Silica® 21
The Silica® 21 offers maximum flexibility in use and is suitable for all mounting situations thanks to its modular design. It is the ideal basis for a smart office through flexible expansion with intelligent sensors, for example for room data acquisition with an open interface. As a sustainable luminaire thanks to easily exchangeable components, the Silica® 21 is the perfect solution for individual projects thanks to the modular principle.
Our open solution: modular, networked, adaptable and open in design
ELDACON® L - with darklight reflector, white
Intro to Productfamily
Data
Article office luminaire
Light emission direct/indirect distribution
Beam angle wide distribution
Net luminous flux 7060lm to 17650lm
Colour temperature 3000K; 4000K
Control DALI 2
Protection rating IP20
Insulation class insulation class I (protective earthing)
Specials
ELDACON® L - lens-reflector optical system: combination of lens with Fibonacci structure and reflector for homogeneous, perfectly mixed light and uniform illumination; with design specified darklight reflectors to avoid glare
Configuration & Datasheets
- please order wire suspension separately (wire suspension in pairs, 1 set required per luminaire | 1 set contains 1x wire suspension with ceiling canopy and connecting cable and 1x wire suspension with ceiling sleeve); wire suspension with height adjustment
- for suspension height > 1.2m: please order the corresponding number of connecting cables and supplementary wires separately
- for continuous row: please order the required number of luminaire connectors and through-wiring kits separately
Results
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 840, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DA47WGTIN (EAN): 4058352619810
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 7060lm | 45.5W | 155lm/W | DALI 2 | 1204 | 3.0 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 840, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DB49WGTIN (EAN): 4058352615485
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8830lm | 56.2W | 157lm/W | DALI 2 | 1504 | 3.5 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 840, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DC4DWGTIN (EAN): 4058352641248
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 17650lm | 110W | 160lm/W | DALI 2 | 3004 | 5.5 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 830, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DA37WGTIN (EAN): 4058352810880
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 7060lm | 50.7W | 139lm/W | DALI 2 | 1204 | 3.0 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 830, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DB39WGTIN (EAN): 4058352810897
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 8830lm | 62.3W | 142lm/W | DALI 2 | 1504 | 3.5 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 830, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DC3DWGTIN (EAN): 4058352810903
| Colour temperature | Colour rendering | Luminous flux | Connected load | Luminous efficacy | Control | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 17650lm | 123.8W | 143lm/W | DALI 2 | 3004 | 5.5 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 840, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DA47WGTIN (EAN): 4058352619810
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 7060lm |
| Connected load | 45.5W |
| Luminous efficacy | 155lm/W |
| Control | DALI 2 |
| L (mm) | 1204 |
| Wt. (kg) | 3.0 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 840, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DB49WGTIN (EAN): 4058352615485
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 8830lm |
| Connected load | 56.2W |
| Luminous efficacy | 157lm/W |
| Control | DALI 2 |
| L (mm) | 1504 |
| Wt. (kg) | 3.5 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 840, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DC4DWGTIN (EAN): 4058352641248
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 17650lm |
| Connected load | 110W |
| Luminous efficacy | 160lm/W |
| Control | DALI 2 |
| L (mm) | 3004 |
| Wt. (kg) | 5.5 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 830, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DA37WGTIN (EAN): 4058352810880
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 7060lm |
| Connected load | 50.7W |
| Luminous efficacy | 139lm/W |
| Control | DALI 2 |
| L (mm) | 1204 |
| Wt. (kg) | 3.0 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 830, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DB39WGTIN (EAN): 4058352810897
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 8830lm |
| Connected load | 62.3W |
| Luminous efficacy | 142lm/W |
| Control | DALI 2 |
| L (mm) | 1504 |
| Wt. (kg) | 3.5 |
Silica® 21, wide distribution, ELDACON® L, darklight reflector, white, Light colour 830, UGR ≤ 19, DALI 2, traffic white (RAL 9016)
Order No.: 51MX36DC3DWGTIN (EAN): 4058352810903
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Luminous flux | 17650lm |
| Connected load | 123.8W |
| Luminous efficacy | 143lm/W |
| Control | DALI 2 |
| L (mm) | 3004 |
| Wt. (kg) | 5.5 |
Mandatory accessory
| Order No.: 59MX30DH20WGTIN (EAN): 4058352606032 | Show details |
| Order No.: 59MX30DJ20WGTIN (EAN): 4058352606056 | Show details |
| Order No.: 59MX30DH20SGTIN (EAN): 4058352606025 | Show details |
| Order No.: 59MX30DJ20SGTIN (EAN): 4058352606049 | Show details |
| Order No.: 59MX300020XGTIN (EAN): 4058352606001 | Show details |
| Order No.: 59MX300040XGTIN (EAN): 4058352606018 | Show details |
| Order No.: 59MX30DL20XGTIN (EAN): 4058352606063 | Show details |
| Order No.: 59MX30DL40XGTIN (EAN): 4058352606070 | Show details |
Optional accessory
| Order No.: 59MX700V40XGTIN (EAN): 4058352606087 | Show details |
| Order No.: 59MX70DL10XGTIN (EAN): 4058352606094 | Show details |
| Order No.: 59MX70DL20XGTIN (EAN): 4058352606100 | Show details |
| Order No.: 59MX70DL30XGTIN (EAN): 4058352606117 | Show details |
