SITECO Connect Wireless Outdoor
SITECO Connect Wireless Outdoor is the powerful, proven and modular radio system for control and monitoring in outdoor areas. It includes radio controls and motion detectors that comply with the D4i and Zhaga Book 18 standards. This makes them the perfect complement to SITECO luminaires with a Smart Interface. The system enables the implementation of both local and self-sufficient networks, i.e. without cellular or internet connection, as well as lighting controls with remote access. A user-friendly software interface with many control and monitoring functions is available for this. The system has a modular structure and accompanies SITECO customers from a simple local installation to complex supraregional expansion stages.
Controlling and monitoring via radio
Product types
SITECO Connect Wireless Outdoor Smart Plug
SITECO Connect Wireless Outdoor motion sensors
SITECO Connect Wireless Outdoor environmental sensors
SITECO Connect Wireless Outdoor Mast Box
SITECO Connect Wireless Outdoor USB programming stick
SITECO Connect Wireless Outdoor Group Control
SITECO Connect Wireless Outdoor Smart Meter
SITECO Connect Wireless Outdoor Smart Plug Box
SITECO Connect Wireless Outdoor motion sensors
Intro product familyKey data
Article sensor
Special features
Configuration & data sheets
Results
Smart Plug Motion Low
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| PIR movement sensor | 0..6m | max. ø11m | 0.1 |
Smart Plug Motion High
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| PIR movement sensor | 6..12m | max. ø18m | 0.1 |
Smart Plug Motion Radar
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| radar movement sensor | 3..8m | max. 70x20m | 0.1 |
Smart Plug Cellular Motion Radar Down
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| radar movement sensor | 4..8m | max. 16x8m | 0.1 |
Smart Plug Cellular Motion Low
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| PIR movement sensor | 0..6m | max. ø11m | 0.1 |
Smart Plug Cellular Motion High
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| PIR movement sensor | 6..12m | max. ø18m | 0.1 |
Motion 2PIR
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| PIR movement sensor | 4..8m | max. 35x16m | 0.1 |
Motion Low
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| PIR movement sensor | max. 4.5m | max. ø15m | 0.1 |
Motion High
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| PIR movement sensor | 4..12m | max. ø30m | 0.1 |
Motion Easy
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| PIR movement sensor | 5..8m | max. 30x6m | 0.1 |
Motion Radar
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| radar movement sensor | 4..8m | max. 70x20m | 0.1 |
Smart Plug Motion Radar Down
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| radar movement sensor | 4..8m | max. 16x8m | 0.1 |
Motion Radar Down
| Type of signal input | Mounting height | Detection range movement | Wt. (kg) |
|---|---|---|---|
| radar movement sensor | 4..8m | max. 16x8m | 0.1 |
Smart Plug Motion Low
Order No.: 5EA40EL01GTIN (EAN): 4058352450208
| Type of signal input | PIR movement sensor |
|---|---|
| Mounting height | 0..6m |
| Detection range movement | max. ø11m |
| Wt. (kg) | 0.1 |
Smart Plug Motion High
Order No.: 5EA40EH01GTIN (EAN): 4058352450178
| Type of signal input | PIR movement sensor |
|---|---|
| Mounting height | 6..12m |
| Detection range movement | max. ø18m |
| Wt. (kg) | 0.1 |
Smart Plug Motion Radar
Order No.: 5EA40RC01GTIN (EAN): 4058352493618
| Type of signal input | radar movement sensor |
|---|---|
| Mounting height | 3..8m |
| Detection range movement | max. 70x20m |
| Wt. (kg) | 0.1 |
Smart Plug Cellular Motion Radar Down
Order No.: 5EA40RCPC01GTIN (EAN): 4069025455970
| Type of signal input | radar movement sensor |
|---|---|
| Mounting height | 4..8m |
| Detection range movement | max. 16x8m |
| Wt. (kg) | 0.1 |
Smart Plug Cellular Motion Low
Order No.: 5EA40ELC01GTIN (EAN): 4058352641347
| Type of signal input | PIR movement sensor |
|---|---|
| Mounting height | 0..6m |
| Detection range movement | max. ø11m |
| Wt. (kg) | 0.1 |
Smart Plug Cellular Motion High
Order No.: 5EA40EHC01GTIN (EAN): 4058352641323
| Type of signal input | PIR movement sensor |
|---|---|
| Mounting height | 6..12m |
| Detection range movement | max. ø18m |
| Wt. (kg) | 0.1 |
Motion 2PIR
Order No.: 5EA40M000201GTIN (EAN): 4058352408490
| Type of signal input | PIR movement sensor |
|---|---|
| Mounting height | 4..8m |
| Detection range movement | max. 35x16m |
| Wt. (kg) | 0.1 |
Motion Low
Order No.: 5EA40LL01GTIN (EAN): 4058352449974
| Type of signal input | PIR movement sensor |
|---|---|
| Mounting height | max. 4.5m |
| Detection range movement | max. ø15m |
| Wt. (kg) | 0.1 |
Motion High
Order No.: 5EA40LH01GTIN (EAN): 4058352450239
| Type of signal input | PIR movement sensor |
|---|---|
| Mounting height | 4..12m |
| Detection range movement | max. ø30m |
| Wt. (kg) | 0.1 |
Motion Easy
Order No.: 5EA40TE01GTIN (EAN): 4058352812075
| Type of signal input | PIR movement sensor |
|---|---|
| Mounting height | 5..8m |
| Detection range movement | max. 30x6m |
| Wt. (kg) | 0.1 |
Motion Radar
Order No.: 5EA40RS01GTIN (EAN): 4058352916476
| Type of signal input | radar movement sensor |
|---|---|
| Mounting height | 4..8m |
| Detection range movement | max. 70x20m |
| Wt. (kg) | 0.1 |
Smart Plug Motion Radar Down
Order No.: 5EA40RCP01GTIN (EAN): 4069025279385
| Type of signal input | radar movement sensor |
|---|---|
| Mounting height | 4..8m |
| Detection range movement | max. 16x8m |
| Wt. (kg) | 0.1 |
Motion Radar Down
Order No.: 5EA40RSP01GTIN (EAN): 4069025279408
| Type of signal input | radar movement sensor |
|---|---|
| Mounting height | 4..8m |
| Detection range movement | max. 16x8m |
| Wt. (kg) | 0.1 |
Optional accessories
| Order No.: 5EAU0A000001GTIN (EAN): 4058352404676 | Show all details |
| Order No.: 5EAU0H000001GTIN (EAN): 4058352641385 | Show all details |
| Order No.: 5EA40RF01GTIN (EAN): 4058352916452 | Show all details |
