Streetlight 11

ProducttypesConfiguration & Datasheets

A modern design with outstanding light, efficient performance of up to 150lm/W, reliable operation and intelligent control. Three sizes and specifications according to requirements ensure maximum flexibility in application. The silver-coated HD faceted reflectors guarantee precise and targeted illumination without unnecessary stray light or glare. The sophisticated, modular design principle makes individual components accessible without tools and forms the basis for an extremely high recycling rate of up to 90%. Open Zhaga interfaces enable intelligent control and networking options for tomorrow's Smart City applications.

Streetlight SL 11 Undisputedly the top model in technical road luminaires.

Streetlight 11 midi

Intro to Productfamily

Data

Article mast luminaire
Net luminous flux 7820lm to 18980lm
Colour temperature 2200K; 3000K; 4000K
Lighting effect direct asymmetric wide distribution; direct asymmetric wide distribution with rear light component; direct asymmetric (left) wide distribution; direct asymmetric (right) wide distribution
Light distribution ST0.5a; ST1.2a; ST0.5ST0.5; ST1.2P1.0; PC-R; PC-L
Protection rating IP66
Insulation class insulation class II (safety insulation)

Specials

Especially durable thanks to robust diecast aluminum housing (IP66/IK09) with optimum heat dissipation, ensuring more than 90% residual luminous flux after 100,000 hours of service life
Highly efficient LED technology up to 150lm/W with uniform, glare-free illumination via HD faceted reflectors with patented silver coating
Digital interface for automatic communication when replacing ECGs or modules – individual pre-configuration of the luminaire ex-works on request
Multiple control options, intelligent dimming, CLO 2.0 and Smart Interface (Zhaga & D4i) for Smart City applications, and featuring modular design for component upgrades

Configuration & Datasheets

Lighting effect

Light distribution

Colour temperature

Control

Smart City

  • please order mast flange according to spigot diameter separately
  • luminaire includes pre-assembled connection cable, l = 8.5m (low luminous flux levels), l = 12.5m (high luminous flux levels); please order the 'mast cable set for Streetlight 11' for configuration of the Plus version with the installed luminaire separately if required
  • please order Siteco® Service Box for configuration of Plus version separately if required
  • please order adapter cable for connection of Siteco® Service Box separately if required
  • if required, please order ‘OSRAM DALI magic’ or ‘PRH 101 (NFC)’ for transmitting the configuration separately for Smart City luminaires
  • please order SLC lighting management components for the Premium version separately if required
  • Please order covers for shielding on the sides and on the street or mast side separately, if required (the luminaire has 2 LED modules, so order two PUs for each application)

Results

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A21B08MCGTIN (EAN): 4058352383308
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 7013510lmST1.2aPlus1301405911.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A31B08LCGTIN (EAN): 4058352383322
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 808020lmST1.2aPlus64653211.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A31B08MCGTIN (EAN): 4058352383346
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8014660lmST1.2aPlus1301405811.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A32D08MCGTIN (EAN): 4058352382844
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8015570lmST1.2aDALI1391536211.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface above

Order No.: 5XC3A32S08MCGTIN (EAN): 4058352358627
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8015570lmST1.2a 138152 11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC3A32T08MCGTIN (EAN): 4058352390856
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8015570lmST1.2a 138152 11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A41B08LCGTIN (EAN): 4058352383377
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 709570lmST1.2aPlus64653311.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A41B08MCGTIN (EAN): 4058352383384
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7018600lmST1.2aPlus1371506211.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A42D08MCGTIN (EAN): 4058352382875
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7018850lmST1.2aDALI1391536311.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface above

Order No.: 5XC3A42S08MCGTIN (EAN): 4058352358641
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7018860lmST1.2a 138152 11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC3A42T08MCGTIN (EAN): 4058352390870
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7018860lmST1.2a 138152 11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC3B31B08MCGTIN (EAN): 4058352382882
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8014700lmST0.5aPlus1301405811.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC3B32D08MCGTIN (EAN): 4058352382905
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8015610lmST0.5aDALI1391536211.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC3B41B08MCGTIN (EAN): 4058352382929
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7018650lmST0.5aPlus1371506211.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC3B42D08MCGTIN (EAN): 4058352382943
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7018900lmST0.5aDALI1391536311.5

Streetlight 11 midi LED, direct asymmetric (left) wide distribution, PC-L

Order No.: 5XC3E21B08MCGTIN (EAN): 4058352382967
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 7011530lmPC-LPlus1301405911.5

Streetlight 11 midi LED, direct asymmetric (left) wide distribution, PC-L

Order No.: 5XC3E31B08MCGTIN (EAN): 4058352382998
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8012520lmPC-LPlus1301405811.5

Streetlight 11 midi LED, direct asymmetric (left) wide distribution, PC-L

Order No.: 5XC3E32D08MCGTIN (EAN): 4058352383001
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8013290lmPC-LDALI1391536211.5

Streetlight 11 midi LED, direct asymmetric (left) wide distribution, PC-L

Order No.: 5XC3E41B08MCGTIN (EAN): 4058352383025
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7015880lmPC-LPlus1371506211.5

Streetlight 11 midi LED, direct asymmetric (left) wide distribution, PC-L

Order No.: 5XC3E42D08MCGTIN (EAN): 4058352383049
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7016090lmPC-LDALI1391536311.5

Streetlight 11 midi LED, direct asymmetric (right) wide distribution, PC-R

Order No.: 5XC3F21B08MCGTIN (EAN): 4058352383063
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
2200KCRI > 7011530lmPC-RPlus1301405911.5

Streetlight 11 midi LED, direct asymmetric (right) wide distribution, PC-R

Order No.: 5XC3F31B08MCGTIN (EAN): 4058352383087
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8012520lmPC-RPlus1301405811.5

Streetlight 11 midi LED, direct asymmetric (right) wide distribution, PC-R

Order No.: 5XC3F32D08MCGTIN (EAN): 4058352383100
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8013290lmPC-RDALI1391536211.5

Streetlight 11 midi LED, direct asymmetric (right) wide distribution, PC-R

Order No.: 5XC3F41B08MCGTIN (EAN): 4058352383407
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7015880lmPC-RPlus1371506211.5

Streetlight 11 midi LED, direct asymmetric (right) wide distribution, PC-R

Order No.: 5XC3F42D08MCGTIN (EAN): 4058352383131
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7016090lmPC-RDALI1391536311.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST1.2P1.0

Order No.: 5XC3G31B08LCGTIN (EAN): 4058352383421
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 807820lmST1.2P1.0Plus64653211.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST1.2P1.0

Order No.: 5XC3G31B08MCGTIN (EAN): 4058352383445
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8014290lmST1.2P1.0Plus1301405811.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2P1.0

Order No.: 5XC3G32D08MCGTIN (EAN): 4058352383148
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8015170lmST1.2P1.0DALI1391536211.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST1.2P1.0

Order No.: 5XC3G41B08LCGTIN (EAN): 4058352383469
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 709330lmST1.2P1.0Plus64653311.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST1.2P1.0

Order No.: 5XC3G41B08MCGTIN (EAN): 4058352383483
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7018130lmST1.2P1.0Plus1371506211.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2P1.0

Order No.: 5XC3G42D08MCGTIN (EAN): 4058352383162
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7018380lmST1.2P1.0DALI1391536311.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST0.5ST0.5

Order No.: 5XC3H31B08MCGTIN (EAN): 4058352383186
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8014760lmST0.5ST0.5Plus1301405811.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5ST0.5

Order No.: 5XC3H32D08MCGTIN (EAN): 4058352383209
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 8015670lmST0.5ST0.5DALI1391536211.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST0.5ST0.5

Order No.: 5XC3H41B08MCGTIN (EAN): 4058352383223
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7018720lmST0.5ST0.5Plus1371506211.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5ST0.5

Order No.: 5XC3H42D08MCGTIN (EAN): 4058352383247
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
4000KCRI > 7018980lmST0.5ST0.5DALI1391536311.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface above

Order No.: 5XC3A52S08MCGTIN (EAN): 4058352478790
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 7017890lmST1.2a 138152 11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC3A52T08MCGTIN (EAN): 4058352478813
Colour temperatureColour renderingLuminous fluxLight distributionControlPnom begin service lifePnom end service lifePred at 50% lumin. fluxWt. (kg)
3000KCRI > 7017890lmST1.2a 138152 11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A21B08MCGTIN (EAN): 4058352383308

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux13510lm
Light distributionST1.2a
ControlPlus
Pnom begin service life130
Pnom end service life140
Pred at 50% lumin. flux59
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A31B08LCGTIN (EAN): 4058352383322

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux8020lm
Light distributionST1.2a
ControlPlus
Pnom begin service life64
Pnom end service life65
Pred at 50% lumin. flux32
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A31B08MCGTIN (EAN): 4058352383346

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux14660lm
Light distributionST1.2a
ControlPlus
Pnom begin service life130
Pnom end service life140
Pred at 50% lumin. flux58
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A32D08MCGTIN (EAN): 4058352382844

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux15570lm
Light distributionST1.2a
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface above

Order No.: 5XC3A32S08MCGTIN (EAN): 4058352358627

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux15570lm
Light distributionST1.2a
Control
Pnom begin service life138
Pnom end service life152
Pred at 50% lumin. flux
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC3A32T08MCGTIN (EAN): 4058352390856

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux15570lm
Light distributionST1.2a
Control
Pnom begin service life138
Pnom end service life152
Pred at 50% lumin. flux
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A41B08LCGTIN (EAN): 4058352383377

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux9570lm
Light distributionST1.2a
ControlPlus
Pnom begin service life64
Pnom end service life65
Pred at 50% lumin. flux33
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A41B08MCGTIN (EAN): 4058352383384

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux18600lm
Light distributionST1.2a
ControlPlus
Pnom begin service life137
Pnom end service life150
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a

Order No.: 5XC3A42D08MCGTIN (EAN): 4058352382875

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux18850lm
Light distributionST1.2a
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux63
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface above

Order No.: 5XC3A42S08MCGTIN (EAN): 4058352358641

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux18860lm
Light distributionST1.2a
Control
Pnom begin service life138
Pnom end service life152
Pred at 50% lumin. flux
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC3A42T08MCGTIN (EAN): 4058352390870

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux18860lm
Light distributionST1.2a
Control
Pnom begin service life138
Pnom end service life152
Pred at 50% lumin. flux
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC3B31B08MCGTIN (EAN): 4058352382882

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux14700lm
Light distributionST0.5a
ControlPlus
Pnom begin service life130
Pnom end service life140
Pred at 50% lumin. flux58
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC3B32D08MCGTIN (EAN): 4058352382905

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux15610lm
Light distributionST0.5a
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC3B41B08MCGTIN (EAN): 4058352382929

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux18650lm
Light distributionST0.5a
ControlPlus
Pnom begin service life137
Pnom end service life150
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5a

Order No.: 5XC3B42D08MCGTIN (EAN): 4058352382943

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux18900lm
Light distributionST0.5a
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux63
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric (left) wide distribution, PC-L

Order No.: 5XC3E21B08MCGTIN (EAN): 4058352382967

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux11530lm
Light distributionPC-L
ControlPlus
Pnom begin service life130
Pnom end service life140
Pred at 50% lumin. flux59
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric (left) wide distribution, PC-L

Order No.: 5XC3E31B08MCGTIN (EAN): 4058352382998

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux12520lm
Light distributionPC-L
ControlPlus
Pnom begin service life130
Pnom end service life140
Pred at 50% lumin. flux58
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric (left) wide distribution, PC-L

Order No.: 5XC3E32D08MCGTIN (EAN): 4058352383001

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux13290lm
Light distributionPC-L
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric (left) wide distribution, PC-L

Order No.: 5XC3E41B08MCGTIN (EAN): 4058352383025

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux15880lm
Light distributionPC-L
ControlPlus
Pnom begin service life137
Pnom end service life150
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric (left) wide distribution, PC-L

Order No.: 5XC3E42D08MCGTIN (EAN): 4058352383049

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux16090lm
Light distributionPC-L
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux63
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric (right) wide distribution, PC-R

Order No.: 5XC3F21B08MCGTIN (EAN): 4058352383063

Colour temperature2200K
Colour renderingCRI > 70
Luminous flux11530lm
Light distributionPC-R
ControlPlus
Pnom begin service life130
Pnom end service life140
Pred at 50% lumin. flux59
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric (right) wide distribution, PC-R

Order No.: 5XC3F31B08MCGTIN (EAN): 4058352383087

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux12520lm
Light distributionPC-R
ControlPlus
Pnom begin service life130
Pnom end service life140
Pred at 50% lumin. flux58
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric (right) wide distribution, PC-R

Order No.: 5XC3F32D08MCGTIN (EAN): 4058352383100

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux13290lm
Light distributionPC-R
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric (right) wide distribution, PC-R

Order No.: 5XC3F41B08MCGTIN (EAN): 4058352383407

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux15880lm
Light distributionPC-R
ControlPlus
Pnom begin service life137
Pnom end service life150
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric (right) wide distribution, PC-R

Order No.: 5XC3F42D08MCGTIN (EAN): 4058352383131

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux16090lm
Light distributionPC-R
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux63
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST1.2P1.0

Order No.: 5XC3G31B08LCGTIN (EAN): 4058352383421

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux7820lm
Light distributionST1.2P1.0
ControlPlus
Pnom begin service life64
Pnom end service life65
Pred at 50% lumin. flux32
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST1.2P1.0

Order No.: 5XC3G31B08MCGTIN (EAN): 4058352383445

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux14290lm
Light distributionST1.2P1.0
ControlPlus
Pnom begin service life130
Pnom end service life140
Pred at 50% lumin. flux58
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2P1.0

Order No.: 5XC3G32D08MCGTIN (EAN): 4058352383148

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux15170lm
Light distributionST1.2P1.0
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST1.2P1.0

Order No.: 5XC3G41B08LCGTIN (EAN): 4058352383469

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux9330lm
Light distributionST1.2P1.0
ControlPlus
Pnom begin service life64
Pnom end service life65
Pred at 50% lumin. flux33
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST1.2P1.0

Order No.: 5XC3G41B08MCGTIN (EAN): 4058352383483

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux18130lm
Light distributionST1.2P1.0
ControlPlus
Pnom begin service life137
Pnom end service life150
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2P1.0

Order No.: 5XC3G42D08MCGTIN (EAN): 4058352383162

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux18380lm
Light distributionST1.2P1.0
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux63
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST0.5ST0.5

Order No.: 5XC3H31B08MCGTIN (EAN): 4058352383186

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux14760lm
Light distributionST0.5ST0.5
ControlPlus
Pnom begin service life130
Pnom end service life140
Pred at 50% lumin. flux58
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5ST0.5

Order No.: 5XC3H32D08MCGTIN (EAN): 4058352383209

Colour temperature3000K
Colour renderingCRI > 80
Luminous flux15670lm
Light distributionST0.5ST0.5
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution with rear light component, ST0.5ST0.5

Order No.: 5XC3H41B08MCGTIN (EAN): 4058352383223

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux18720lm
Light distributionST0.5ST0.5
ControlPlus
Pnom begin service life137
Pnom end service life150
Pred at 50% lumin. flux62
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST0.5ST0.5

Order No.: 5XC3H42D08MCGTIN (EAN): 4058352383247

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux18980lm
Light distributionST0.5ST0.5
ControlDALI
Pnom begin service life139
Pnom end service life153
Pred at 50% lumin. flux63
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface above

Order No.: 5XC3A52S08MCGTIN (EAN): 4058352478790

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux17890lm
Light distributionST1.2a
Control
Pnom begin service life138
Pnom end service life152
Pred at 50% lumin. flux
Wt. (kg)11.5

Streetlight 11 midi LED, direct asymmetric wide distribution, ST1.2a, with Smart Interface below and above

Order No.: 5XC3A52T08MCGTIN (EAN): 4058352478813

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux17890lm
Light distributionST1.2a
Control
Pnom begin service life138
Pnom end service life152
Pred at 50% lumin. flux
Wt. (kg)11.5

Mandatory accessory

Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 42mmPU1 pc.Wt. (kg)0.5Order No.: 5XC10008XM4GTIN (EAN): 4058352147849Show details
Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 60mmPU1 pc.Wt. (kg)0.6Order No.: 5XC10008XM2GTIN (EAN): 4058352147825Show details
Articlemast flange, Siteco® metallic grey (DB 702S), spigot size: 76mmPU1 pc.Wt. (kg)0.7Order No.: 5XC10008XM1GTIN (EAN): 4058352147801Show details

Optional accessory

Articleshield, lateral shielding, shielding for glare limitation class G4PU2 pcs.Wt. (kg)0.3Order No.: 5XCBLE208G4GTIN (EAN): 4058352164839Show details
Articleshield, lateral shielding, shielding for glare limitation class G6PU2 pcs.Wt. (kg)0.1Order No.: 5XCBLE208G6GTIN (EAN): 4058352164716Show details
Articleshield, shielding on road and mast sidePU1 pc.Wt. (kg)0.1Order No.: 5XCBLE208BLGTIN (EAN): 4058352384237Show details
Articlecable set for mast, Plus version, L= 4mPU1 pc.Wt. (kg)0.8Order No.: 5EA6Y00L02GTIN (EAN): 4050737028804Show details
Articlecable set for mast, Plus version, L= 5mPU1 pc.Wt. (kg)0.9Order No.: 5EA6Y00L03GTIN (EAN): 4050737028828Show details
Articlecable set for mast, Plus version, L= 6mPU1 pc.Wt. (kg)1.1Order No.: 5EA6Y00L08GTIN (EAN): 4050737056098Show details
Articlecable set for mast, Plus version, L= 7mPU1 pc.Wt. (kg)1.2Order No.: 5EA6Y00L07GTIN (EAN): 4050737037745Show details
Articlecable set for mast, Plus version, L= 8mPU1 pc.Wt. (kg)1.3Order No.: 5EA6Y00L09GTIN (EAN): 4050737056111Show details
ArticleSiteco® Service Box WiFi, for Plus versionPU1 pc.Wt. (kg)3.5Order No.: 5EA6TEF02GTIN (EAN): 4058352017357Show details
