST1.2aiQ Street-Remote2626125.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51F08DEGTIN (EAN): 4058352557471
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703670lmST0.5aiQ Street-Remote2626125.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A52T08CEGTIN (EAN): 4058352561232
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701880lmST1.2aD4i141485.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A52T08DEGTIN (EAN): 4058352561249
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703700lmST1.2aD4i2727145.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A52Y08CEGTIN (EAN): 4058352561256
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701880lmST1.2aD4i with power reduction141485.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A52Y08DEGTIN (EAN): 4058352561263
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703700lmST1.2aD4i with power reduction2727145.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A31F08CEGTIN (EAN): 4058352554418
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 801620lmST1.2aiQ Street-Remote131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A31F08DEGTIN (EAN): 4058352561171
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 803190lmST1.2aiQ Street-Remote2626125.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A32Y08DEGTIN (EAN): 4058352561188
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 803190lmST1.2aD4i with power reduction2727145.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A21F08CEGTIN (EAN): 4058352557174
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 701560lmST1.2aiQ Street-Remote131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A21F08DEGTIN (EAN): 4058352557204
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 703070lmST1.2aiQ Street-Remote2626125.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A22Y08CEGTIN (EAN): 4058352561157
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 701560lmST1.2aD4i with power reduction141485.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A22Y08DEGTIN (EAN): 4058352561164
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 703070lmST1.2aD4i with power reduction2727145.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41E08CEGTIN (EAN): 4058352583333
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701940lmST0.5aiQ-Comfort131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C41E08CEGTIN (EAN): 4058352583425
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701660lmP1.0aiQ-Comfort131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41E08DEGTIN (EAN): 4058352583357
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703820lmST0.5aiQ-Comfort2626135.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C41E08DEGTIN (EAN): 4058352583432
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703280lmP1.0aiQ-Comfort2626125.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51E08CEGTIN (EAN): 4058352583371
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701860lmST0.5aiQ-Comfort131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C51E08CEGTIN (EAN): 4058352583456
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701600lmP1.0aiQ-Comfort131375.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51E08DEGTIN (EAN): 4058352583395
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703670lmST0.5aiQ-Comfort2626135.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C51E08DEGTIN (EAN): 4058352583470
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703150lmP1.0aiQ-Comfort2626125.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41E08CEGTIN (EAN): 4058352557259

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1960lm
Light distributionST1.2a
ControliQ-Comfort
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41E08DEGTIN (EAN): 4058352557273

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3860lm
Light distributionST1.2a
ControliQ-Comfort
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41F08CEGTIN (EAN): 4058352557297

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1960lm
Light distributionST1.2a
ControliQ Street-Remote
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41F08CEGTIN (EAN): 4058352557419

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1940lm
Light distributionST0.5a
ControliQ Street-Remote
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C41F08CEGTIN (EAN): 4058352557556

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1660lm
Light distributionP1.0a
ControliQ Street-Remote
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41F08DEGTIN (EAN): 4058352557327

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3860lm
Light distributionST1.2a
ControliQ Street-Remote
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41F08DEGTIN (EAN): 4058352557440

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3820lm
Light distributionST0.5a
ControliQ Street-Remote
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A42T08CEGTIN (EAN): 4058352561195

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1960lm
Light distributionST1.2a
ControlD4i
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux8
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A42T08DEGTIN (EAN): 4058352561201

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3860lm
Light distributionST1.2a
ControlD4i
Pnom begin service life27
Pnom end service life27
Pred at 50% lumin. flux14
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A42Y08CEGTIN (EAN): 4058352561218

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1960lm
Light distributionST1.2a
ControlD4i with power reduction
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux8
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A42Y08DEGTIN (EAN): 4058352561225

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3860lm
Light distributionST1.2a
ControlD4i with power reduction
Pnom begin service life27
Pnom end service life27
Pred at 50% lumin. flux14
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51E08CEGTIN (EAN): 4058352557334

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1880lm
Light distributionST1.2a
ControliQ-Comfort
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51E08DEGTIN (EAN): 4058352557358

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3700lm
Light distributionST1.2a
ControliQ-Comfort
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51F08CEGTIN (EAN): 4058352557372

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1880lm
Light distributionST1.2a
ControliQ Street-Remote
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51F08CEGTIN (EAN): 4058352557457

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1860lm
Light distributionST0.5a
ControliQ Street-Remote
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C51F08CEGTIN (EAN): 4058352557587

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1600lm
Light distributionP1.0a
ControliQ Street-Remote
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51F08DEGTIN (EAN): 4058352557396

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3700lm
Light distributionST1.2a
ControliQ Street-Remote
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51F08DEGTIN (EAN): 4058352557471

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3670lm
Light distributionST0.5a
ControliQ Street-Remote
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A52T08CEGTIN (EAN): 4058352561232

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1880lm
Light distributionST1.2a
ControlD4i
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux8
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A52T08DEGTIN (EAN): 4058352561249

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3700lm
Light distributionST1.2a
ControlD4i
Pnom begin service life27
Pnom end service life27
Pred at 50% lumin. flux14
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A52Y08CEGTIN (EAN): 4058352561256

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1880lm
Light distributionST1.2a
ControlD4i with power reduction
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux8
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A52Y08DEGTIN (EAN): 4058352561263

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3700lm
Light distributionST1.2a
ControlD4i with power reduction
Pnom begin service life27
Pnom end service life27
Pred at 50% lumin. flux14
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A31F08CEGTIN (EAN): 4058352554418

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux1620lm
Light distributionST1.2a
ControliQ Street-Remote
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A31F08DEGTIN (EAN): 4058352561171

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux3190lm
Light distributionST1.2a
ControliQ Street-Remote
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A32Y08DEGTIN (EAN): 4058352561188

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux3190lm
Light distributionST1.2a
ControlD4i with power reduction
Pnom begin service life27
Pnom end service life27
Pred at 50% lumin. flux14
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A21F08CEGTIN (EAN): 4058352557174

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux1560lm
Light distributionST1.2a
ControliQ Street-Remote
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A21F08DEGTIN (EAN): 4058352557204

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux3070lm
Light distributionST1.2a
ControliQ Street-Remote
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A22Y08CEGTIN (EAN): 4058352561157

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux1560lm
Light distributionST1.2a
ControlD4i with power reduction
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux8
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A22Y08DEGTIN (EAN): 4058352561164

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux3070lm
Light distributionST1.2a
ControlD4i with power reduction
Pnom begin service life27
Pnom end service life27
Pred at 50% lumin. flux14
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41E08CEGTIN (EAN): 4058352583333

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1940lm
Light distributionST0.5a
ControliQ-Comfort
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C41E08CEGTIN (EAN): 4058352583425

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1660lm
Light distributionP1.0a
ControliQ-Comfort
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41E08DEGTIN (EAN): 4058352583357

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3820lm
Light distributionST0.5a
ControliQ-Comfort
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux13
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C41E08DEGTIN (EAN): 4058352583432

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3280lm
Light distributionP1.0a
ControliQ-Comfort
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51E08CEGTIN (EAN): 4058352583371

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1860lm
Light distributionST0.5a
ControliQ-Comfort
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C51E08CEGTIN (EAN): 4058352583456

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1600lm
Light distributionP1.0a
ControliQ-Comfort
Pnom begin service life13
Pnom end service life13
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51E08DEGTIN (EAN): 4058352583395

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3670lm
Light distributionST0.5a
ControliQ-Comfort
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux13
Wt. (kg)5.2

Streetlight SL 11 micro, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C51E08DEGTIN (EAN): 4058352583470

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3150lm
Light distributionP1.0a
ControliQ-Comfort
Pnom begin service life26
Pnom end service life26
Pred at 50% lumin. flux12
Wt. (kg)5.2

Mandatory accessory

Articleadapter, spigot size: 60mm, spigot size: 76mm, inclination 15°PU1 pc.Wt. (kg)1.5Order No.: 5XC10000W12GTIN (EAN): 4058352637265Show details
Articlereducer, spigot size: 60/42mmPU1 pc.Wt. (kg)0.1Order No.: 5XC10000WR6GTIN (EAN): 4058352641125Show details
Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 42mmPU1 pc.Wt. (kg)0.5Order No.: 5XC10008XM4GTIN (EAN): 4058352147849Show details
Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 60mmPU1 pc.Wt. (kg)0.6Order No.: 5XC10008XM2GTIN (EAN): 4058352147825Show details
Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 76/60mmPU1 pc.Wt. (kg)0.7Order No.: 5XC10108XM1GTIN (EAN): 4058352460153Show details

Optional accessory

Articleshield, lateral shielding, shielding for glare limitation class G4PU2 pcs.Wt. (kg)0.2Order No.: 5XCBLE108G4GTIN (EAN): 4058352188439Show details
Articleshield, lateral shielding, shielding for glare limitation class G6PU2 pcs.Wt. (kg)0.1Order No.: 5XCBLE108G6GTIN (EAN): 4058352188453Show details
Articleshield, shielding on road and mast sidePU1 pc.Wt. (kg)0.1Order No.: 5XCBLE108BLGTIN (EAN): 4058352384213Show details
Articlecable set for mast, Plus version, L= 4mPU1 pc.Wt. (kg)0.8Order No.: 5EA6Y00L02GTIN (EAN): 4050737028804Show details
Articlecable set for mast, Plus version, L= 5mPU1 pc.Wt. (kg)0.9Order No.: 5EA6Y00L03GTIN (EAN): 4050737028828Show details
Articlecable set for mast, Plus version, L= 6mPU1 pc.Wt. (kg)1.1Order No.: 5EA6Y00L08GTIN (EAN): 4050737056098Show details
