spare parts Streetlight 10

ProducttypesConfiguration & Datasheets

Switch to the latest LED technology while leaving 80% of the existing luminaire on the mast - possible with the upgrade kit for Streetlight 10 luminaires. Significantly lower operating costs, a quick and uncomplicated conversion in accordance with legal requirements and the needs of flora and fauna even better in view - an upgrade is worthwhile for many reasons.
No matter whether it's an ECG replacement, an LED module replacement or both, the replacement works quickly and effortlessly: the LED replacement is possible without ESD protection, an ECG replacement is done in no time at all thanks to automatic data transfer.

Upgrade now and benefit from lower operating costs and well thought-out functions!

Producttypes

Streetlight 10 micro LED module

Streetlight 10 mini/midi LED module

Streetlight 10 ECG unit

Streetlight 10 micro LED module

Intro to Productfamily

Data

Article LED module
Lighting effect asymmetric wide distribution; asymmetric extremely wide distribution
Light distribution ST1.2a; P1.0a
Colour temperature 2700K; 2200K; 1800K; 3000K; 4000K; 5000K

Specials

Sustainable concept: the Streetlight 10 family consists of a high-quality aluminum housing and, thanks to its modular design, is prepared for quick and easy replacement of the components
Turn old into new: with the upgrade kit, around 80% of the luminaire remains on the mast and can be reused. Replacing the LED module and/or ECG is all it takes to bring your Streetlight 10 back to the state of the art
Upgrade yes, but how? Very uncomplicated! ECG exchange? LED module exchange? Both? No matter what you choose, the exchange is quick and easy. The LED module can be replaced without ESD protection, and you can also replace the ECG in no time at all, because all data is transferred automatically thanks to SITECO Auto-Match
Auto-Match: Replacing or refurbishing components for upgrades with automatic data transfer: With SITECO Auto-Match it's really easy, because ECG and LED board communicate with each other: As soon as a new element is added to the luminaire, it automatically receives all the necessary settings and information from the system. You don't have to do anything else! Save yourself the time and effort - and simply benefit from lower operating costs and well thought-out functions

Configuration & Datasheets

Light distribution

Colour temperature

For luminaire variants with order numbers 5XA58.7CN… or 5XA58.8CN… please contact your sales representative

Results

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0114K GTIN (EAN): 4050737848457
Colour temperatureColour renderingLight distributionWt. (kg)
4000KCRI > 70ST1.2a0.7
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric extremely wide distribution, P1.0a

Order No.: 5XMOD0114L GTIN (EAN): 4050737957180
Colour temperatureColour renderingLight distributionWt. (kg)
4000KCRI > 70P1.0a0.6
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0114A GTIN (EAN): 4050737848419
Colour temperatureColour renderingLight distributionWt. (kg)
5000KCRI > 70ST1.2a0.7
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0155K GTIN (EAN): 4058352780510
Colour temperatureColour renderingLight distributionWt. (kg)
3000KCRI > 70ST1.2a0.8
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric extremely wide distribution, P1.0a

Order No.: 5XMOD0114F GTIN (EAN): 4050737957166
Colour temperatureColour renderingLight distributionWt. (kg)
3000KCRI > 80P1.0a0.6
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0165K GTIN (EAN): 4058352780558
Colour temperatureColour renderingLight distributionWt. (kg)
2700KCRI > 70ST1.2a0.8
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric extremely wide distribution, P1.0a

Order No.: 5XMOD0165L GTIN (EAN): 4058352780572
Colour temperatureColour renderingLight distributionWt. (kg)
2700KCRI > 70P1.0a0.8
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0125K GTIN (EAN): 4058352780473
Colour temperatureColour renderingLight distributionWt. (kg)
2200KCRI > 70ST1.2a0.8
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric extremely wide distribution, P1.0a

Order No.: 5XMOD0125L GTIN (EAN): 4058352780497
Colour temperatureColour renderingLight distributionWt. (kg)
2200KCRI > 70P1.0a0.8
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0175K GTIN (EAN): 4058352780596
Colour temperatureColour renderingLight distributionWt. (kg)
1800KCRI > 70ST1.2a0.8
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric extremely wide distribution, P1.0a

Order No.: 5XMOD0175L GTIN (EAN): 4058352780619
Colour temperatureColour renderingLight distributionWt. (kg)
1800KCRI > 70P1.0a0.8
Show details
Tender textData sheet (PDF, full)All Downloads

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0114KGTIN (EAN): 4050737848457

Colour temperature4000K
Colour renderingCRI > 70
Light distributionST1.2a
Wt. (kg)0.7
Show details

Streetlight 10 micro, LED module, asymmetric extremely wide distribution, P1.0a

Order No.: 5XMOD0114LGTIN (EAN): 4050737957180

Colour temperature4000K
Colour renderingCRI > 70
Light distributionP1.0a
Wt. (kg)0.6
Show details

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0114AGTIN (EAN): 4050737848419

Colour temperature5000K
Colour renderingCRI > 70
Light distributionST1.2a
Wt. (kg)0.7
Show details

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0155KGTIN (EAN): 4058352780510

Colour temperature3000K
Colour renderingCRI > 70
Light distributionST1.2a
Wt. (kg)0.8
Show details

Streetlight 10 micro, LED module, asymmetric extremely wide distribution, P1.0a

Order No.: 5XMOD0114FGTIN (EAN): 4050737957166

Colour temperature3000K
Colour renderingCRI > 80
Light distributionP1.0a
Wt. (kg)0.6
Show details

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0165KGTIN (EAN): 4058352780558

Colour temperature2700K
Colour renderingCRI > 70
Light distributionST1.2a
Wt. (kg)0.8
Show details

Streetlight 10 micro, LED module, asymmetric extremely wide distribution, P1.0a

Order No.: 5XMOD0165LGTIN (EAN): 4058352780572

Colour temperature2700K
Colour renderingCRI > 70
Light distributionP1.0a
Wt. (kg)0.8
Show details

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0125KGTIN (EAN): 4058352780473

Colour temperature2200K
Colour renderingCRI > 70
Light distributionST1.2a
Wt. (kg)0.8
Show details

Streetlight 10 micro, LED module, asymmetric extremely wide distribution, P1.0a

Order No.: 5XMOD0125LGTIN (EAN): 4058352780497

Colour temperature2200K
Colour renderingCRI > 70
Light distributionP1.0a
Wt. (kg)0.8
Show details

Streetlight 10 micro, LED module, asymmetric wide distribution, ST1.2a

Order No.: 5XMOD0175KGTIN (EAN): 4058352780596

Colour temperature1800K
Colour renderingCRI > 70
Light distributionST1.2a
Wt. (kg)0.8
Show details

Streetlight 10 micro, LED module, asymmetric extremely wide distribution, P1.0a

Order No.: 5XMOD0175LGTIN (EAN): 4058352780619

Colour temperature1800K
Colour renderingCRI > 70
Light distributionP1.0a
Wt. (kg)0.8
Show details
