Streetlight 11

ProducttypesConfiguration & Datasheets

A modern design with outstanding light, efficient performance of up to 150lm/W, reliable operation and intelligent control. Three sizes and specifications according to requirements ensure maximum flexibility in application. The silver-coated HD faceted reflectors guarantee precise and targeted illumination without unnecessary stray light or glare. The sophisticated, modular design principle makes individual components accessible without tools and forms the basis for an extremely high recycling rate of up to 90%. Open Zhaga interfaces enable intelligent control and networking options for tomorrow's Smart City applications.

Streetlight SL 11 Undisputedly the top model in technical road luminaires.

Streetlight 11 micro

Intro to Productfamily

Data

Article mast luminaire
Net luminous flux 1380lm to 3840lm
Colour temperature 2200K; 3000K; 4000K
Lighting effect direct asymmetric wide distribution; direct asymmetric extremely wide distribution
Light distribution ST0.5a; ST1.2a; P1.0a
Protection rating IP66
Insulation class insulation class II (safety insulation)

Specials

Especially durable thanks to robust diecast aluminum housing (IP66/IK09) with optimum heat dissipation, ensuring more than 90% residual luminous flux after 100,000 hours of service life
Highly efficient LED technology up to 150lm/W with uniform, glare-free illumination via HD faceted reflectors with patented silver coating
Digital interface for automatic communication when replacing ECGs or modules – individual pre-configuration of the luminaire ex-works on request
Multiple control options, intelligent dimming, CLO 2.0 and Smart Interface (Zhaga & D4i) for Smart City applications, and featuring modular design for component upgrades

Configuration & Datasheets

Lighting effect

Light distribution

Colour temperature

Control

Smart City

  • please order mast flange according to spigot diameter separately
  • luminaire includes pre-assembled connection cable, l = 5.5m (low luminous flux levels), l = 6.5m (high luminous flux levels); please order the 'mast cable set for Streetlight 11' for configuration of the Plus version with the installed luminaire separately if required
  • please order Siteco® Service Box for configuration of Plus version separately if required
  • please order adapter cable for connection of Siteco® Service Box separately if required
  • if required, please order ‘OSRAM DALI magic’ or ‘PRH 101 (NFC)’ for transmitting the configuration separately for Smart City luminaires
  • please order SLC lighting management components for the Premium version separately if required

Results

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A21B08DCGTIN (EAN): 4058352381380
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 702600lmST1.2aPlus2627135.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A31B08CCGTIN (EAN): 4058352381410
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 801620lmST1.2aPlus141475.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A31B08DCGTIN (EAN): 4058352381427
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 802810lmST1.2aPlus2527125.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A32D08DCGTIN (EAN): 4058352381052
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 803160lmST1.2aDALI2930155.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface above

Order No.: 5XC1A32S08DCGTIN (EAN): 4058352358443
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 803170lmST1.2a 2930 5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A32T08DCGTIN (EAN): 4058352390573
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 803170lmST1.2a 2930 5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface above

Order No.: 5XC1A42S08DCGTIN (EAN): 4058352358467
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703830lmST1.2a 2930 5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A42T08DCGTIN (EAN): 4058352390597
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703830lmST1.2a 2930 5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B31B08CCGTIN (EAN): 4058352381489
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 801630lmST0.5aPlus141475.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B31B08DCGTIN (EAN): 4058352381502
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 802820lmST0.5aPlus2527125.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B32D08DCGTIN (EAN): 4058352381090
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 803170lmST0.5aDALI2930155.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C21B08DCGTIN (EAN): 4058352381137
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 702210lmP1.0aPlus2627135.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C31B08CCGTIN (EAN): 4058352381151
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 801380lmP1.0aPlus141475.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C31B08DCGTIN (EAN): 4058352381175
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 802390lmP1.0aPlus2527125.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C32D08DCGTIN (EAN): 4058352381199
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 802690lmP1.0aDALI2930155.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41B08CCGTIN (EAN): 4058352381441
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701920lmST1.2aPlus141485.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41B08DCGTIN (EAN): 4058352381465
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703400lmST1.2aPlus2527135.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A42D08DCGTIN (EAN): 4058352381076
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703830lmST1.2aDALI2930155.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41B08CCGTIN (EAN): 4058352381526
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701930lmST0.5aPlus141485.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41B08DCGTIN (EAN): 4058352381557
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703410lmST0.5aPlus2527135.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B42D08DCGTIN (EAN): 4058352381113
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703840lmST0.5aDALI2930155.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C41B08CCGTIN (EAN): 4058352381564
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 701630lmP1.0aPlus141485.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C41B08DCGTIN (EAN): 4058352381588
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 702890lmP1.0aPlus2527135.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C42D08DCGTIN (EAN): 4058352381212
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 703250lmP1.0aDALI2930155.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51B08CCGTIN (EAN): 4058352478493
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701830lmST1.2aPlus141475.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51B08DCGTIN (EAN): 4058352478516
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703220lmST1.2aPlus2527125.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51B08CCGTIN (EAN): 4058352495896
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701840lmST0.5aPlus141475.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51B08DCGTIN (EAN): 4058352495919
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703230lmST0.5aPlus2527125.2

Streetlight 11 micro LED, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C51B08CCGTIN (EAN): 4058352495940
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 701560lmP1.0aPlus141475.2

Streetlight 11 micro LED, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C51B08DCGTIN (EAN): 4058352495957
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 702740lmP1.0aPlus2527125.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A52D08DCGTIN (EAN): 4058352478547
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703630lmST1.2aDALI2930155.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A52T08DCGTIN (EAN): 4058352478578
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 703640lmST1.2a 2930 5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A21B08DCGTIN (EAN): 4058352381380

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux2600lm
Light distributionST1.2a
ControlPlus
Pnom begin service life26
Pnom end service life27
Pred at 50% lumin. flux13
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A31B08CCGTIN (EAN): 4058352381410

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux1620lm
Light distributionST1.2a
ControlPlus
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A31B08DCGTIN (EAN): 4058352381427

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux2810lm
Light distributionST1.2a
ControlPlus
Pnom begin service life25
Pnom end service life27
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A32D08DCGTIN (EAN): 4058352381052

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux3160lm
Light distributionST1.2a
ControlDALI
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux15
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface above

Order No.: 5XC1A32S08DCGTIN (EAN): 4058352358443

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux3170lm
Light distributionST1.2a
Control
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A32T08DCGTIN (EAN): 4058352390573

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux3170lm
Light distributionST1.2a
Control
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface above

Order No.: 5XC1A42S08DCGTIN (EAN): 4058352358467

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3830lm
Light distributionST1.2a
Control
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A42T08DCGTIN (EAN): 4058352390597

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3830lm
Light distributionST1.2a
Control
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B31B08CCGTIN (EAN): 4058352381489

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux1630lm
Light distributionST0.5a
ControlPlus
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B31B08DCGTIN (EAN): 4058352381502

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux2820lm
Light distributionST0.5a
ControlPlus
Pnom begin service life25
Pnom end service life27
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B32D08DCGTIN (EAN): 4058352381090

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux3170lm
Light distributionST0.5a
ControlDALI
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux15
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C21B08DCGTIN (EAN): 4058352381137

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux2210lm
Light distributionP1.0a
ControlPlus
Pnom begin service life26
Pnom end service life27
Pred at 50% lumin. flux13
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C31B08CCGTIN (EAN): 4058352381151

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux1380lm
Light distributionP1.0a
ControlPlus
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C31B08DCGTIN (EAN): 4058352381175

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux2390lm
Light distributionP1.0a
ControlPlus
Pnom begin service life25
Pnom end service life27
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C32D08DCGTIN (EAN): 4058352381199

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux2690lm
Light distributionP1.0a
ControlDALI
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux15
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41B08CCGTIN (EAN): 4058352381441

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1920lm
Light distributionST1.2a
ControlPlus
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux8
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A41B08DCGTIN (EAN): 4058352381465

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3400lm
Light distributionST1.2a
ControlPlus
Pnom begin service life25
Pnom end service life27
Pred at 50% lumin. flux13
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A42D08DCGTIN (EAN): 4058352381076

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3830lm
Light distributionST1.2a
ControlDALI
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux15
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41B08CCGTIN (EAN): 4058352381526

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1930lm
Light distributionST0.5a
ControlPlus
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux8
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B41B08DCGTIN (EAN): 4058352381557

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3410lm
Light distributionST0.5a
ControlPlus
Pnom begin service life25
Pnom end service life27
Pred at 50% lumin. flux13
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B42D08DCGTIN (EAN): 4058352381113

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3840lm
Light distributionST0.5a
ControlDALI
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux15
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C41B08CCGTIN (EAN): 4058352381564

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux1630lm
Light distributionP1.0a
ControlPlus
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux8
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C41B08DCGTIN (EAN): 4058352381588

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux2890lm
Light distributionP1.0a
ControlPlus
Pnom begin service life25
Pnom end service life27
Pred at 50% lumin. flux13
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric extremely wide distribution, P1.0a

Order No.: 5XC1C42D08DCGTIN (EAN): 4058352381212

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux3250lm
Light distributionP1.0a
ControlDALI
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux15
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51B08CCGTIN (EAN): 4058352478493

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1830lm
Light distributionST1.2a
ControlPlus
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A51B08DCGTIN (EAN): 4058352478516

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3220lm
Light distributionST1.2a
ControlPlus
Pnom begin service life25
Pnom end service life27
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51B08CCGTIN (EAN): 4058352495896

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1840lm
Light distributionST0.5a
ControlPlus
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC1B51B08DCGTIN (EAN): 4058352495919

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3230lm
Light distributionST0.5a
ControlPlus
Pnom begin service life25
Pnom end service life27
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C51B08CCGTIN (EAN): 4058352495940

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux1560lm
Light distributionP1.0a
ControlPlus
Pnom begin service life14
Pnom end service life14
Pred at 50% lumin. flux7
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, P1.0a

Order No.: 5XC1C51B08DCGTIN (EAN): 4058352495957

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux2740lm
Light distributionP1.0a
ControlPlus
Pnom begin service life25
Pnom end service life27
Pred at 50% lumin. flux12
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC1A52D08DCGTIN (EAN): 4058352478547

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3630lm
Light distributionST1.2a
ControlDALI
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux15
Wt. (kg)5.2

Streetlight 11 micro LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC1A52T08DCGTIN (EAN): 4058352478578

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux3640lm
Light distributionST1.2a
Control
Pnom begin service life29
Pnom end service life30
Pred at 50% lumin. flux
Wt. (kg)5.2

Mandatory accessory

Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 42mmPU1 pc.Wt. (kg)0.5Order No.: 5XC10008XM4GTIN (EAN): 4058352147849Show details
Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 60mmPU1 pc.Wt. (kg)0.6Order No.: 5XC10008XM2GTIN (EAN): 4058352147825Show details
Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 76mmPU1 pc.Wt. (kg)0.7Order No.: 5XC10008XM1GTIN (EAN): 4058352147801Show details

Optional accessory

Articleshield, lateral shielding, shielding for glare limitation class G4PU2 pcs.Wt. (kg)0.2Order No.: 5XCBLE108G4GTIN (EAN): 4058352188439Show details
Articleshield, lateral shielding, shielding for glare limitation class G6PU2 pcs.Wt. (kg)0.1Order No.: 5XCBLE108G6GTIN (EAN): 4058352188453Show details
Articleshield, shielding on road and mast sidePU1 pc.Wt. (kg)0.1Order No.: 5XCBLE108BLGTIN (EAN): 4058352384213Show details
Articlecable set for mast, Plus version, L= 4mPU1 pc.Wt. (kg)0.8Order No.: 5EA6Y00L02GTIN (EAN): 4050737028804Show details
Articlecable set for mast, Plus version, L= 5mPU1 pc.Wt. (kg)0.9Order No.: 5EA6Y00L03GTIN (EAN): 4050737028828Show details
Articlecable set for mast, Plus version, L= 6mPU1 pc.Wt. (kg)1.1Order No.: 5EA6Y00L08GTIN (EAN): 4050737056098Show details
ArticleSiteco® Service Box WiFi, for Plus versionPU1 pc.Wt. (kg)3.5Order No.: 5EA6TEF02GTIN (EAN): 4058352017357Show details
