Lunis 41

ProducttypesConfiguration & Datasheets

The Lunis 41 product family is the simple downlight solution. The compact, handy design with a low overall height makes it universally applicable. Various variants allow, for example, accent lighting or use in harsh environments thanks to a high degree of protection. In many cases, Lunis 41 is a practical replacement for downlights with compact fluorescent and halogen lamps.

Our simple solution: Lunis 41 is our downlight with the simplest requirements in terms of efficiency and quality

Producttypes

Lunis 41 Flat

Lunis 41 Eco

Lunis 41 Spot

Lunis 41 Spot

Intro to Productfamily

Data

Article downlight
Lighting effect direct distribution
Net luminous flux 500lm to 720lm
Colour temperature 3000K; 4000K
Control ON/OFF
Protection rating IP20
Insulation class insulation class II (safety insulation)

Specials

Directional spotlight for ceiling installation with swiveling head (±25°)
For simple accent lighting in public buildings and retail
Compact, handy design
Directed light with good colour rendering in two colour temperatures (3000K, 4000K)
Due to its compact dimensions and the standard installation diameter, is in many cases ideal for renovation purposes and as a replacement for conventional halogen lamp downlights

Configuration & Datasheets

Colour temperature

Rated luminous flux

Results

Lunis 41 Spot, Light colour 830, ON/OFF, 68

Order No.: 51DT137A31AGTIN (EAN): 4058352510001
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
3000KCRI > 80500lm5W100lm/WON/OFF880.1
Show details
Tender textData sheet (PDF, full)Photometric report / planning dataAll Downloads

Lunis 41 Spot, Light colour 830, ON/OFF, 68

Order No.: 51DT137A32AGTIN (EAN): 4058352510018
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
3000KCRI > 80650lm6.5W100lm/WON/OFF880.1
Show details
Tender textData sheet (PDF, full)Photometric report / planning dataAll Downloads

Lunis 41 Spot, Light colour 840, ON/OFF, 68

Order No.: 51DT137A41AGTIN (EAN): 4058352510025
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
4000KCRI > 80550lm5W110lm/WON/OFF880.1
Show details
Tender textData sheet (PDF, full)Photometric report / planning dataAll Downloads

Lunis 41 Spot, Light colour 840, ON/OFF, 68

Order No.: 51DT137A42AGTIN (EAN): 4058352510032
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
4000KCRI > 80720lm6.5W111lm/WON/OFF880.1
Show details
Tender textData sheet (PDF, full)Photometric report / planning dataAll Downloads

Lunis 41 Spot, Light colour 830, ON/OFF, 68

Order No.: 51DT137A31AGTIN (EAN): 4058352510001

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux500lm
Connected load5W
Luminous efficacy100lm/W
ControlON/OFF
D (mm)88
Wt. (kg)0.1
Show details

Lunis 41 Spot, Light colour 830, ON/OFF, 68

Order No.: 51DT137A32AGTIN (EAN): 4058352510018

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux650lm
Connected load6.5W
Luminous efficacy100lm/W
ControlON/OFF
D (mm)88
Wt. (kg)0.1
Show details

Lunis 41 Spot, Light colour 840, ON/OFF, 68

Order No.: 51DT137A41AGTIN (EAN): 4058352510025

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux550lm
Connected load5W
Luminous efficacy110lm/W
ControlON/OFF
D (mm)88
Wt. (kg)0.1
Show details

Lunis 41 Spot, Light colour 840, ON/OFF, 68

Order No.: 51DT137A42AGTIN (EAN): 4058352510032

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux720lm
Connected load6.5W
Luminous efficacy111lm/W
ControlON/OFF
D (mm)88
Wt. (kg)0.1
Show details

Optional accessory

Articlejunction box, IP20PU1 pc.Wt. (kg)0.1Order No.: 58DV003GTIN (EAN): 4058352534304Show details
