Lunis®

ProducttypesConfiguration & Datasheets

Whether spotlight, downlight or wallwasher – the Lunis® range meets maximum demands in terms of design, quality of light and flexibility. As an individual lighting construction kit it masters the complete spectrum, from general lighting and VDU workstation illumination to pinpoint accenting. The high quality design ensures seamless integration into the architectural space especially with the recessed versions. The Optical Core System always provides the best quality of light and enables optimum visual conditions with up to UGR ≤ 19.

Form and function in harmony

Lunis® Wallwasher

Intro to Productfamily

Data

Article downlight
Lighting effect wallwasher - direct asymmetric distribution; wallwasher - direct asymmetric distribution
Net luminous flux 1100lm to 2470lm
Colour temperature 3000K; 4000K
Control ON/OFF; DALI

Specials

High flexibility due to modular design and large number of variants based on the Optical Core System
Seamless integration into the architectural space due to high design factor with shadow gap
Excellent visual conditions at VDU workstations due to UGR ≤ 19
Uncomplicated handling and simple, quick mounting via clip system

Configuration & Datasheets

Lighting effect

Colour temperature

Light colour

Rated luminous flux (lm)

Control

  • if required, please order visually decorative accessories separately in the corresponding size

Results

Lunis® micro round, wallwasher, Light colour 830, ON/OFF, Ø114

Order No.: 51DJ11B71WF21GTIN (EAN): 4058352105450
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
3000KCRI > 801320lm20W67lm/WON/OFF1140.5

Lunis® micro round, wallwasher, Light colour 840, ON/OFF, Ø114

Order No.: 51DJ11B71WG21GTIN (EAN): 4058352105399
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
4000KCRI > 801400lm20W71lm/WON/OFF1140.5

Lunis® micro round, wallwasher, Light colour 930, ON/OFF, Ø114

Order No.: 51DJ11B71WM21GTIN (EAN): 4058352132227
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
3000KCRI > 901100lm20W56lm/WON/OFF1140.5

Lunis® micro round, wallwasher, Light colour 940, ON/OFF, Ø114

Order No.: 51DJ11B71WN21GTIN (EAN): 4058352131695
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
4000KCRI > 901210lm20W61lm/WON/OFF1140.5

Lunis® micro round, wallwasher, Light colour 830, DALI, Ø114

Order No.: 51DJ11CD1WF21GTIN (EAN): 4058352105436
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
3000KCRI > 801320lm20W67lm/WDALI1140.5

Lunis® micro round, wallwasher, Light colour 840, DALI, Ø114

Order No.: 51DJ11CD1WG21GTIN (EAN): 4058352105412
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
4000KCRI > 801400lm20W71lm/WDALI1141.0

Lunis® micro round, wallwasher, Light colour 930, DALI, Ø114

Order No.: 51DJ11CD1WM21GTIN (EAN): 4058352132241
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
3000KCRI > 901100lm20W56lm/WDALI1140.5

Lunis® micro round, wallwasher, Light colour 940, DALI, Ø114

Order No.: 51DJ11CD1WN21GTIN (EAN): 4058352132265
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
4000KCRI > 901210lm20W61lm/WDALI1140.5

Lunis® mini round, wallwasher, Light colour 830, ON/OFF, Ø176

Order No.: 51DK11B72WF21GTIN (EAN): 4058352105474
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
3000KCRI > 802380lm28W85lm/WON/OFF1761.1

Lunis® mini round, wallwasher, Light colour 840, ON/OFF, Ø176

Order No.: 51DK11B72WG21GTIN (EAN): 4058352105535
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
4000KCRI > 802470lm28W88lm/WON/OFF1761.1

Lunis® mini round, wallwasher, Light colour 930, ON/OFF, Ø176

Order No.: 51DK11B72WM21GTIN (EAN): 4058352132289
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
3000KCRI > 901930lm28W69lm/WON/OFF1761.1

Lunis® mini round, wallwasher, Light colour 940, ON/OFF, Ø176

Order No.: 51DK11B72WN21GTIN (EAN): 4058352132302
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
4000KCRI > 902120lm28W75lm/WON/OFF1761.1

Lunis® mini round, wallwasher, Light colour 830, DALI, Ø176

Order No.: 51DK11CD2WF21GTIN (EAN): 4058352105511
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
3000KCRI > 802380lm28W86lm/WDALI1761.1

Lunis® mini round, wallwasher, Light colour 840, DALI, Ø176

Order No.: 51DK11CD2WG21GTIN (EAN): 4058352105498
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
4000KCRI > 802470lm28W89lm/WDALI1761.1

Lunis® mini round, wallwasher, Light colour 930, DALI, Ø176

Order No.: 51DK11CD2WM21GTIN (EAN): 4058352132326
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
3000KCRI > 901930lm28W69lm/WDALI1761.1

Lunis® mini round, wallwasher, Light colour 940, DALI, Ø176

Order No.: 51DK11CD2WN21GTIN (EAN): 4058352132340
Colour temperatureColour renderingLuminous fluxConnected loadLuminous efficacyControlD (mm)Wt. (kg)
4000KCRI > 902120lm28W76lm/WDALI1761.1

Lunis® micro round, wallwasher, Light colour 830, ON/OFF, Ø114

Order No.: 51DJ11B71WF21GTIN (EAN): 4058352105450

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux1320lm
Connected load20W
Luminous efficacy67lm/W
ControlON/OFF
D (mm)114
Wt. (kg)0.5

Lunis® micro round, wallwasher, Light colour 840, ON/OFF, Ø114

Order No.: 51DJ11B71WG21GTIN (EAN): 4058352105399

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux1400lm
Connected load20W
Luminous efficacy71lm/W
ControlON/OFF
D (mm)114
Wt. (kg)0.5

Lunis® micro round, wallwasher, Light colour 930, ON/OFF, Ø114

Order No.: 51DJ11B71WM21GTIN (EAN): 4058352132227

Colour temperature3000K
Colour renderingCRI > 90
Luminous flux1100lm
Connected load20W
Luminous efficacy56lm/W
ControlON/OFF
D (mm)114
Wt. (kg)0.5

Lunis® micro round, wallwasher, Light colour 940, ON/OFF, Ø114

Order No.: 51DJ11B71WN21GTIN (EAN): 4058352131695

Colour temperature4000K
Colour renderingCRI > 90
Luminous flux1210lm
Connected load20W
Luminous efficacy61lm/W
ControlON/OFF
D (mm)114
Wt. (kg)0.5

Lunis® micro round, wallwasher, Light colour 830, DALI, Ø114

Order No.: 51DJ11CD1WF21GTIN (EAN): 4058352105436

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux1320lm
Connected load20W
Luminous efficacy67lm/W
ControlDALI
D (mm)114
Wt. (kg)0.5

Lunis® micro round, wallwasher, Light colour 840, DALI, Ø114

Order No.: 51DJ11CD1WG21GTIN (EAN): 4058352105412

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux1400lm
Connected load20W
Luminous efficacy71lm/W
ControlDALI
D (mm)114
Wt. (kg)1.0

Lunis® micro round, wallwasher, Light colour 930, DALI, Ø114

Order No.: 51DJ11CD1WM21GTIN (EAN): 4058352132241

Colour temperature3000K
Colour renderingCRI > 90
Luminous flux1100lm
Connected load20W
Luminous efficacy56lm/W
ControlDALI
D (mm)114
Wt. (kg)0.5

Lunis® micro round, wallwasher, Light colour 940, DALI, Ø114

Order No.: 51DJ11CD1WN21GTIN (EAN): 4058352132265

Colour temperature4000K
Colour renderingCRI > 90
Luminous flux1210lm
Connected load20W
Luminous efficacy61lm/W
ControlDALI
D (mm)114
Wt. (kg)0.5

Lunis® mini round, wallwasher, Light colour 830, ON/OFF, Ø176

Order No.: 51DK11B72WF21GTIN (EAN): 4058352105474

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux2380lm
Connected load28W
Luminous efficacy85lm/W
ControlON/OFF
D (mm)176
Wt. (kg)1.1

Lunis® mini round, wallwasher, Light colour 840, ON/OFF, Ø176

Order No.: 51DK11B72WG21GTIN (EAN): 4058352105535

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux2470lm
Connected load28W
Luminous efficacy88lm/W
ControlON/OFF
D (mm)176
Wt. (kg)1.1

Lunis® mini round, wallwasher, Light colour 930, ON/OFF, Ø176

Order No.: 51DK11B72WM21GTIN (EAN): 4058352132289

Colour temperature3000K
Colour renderingCRI > 90
Luminous flux1930lm
Connected load28W
Luminous efficacy69lm/W
ControlON/OFF
D (mm)176
Wt. (kg)1.1

Lunis® mini round, wallwasher, Light colour 940, ON/OFF, Ø176

Order No.: 51DK11B72WN21GTIN (EAN): 4058352132302

Colour temperature4000K
Colour renderingCRI > 90
Luminous flux2120lm
Connected load28W
Luminous efficacy75lm/W
ControlON/OFF
D (mm)176
Wt. (kg)1.1

Lunis® mini round, wallwasher, Light colour 830, DALI, Ø176

Order No.: 51DK11CD2WF21GTIN (EAN): 4058352105511

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux2380lm
Connected load28W
Luminous efficacy86lm/W
ControlDALI
D (mm)176
Wt. (kg)1.1

Lunis® mini round, wallwasher, Light colour 840, DALI, Ø176

Order No.: 51DK11CD2WG21GTIN (EAN): 4058352105498

Colour temperature4000K
Colour renderingCRI > 80
Luminous flux2470lm
Connected load28W
Luminous efficacy89lm/W
ControlDALI
D (mm)176
Wt. (kg)1.1

Lunis® mini round, wallwasher, Light colour 930, DALI, Ø176

Order No.: 51DK11CD2WM21GTIN (EAN): 4058352132326

Colour temperature3000K
Colour renderingCRI > 90
Luminous flux1930lm
Connected load28W
Luminous efficacy69lm/W
ControlDALI
D (mm)176
Wt. (kg)1.1

Lunis® mini round, wallwasher, Light colour 940, DALI, Ø176

Order No.: 51DK11CD2WN21GTIN (EAN): 4058352132340

Colour temperature4000K
Colour renderingCRI > 90
Luminous flux2120lm
Connected load28W
Luminous efficacy76lm/W
ControlDALI
D (mm)176
Wt. (kg)1.1

Optional accessory

Articledecorative cover ring, black, roundPU1 pc.Wt. (kg)0.1Order No.: 59DL10000400D00D0GTIN (EAN): 4058352115084Show details
Articledecorative cover ring, metallic grey (RAL 9006), roundPU1 pc.Wt. (kg)0.1Order No.: 59DL10000300D00D0GTIN (EAN): 4058352114797Show details
Articledecorative cover ring, black, roundPU1 pc.Wt. (kg)0.1Order No.: 59DL10000400F00D0GTIN (EAN): 4058352103814Show details
Articledecorative cover ring, metallic grey (RAL 9006), roundPU1 pc.Wt. (kg)0.1Order No.: 59DL10000300F00D0GTIN (EAN): 4058352097106Show details
