SiCompact® 31

ProducttypesConfiguration & Datasheets

SiCompact® stands for high reliability, robustness, ease of assembly and quality. High-quality workmanship, modern lighting technology and the high degree of protection IP66 make the floodlight family the first choice for standard outdoor lighting tasks and present it as an economical, low-maintenance, energy-efficient lighting solution.

Industrial-look design meets state of the art technology

Producttypes

SiCompact® 31 micro

SiCompact® 31 mini

SiCompact® 31 midi

SiCompact® 31 maxi

SiCompact® 31 micro

Intro to Productfamily

Data

Article floodlight
Lighting effect direct asymmetric distribution
Net luminous flux 4400lm
Colour temperature 3000K; 4000K
Control ON/OFF

Specials

Easy and quick installation thanks to mounting bracket and preassembled connection cable (2m)
High efficient operation with up to 170lm/W and asymmetric narrow light distribution (PL32)
Robust housing and ESD-protected LED module, IP66, IK08, dustproof, vibration stability tested with 250,000 strokes, ENEC certified
High flexibility for all requirements with four construction sizes and rated luminous fluxes of 4,400–70,000lm

Configuration & Datasheets

Results

SiCompact® 31 micro, PL32, asymmetric distribution

Order No.: 5XA7561A1K23GTIN (EAN): 4058352624548
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
3000KCRI > 704400lmPL3230W147lm/WON/OFF1.9
Show details
Tender textData sheet (PDF, full)Photometric report / planning dataAll Downloads

SiCompact® 31 micro, PL32, asymmetric distribution

Order No.: 5XA7561A2K23GTIN (EAN): 4058352624562
Colour temperatureColour renderingLuminous fluxLight distributionConnected loadLuminous efficacyControlWt. (kg)
4000KCRI > 704400lmPL3229W152lm/WON/OFF2.3
Show details
Tender textData sheet (PDF, full)Photometric report / planning dataAll Downloads

SiCompact® 31 micro, PL32, asymmetric distribution

Order No.: 5XA7561A1K23GTIN (EAN): 4058352624548

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux4400lm
Light distributionPL32
Connected load30W
Luminous efficacy147lm/W
ControlON/OFF
Wt. (kg)1.9
Show details

SiCompact® 31 micro, PL32, asymmetric distribution

Order No.: 5XA7561A2K23GTIN (EAN): 4058352624562

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux4400lm
Light distributionPL32
Connected load29W
Luminous efficacy152lm/W
ControlON/OFF
Wt. (kg)2.3
Show details

Optional accessory

Articlesystem connector: plug/socket, IP65, 3-pole, max. 2.5mm²PU1 pc.Wt. (kg)0.1Order No.: 5NX30003GTIN (EAN): 4058352143254Show details
Articlecross-arm, single, galvanised, d_a= 60mmPU1 pc.Wt. (kg)2.0Order No.: 5NY74701XA01GTIN (EAN): 4039806199508Show details
Articlecross-arm, single, galvanised, d_a= 76mmPU1 pc.Wt. (kg)2.2Order No.: 5NY74701XA11GTIN (EAN): 4039806199522Show details
Articlecross-arm, single, galvanised, d_a= 89mmPU1 pc.Wt. (kg)2.3Order No.: 5NY74701XA21GTIN (EAN): 4039806199546Show details
Articlecross-arm, twin, galvanised, d_a= 76mmPU1 pc.Wt. (kg)3.3Order No.: 5NY74702XA11GTIN (EAN): 4039806199409Show details
Articlecross-arm, twin, galvanised, d_a= 89mmPU1 pc.Wt. (kg)3.5Order No.: 5NY74702XA21GTIN (EAN): 4039806383365Show details
Articlecross-arm, single, DB 702S, d_a= 60mmPU1 pc.Wt. (kg)2.0Order No.: 5NY74701XA0108GTIN (EAN): 4050737956084Show details
Articlecross-arm, single, DB 702S, d_a= 76mmPU1 pc.Wt. (kg)2.2Order No.: 5NY74701XA1108GTIN (EAN): 4050737956107Show details
Articlecross-arm, single, DB 702S, d_a= 89mmPU1 pc.Wt. (kg)2.3Order No.: 5NY74701XA2108GTIN (EAN): 4050737956138Show details
Articlecross-arm, twin, DB 702S, d_a= 76mmPU1 pc.Wt. (kg)3.2Order No.: 5NY74702XA1108GTIN (EAN): 4050737956169Show details
