Licross® 11
45 years of experience – trunking Made in Germany perfected in our Licross® trunking system. The one-for-all concept offers a variety of luminaire inserts and functional expansion options for maximum flexibility and future compatibility. With its unique 14 cores, the rail system becomes the backbone of the building infrastructure and is ready for a wide range of applications - today and tomorrow. The luminaire inserts offer outstanding lighting technology with up to 203lm/W or low operating costs as well as SITECO-typical optics technology for the best viewing conditions. Various extensions from sensor to cameras and data transmission open up a broad horizon of applications far from lighting, which create additional added value.
Our performance solution: Licross® 11 is our innovative trunking system with maximum efficiency (up to 203lm/W), service life (up to 100,000h) and flexibility
Protected luminaire insert IP50/IP54/IP64
Intro to Productfamily
Data
Article luminaire insert
Protection rating IP50; IP54; IP64
Net luminous flux 5500lm to 16110lm
Colour temperature 2700…6500K; 3000K; 4000K; 5000K; 6500K
Lighting effect direct symmetric extremely narrow distribution; direct symmetric extremely narrow distribution with ceiling illumination; direct symmetric narrow distribution, with ceiling illumination; direct symmetric wide distribution, with ceiling illumination
Specials
High robustness due to chemical resistance and suitability for ambient temperatures up to 50°C over complete service life
Very robust system with protection ratings to IP64/IK06 and long service life of up to 100,000 hours
High luminous flux of up to 16,000lm and tunable white function for demand-oriented illumination of harsh environments
Depending on version switchable, switchable with multilumen and constant luminous flux control (CLO) or light control via DALI
Configuration & Datasheets
- Please order Licross® Trunking trunking rail and trunking rail accessories separately.
- with ceiling surface mounting: reducing of maximum allowable ambient temperature of 5°C
- luminaire inserts (AC/DC) suiatble for group and central battery systems according to EN60598-2-22 (even at AC operation)
- With AC/DC luminaire inserts, the power supply can be changed to either mains supply operation L1/L2/L3, emergency supply 1 L´/N´ or emergency supply 2 L´´/N´´ by moving the contacts on the connection block
- with luminaire inserts (AC/DC), luminaires use reduced luminous flux with DC operation (see photometric report for DC operation)
Results
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD117N485GGTIN (EAN): 4058352928493
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8680 | 49W | 179lm/W | ON/OFF | IP54 | 1500 | 2.4 | 247.10 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11CN49XGGTIN (EAN): 4058352928509
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9030 | 49 | 55 | 183lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 2.4 | 266.70 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11CN4EXSGTIN (EAN): 4058352928523
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14460 | 78 | 87 | 186lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 2.4 | 323.50 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11DN495GGTIN (EAN): 4058352928547
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9930 | 57W | 174lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 2.4 | 278.40 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11DN4F5SGTIN (EAN): 4058352928561
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 15510 | 87W | 178lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 2.4 | 335.30 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11MN495GGTIN (EAN): 4058352928585
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 55W | 180lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 2.4 | 266.70 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11MN4GXSGTIN (EAN): 4058352928608
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 16070 | 87W | 184lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 2.4 | 323.50 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD127N485GGTIN (EAN): 4058352928622
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8720 | 49W | 180lm/W | ON/OFF | IP54 | 1500 | 2.4 | 247.10 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12CN49XGGTIN (EAN): 4058352928653
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9070 | 49 | 55 | 184lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 2.4 | 266.70 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12CN4EXMGTIN (EAN): 4058352928660
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14240 | 78 | 87 | 184lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 2.4 | 323.50 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12DN495GGTIN (EAN): 4058352928684
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 57W | 175lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 2.4 | 278.40 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD12DN495G3CGTIN (EAN): 4058352934623
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 | 547.10 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD12DN495G3SGTIN (EAN): 4058352934647
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 | 519.60 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TD12DN495G3S4GTIN (EAN): 4058352934661
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 | 519.60 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12DN4FXMGTIN (EAN): 4058352928707
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 15270 | 87W | 175lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 2.4 | 335.30 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD12DN4FXM3CGTIN (EAN): 4058352934685
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 15270 | 91W | 168lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 | 603.90 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD12DN4FXM3SGTIN (EAN): 4058352934708
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 15270 | 91W | 168lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 | 576.50 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TD12DN4FXM3S4GTIN (EAN): 4058352934739
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 15270 | 91W | 168lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 | 576.50 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12MN4AXGGTIN (EAN): 4058352928721
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 10030 | 55W | 181lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 2.4 | 266.70 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12MN4F5MGTIN (EAN): 4058352928745
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 15820 | 87W | 181lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 2.4 | 323.50 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12VN455FGTIN (EAN): 4058352749975
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 5500 | 34 | 39 | 162lm/W | DALI 2, CLO | -25..+45°C | IP54 | 1500 | 3.2 | 270.60 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12VN465FGTIN (EAN): 4058352749999
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 6510 | 40 | 47 | 163lm/W | DALI 2, CLO | -25..+40°C | IP54 | 1500 | 2.8 | 270.60 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12VN475FGTIN (EAN): 4058352750025
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 7910 | 49 | 56 | 161lm/W | DALI 2, CLO | -25..+35°C | IP54 | 1500 | 3.2 | 270.60 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP54, AC
Order No.: 51TD13CN4E5SGTIN (EAN): 4058352928769
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14500 | 78 | 87 | 187lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 2.4 | 323.50 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP54, AC
Order No.: 51TD13DN4F5SGTIN (EAN): 4058352928790
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 15550 | 87W | 178lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 2.4 | 335.30 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP54, AC
Order No.: 51TD13MN4GXSGTIN (EAN): 4058352928806
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 16110 | 87W | 184lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 2.4 | 323.50 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1B7N48XGGTIN (EAN): 4058352928967
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8190 | 49W | 169lm/W | ON/OFF | IP54 | 1500 | 2.4 | 239.20 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BCN485GGTIN (EAN): 4058352918296
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8520 | 49 | 55 | 172lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 2.4 | 256.90 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BCN4D5MGTIN (EAN): 4058352918319
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 13520 | 78 | 87 | 174lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 2.4 | 321.60 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BDN49XGGTIN (EAN): 4058352918333
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9370 | 57W | 164lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 2.4 | 268.60 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD1BDN49XG3CGTIN (EAN): 4058352938461
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9370 | 61W | 154lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 | 537.30 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD1BDN49XG3SGTIN (EAN): 4058352938485
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9370 | 61W | 154lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 | 509.80 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TD1BDN49XG3S4GTIN (EAN): 4058352938508
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9370 | 61W | 154lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 | 509.80 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BDN4E5MGTIN (EAN): 4058352918357
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14500 | 87W | 166lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 2.4 | 333.30 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD1BDN4E5M3CGTIN (EAN): 4058352938522
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14500 | 91W | 159lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 | 602.00 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD1BDN4E5M3SGTIN (EAN): 4058352938553
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14500 | 91W | 159lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 | 574.50 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TD1BDN4E5M3S4GTIN (EAN): 4058352938560
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14500 | 91W | 159lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 | 574.50 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BMN49XGGTIN (EAN): 4058352928981
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9420 | 55W | 170lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 2.4 | 256.90 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BMN4FXMGTIN (EAN): 4058352929001
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 15020 | 87W | 172lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 2.4 | 321.60 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP117N485GGTIN (EAN): 4058352930083
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8680 | 49W | 179lm/W | ON/OFF | IP64 | 1500 | 2.4 | 256.90 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11CN48XFGTIN (EAN): 4058352210574
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8140 | 49 | 54 | 166lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.2 | 267.30 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP11CN48XFDGTIN (EAN): 4058352418376
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8140 | 49 | 54 | 166lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.2 | 278.20 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11CN49XGGTIN (EAN): 4058352930106
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9030 | 49 | 55 | 183lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.4 | 276.50 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11CN4DXRGTIN (EAN): 4058352265055
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 13240 | 76 | 86 | 173lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.9 | 321.60 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP11CN4DXRDGTIN (EAN): 4058352418390
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 13240 | 76 | 86 | 173lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.9 | 332.40 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11CN4EXSGTIN (EAN): 4058352930120
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14460 | 78 | 87 | 186lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP64 | 1500 | 2.4 | 333.30 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11CN58XFGTIN (EAN): 4058352447758
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5000K | CRI > 80 | 8150 | 49 | 54 | 166lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.7 | 267.30 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN495GGTIN (EAN): 4058352930144
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 57W | 174lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 2.4 | 288.20 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN49XFGTIN (EAN): 4058352297957
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9080 | 57W | 160lm/W | DALI 2 | -25..+40°C | IP64 | 1500 | 3.2 | 284.30 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP11DN49XFDGTIN (EAN): 4058352418413
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9080 | 57W | 160lm/W | DALI 2 | -25..+40°C | IP64 | 1500 | 3.2 | 296.30 |
Licross® 11 Protected extreme MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN49XFEGTIN (EAN): 4058352447291
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9080 | 57W | 160lm/W | DALI 2 | -25..+50°C | IP64 | 1500 | 3.2 | 339.60 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN4EXRGTIN (EAN): 4058352210512
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14140 | 84W | 168lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 3.2 | 332.40 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP11DN4EXRDGTIN (EAN): 4058352418444
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14140 | 84W | 168lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 3.2 | 344.50 |
Licross® 11 Protected extreme HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN4EXREGTIN (EAN): 4058352447314
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14140 | 84W | 168lm/W | DALI 2 | -25..+45°C | IP64 | 1500 | 3.0 | 392.70 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN4F5SGTIN (EAN): 4058352930175
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 15510 | 87W | 178lm/W | DALI 2 | -25..+30°C | IP64 | 1500 | 2.4 | 345.10 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP11DN685F3SGTIN (EAN): 4058352688168
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6500K | CRI > 80 | 8870 | 61W | 146lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 3.5 | 515.90 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN6EXRGTIN (EAN): 4058352241196
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6500K | CRI > 80 | 14070 | 86W | 163lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 2.5 | 332.40 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11MN495GGTIN (EAN): 4058352930182
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 55W | 180lm/W | ON/OFF Multilumen | -35..+40°C | IP64 | 1500 | 2.4 | 276.50 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11MN4GXSGTIN (EAN): 4058352930205
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 16070 | 87W | 184lm/W | ON/OFF Multilumen | -35..+35°C | IP64 | 1500 | 2.4 | 333.30 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP127N485GGTIN (EAN): 4058352930229
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8720 | 49W | 180lm/W | ON/OFF | IP64 | 1500 | 2.4 | 256.90 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP127N58XFGTIN (EAN): 4058352241417
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5000K | CRI > 80 | 8120 | 48W | 171lm/W | ON/OFF | -35..+45°C | IP64 | 1500 | 3.0 | 249.30 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN3CXLGTIN (EAN): 4058352447772
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 12330 | 79 | 88 | 157lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.0 | 321.60 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN48XFGTIN (EAN): 4058352210413
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8180 | 49 | 54 | 167lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.9 | 267.30 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP12CN48XFDGTIN (EAN): 4058352418451
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8180 | 49 | 54 | 167lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.9 | 278.20 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN49XGGTIN (EAN): 4058352930243
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9070 | 49 | 55 | 184lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.4 | 276.50 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN4DXLGTIN (EAN): 4058352265062
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 13270 | 79 | 88 | 169lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.0 | 321.60 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP12CN4DXLDGTIN (EAN): 4058352418475
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 13270 | 79 | 88 | 169lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.1 | 332.40 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN4EXMGTIN (EAN): 4058352930267
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14240 | 78 | 87 | 184lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP64 | 1500 | 2.4 | 333.30 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN58XFGTIN (EAN): 4058352241455
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5000K | CRI > 80 | 8190 | 49 | 54 | 167lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.9 | 267.30 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN68XFGTIN (EAN): 4058352241493
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6500K | CRI > 80 | 8050 | 49 | 55 | 163lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP64 | 1500 | 3.2 | 267.30 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN6DXLGTIN (EAN): 4058352435724
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6500K | CRI > 80 | 13040 | 79 | 88 | 165lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP64 | 1500 | 3.0 | 321.60 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN495GGTIN (EAN): 4058352918494
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 57W | 175lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 2.4 | 288.20 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN495G3CGTIN (EAN): 4058352935248
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 2.9 | 556.90 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN495G3SGTIN (EAN): 4058352935262
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 2.9 | 529.40 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TP12DN495G3S4GTIN (EAN): 4058352935286
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 2.9 | 529.40 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN49XFGTIN (EAN): 4058352265109
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9020 | 56W | 160lm/W | DALI 2 | -25..+40°C | IP64 | 1500 | 2.9 | 278.20 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN49XF3CGTIN (EAN): 4058352484562
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9020 | 60W | 150lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 3.5 | 539.60 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN49XF3SGTIN (EAN): 4058352484586
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9020 | 60W | 150lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 3.5 | 515.50 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TP12DN49XF3S4GTIN (EAN): 4058352676776
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9020 | 60W | 150lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 3.5 | 516.00 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP12DN49XFDGTIN (EAN): 4058352418499
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9020 | 56W | 161lm/W | DALI 2 | -25..+40°C | IP64 | 1500 | 2.9 | 290.20 |
Licross® 11 Protected extreme MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN49XFEGTIN (EAN): 4058352447338
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9020 | 56W | 160lm/W | DALI 2 | -25..+50°C | IP64 | 1500 | 2.9 | 339.60 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN4EXLGTIN (EAN): 4058352210352
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14070 | 86W | 163lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 3.0 | 332.40 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN4EXL3CGTIN (EAN): 4058352485712
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14070 | 90W | 157lm/W | DALI 2 | +5..+30°C | IP64 | 1500 | 3.5 | 592.50 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN4EXL3SGTIN (EAN): 4058352485736
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14070 | 90W | 157lm/W | DALI 2 | +5..+30°C | IP64 | 1500 | 3.5 | 568.40 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TP12DN4EXL3S4GTIN (EAN): 4058352676790
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14070 | 90W | 157lm/W | DALI 2 | +5..+30°C | IP64 | 1500 | 3.5 | 568.00 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP12DN4EXLDGTIN (EAN): 4058352418512
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) | Price (EUR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14070 | 86W | 163lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 3.0 | 344.50 |
