SITECO
SITECO Connect 41
Luminaires can be switched on and off or dimmed using a push button (ECG DALI).
Special features
Light only when and where and to the extent that it is actually needed
The user can control the lighting at any time using a push button (on/off/dimming)
The controller bundles the entire control intelligence for the room in one device
Significantly less installation and cabling effort than with central lighting or building management systems
Easy commissioning via push button - DALI knowledge is not necessary
Configuration & data sheets
- DALI, master function, broadcast addressing, max. 32 DALI ECGs
- push button short press: On/Off, push button long press: dimming, push button double press: save switch-on setpoint
Results
controller, in the ceiling
Order No.: 5LZ904315 GTIN (EAN): 4058352559925
| Control | Installation type | Protection rating | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|
| DALI | recessed | IP20 | 0.1 | 154.90 |
controller, in the ceiling
Order No.: 5LZ904315GTIN (EAN): 4058352559925
| Control | DALI |
|---|---|
| Installation type | recessed |
| Protection rating | IP20 |
| Wt. (kg) | 0.1 |
| Price (EUR) | 154.90 |
Mandatory accessories
| Order No.: 5LZ9047212GTIN (EAN): 4008321392091 | Show all details |
