Licross® 11
45 years of experience – trunking Made in Germany perfected in our Licross® trunking system. The one-for-all concept offers a variety of luminaire inserts and functional expansion options for maximum flexibility and future compatibility. With its unique 14 cores, the rail system becomes the backbone of the building infrastructure and is ready for a wide range of applications - today and tomorrow. The luminaire inserts offer outstanding lighting technology with up to 203lm/W or low operating costs as well as SITECO-typical optics technology for the best viewing conditions. Various extensions from sensor to cameras and data transmission open up a broad horizon of applications far from lighting, which create additional added value.
Our performance solution: Licross® 11 is our innovative trunking system with maximum efficiency (up to 203lm/W), service life (up to 100,000h) and flexibility

Performance luminaire insert IP40/IP54
Intro to Productfamily
Data
Varetekst armaturinnsats
Kapslingsklasse IP40; IP50; IP54
Netto lysfluks 4520lm til 16020lm
Fargetemperatur 2700…6500K; 4000K; 5000K; 6500K
Lyseffekt direkte/indirekte symmetrisk bredstrålende
Specials
Configuration & Datasheets
- Licross®-monteringsskinne og monteringskinnetilbehør må bestilles separat
- ved utenpåliggende montasje i tak: reduksjon av maksimalt tillatt omgivelsestemperatur med 5°C
- armaturinnsatser (AC / DC) egnet for gruppe- og sentralbatterisystemer i henhold til EN60598-2-22 (også med AC-drift)
- With AC/DC luminaire inserts, the power supply can be changed to either mains supply operation L1/L2/L3, emergency supply 1 L´/N´ or emergency supply 2 L´´/N´´ by moving the contacts on the connection block
- med armaturinnsatser (AC/DC) har armaturene redusert lysstrøm i DC-drift (se lysteknisk testrapport for DC-drift)
Results
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8840 | 49W | 182lm/W | PÅ/AV | IP54 | 1500 | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9190 | 49 | 55 | 186lm/W | PÅ/AV multilumen, CLOi | -35..+40°C | IP54 | 1500 | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14420 | 78 | 87 | 186lm/W | PÅ/AV multilumen, CLOi | -35..+35°C | IP54 | 1500 | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10110 | 57W | 177lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15460 | 87W | 177lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10160 | 55W | 184lm/W | PÅ/AV multilumen | -35..+40°C | IP54 | 1500 | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 16020 | 87W | 183lm/W | PÅ/AV multilumen | -35..+35°C | IP54 | 1500 | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8840 | 49W | 182lm/W | PÅ/AV | IP40 | 1500 | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8210 | 48W | 173lm/W | PÅ/AV | -35..+45°C | IP40 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8280 | 49 | 54 | 169lm/W | PÅ/AV multilumen, CLOi | -35..+40°C | IP40 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9190 | 49 | 55 | 186lm/W | PÅ/AV multilumen, CLOi | -35..+40°C | IP40 | 1500 | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13440 | 79 | 88 | 171lm/W | PÅ/AV multilumen, CLOi | -35..+40°C | IP40 | 1500 | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14420 | 78 | 87 | 186lm/W | PÅ/AV multilumen, CLOi | -35..+35°C | IP40 | 1500 | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9140 | 56W | 163lm/W | DALI 2 | -25..+40°C | IP40 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10110 | 57W | 177lm/W | DALI 2 | -25..+35°C | IP40 | 1500 | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14250 | 86W | 166lm/W | DALI 2 | -25..+35°C | IP40 | 1500 | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15460 | 87W | 177lm/W | DALI 2 | -25..+30°C | IP40 | 1500 | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10160 | 55W | 184lm/W | PÅ/AV multilumen | -35..+40°C | IP40 | 1500 | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 16020 | 87W | 183lm/W | PÅ/AV multilumen | -35..+35°C | IP40 | 1500 | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8210 | 48W | 173lm/W | PÅ/AV | -35..+45°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8280 | 40 | 54 | 169lm/W | PÅ/AV multilumen, CLOi | -35..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC/DC, betjening på gruppe / sentralbatteri
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8280 | 49 | 54 | 169lm/W | PÅ/AV multilumen, CLOi | -35..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13440 | 79 | 88 | 171lm/W | PÅ/AV multilumen, CLOi | -35..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC/DC, betjening på gruppe / sentralbatteri
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13440 | 79 | 88 | 171lm/W | PÅ/AV multilumen, CLOi | -35..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
6500K | CRI > 80 | 8080 | 49 | 54 | 165lm/W | PÅ/AV multilumen, CLOi | -35..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 4520 | 26W | 171lm/W | DALI 2 | -25..+45°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9140 | 56W | 163lm/W | DALI 2 | -25..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9140 | 60W | 153lm/W | DALI 2 | +5..+35°C | IP50 | 1500 | 4,0 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9140 | 60W | 153lm/W | DALI 2 | +5..+35°C | IP50 | 1500 | 4,0 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9140 | 60W | 153lm/W | DALI 2 | +5..+35°C | IP50 | 1500 | 4,0 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC/DC, betjening på gruppe / sentralbatteri
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9140 | 56W | 163lm/W | DALI 2 | -25..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance extreme MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9140 | 56W | 163lm/W | DALI 2 | -25..+50°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14250 | 86W | 166lm/W | DALI 2 | -25..+35°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14250 | 90W | 159lm/W | DALI 2 | +5..+30°C | IP50 | 1500 | 4,0 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14250 | 90W | 159lm/W | DALI 2 | +5..+30°C | IP50 | 1500 | 4,0 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14250 | 90W | 159lm/W | DALI 2 | +5..+30°C | IP50 | 1500 | 4,0 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC/DC, betjening på gruppe / sentralbatteri
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14250 | 86W | 166lm/W | DALI 2 | -25..+35°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance extreme HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14250 | 86W | 166lm/W | DALI 2 | -25..+45°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
5000K | CRI > 80 | 9150 | 56W | 163lm/W | DALI 2 | -25..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
6500K | CRI > 80 | 9030 | 57W | 159lm/W | DALI 2 | -25..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
6500K | CRI > 80 | 9030 | 61W | 149lm/W | DALI 2 | +5..+35°C | IP50 | 1500 | 4,0 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
6500K | CRI > 80 | 14180 | 88W | 161lm/W | DALI 2 | -25..+30°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance TW, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
2700..6500K | CRI > 80 | 8190 | 57W | 143lm/W | DALI DT8 | -25..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 5580 | 34 | 38 | 166lm/W | DALI 2, CLO | -25..+45°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6560 | 40 | 46 | 166lm/W | DALI 2, CLO | -25..+40°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Fargetemperatur | Fargegjengivelse | Netto lysfluks (lm) | Tilkoblingseffekt | Pnom (W) start levetid | Pnom (W) slutt levetid | Lysutbytte | Styring | ta | Kapslingsklasse | L (mm) | Vekt (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8100 | 49 | 58 | 164lm/W | DALI 2, CLO | -25..+35°C | IP50 | 1500 | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TD167N485GGTIN (EAN): 4058352928820
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 8840 |
Tilkoblingseffekt | 49W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 182lm/W |
Styring | PÅ/AV |
ta | |
Kapslingsklasse | IP54 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TD16CN49XGGTIN (EAN): 4058352928844
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9190 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 49 |
Pnom (W) slutt levetid | 55 |
Lysutbytte | 186lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+40°C |
Kapslingsklasse | IP54 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TD16CN4EXMGTIN (EAN): 4058352928868
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 14420 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 78 |
Pnom (W) slutt levetid | 87 |
Lysutbytte | 186lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+35°C |
Kapslingsklasse | IP54 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TD16DN4AXGGTIN (EAN): 4058352928882
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 10110 |
Tilkoblingseffekt | 57W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 177lm/W |
Styring | DALI 2 |
ta | -25..+35°C |
Kapslingsklasse | IP54 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TD16DN4FXMGTIN (EAN): 4058352928905
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 15460 |
Tilkoblingseffekt | 87W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 177lm/W |
Styring | DALI 2 |
ta | -25..+30°C |
Kapslingsklasse | IP54 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TD16MN4AXGGTIN (EAN): 4058352928929
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 10160 |
Tilkoblingseffekt | 55W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 184lm/W |
Styring | PÅ/AV multilumen |
ta | -35..+40°C |
Kapslingsklasse | IP54 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TD16MN4GXMGTIN (EAN): 4058352928950
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 16020 |
Tilkoblingseffekt | 87W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 183lm/W |
Styring | PÅ/AV multilumen |
ta | -35..+35°C |
Kapslingsklasse | IP54 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM167N485GGTIN (EAN): 4058352929940
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 8840 |
Tilkoblingseffekt | 49W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 182lm/W |
Styring | PÅ/AV |
ta | |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM167N48XFGTIN (EAN): 4058352491928
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 8210 |
Tilkoblingseffekt | 48W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 173lm/W |
Styring | PÅ/AV |
ta | -35..+45°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM16CN48XFGTIN (EAN): 4058352491980
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 8280 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 49 |
Pnom (W) slutt levetid | 54 |
Lysutbytte | 169lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+40°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM16CN49XGGTIN (EAN): 4058352929964
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9190 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 49 |
Pnom (W) slutt levetid | 55 |
Lysutbytte | 186lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+40°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM16CN4DXLGTIN (EAN): 4058352492000
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 13440 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 79 |
Pnom (W) slutt levetid | 88 |
Lysutbytte | 171lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+40°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM16CN4EXMGTIN (EAN): 4058352929988
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 14420 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 78 |
Pnom (W) slutt levetid | 87 |
Lysutbytte | 186lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+35°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM16DN49XFGTIN (EAN): 4058352492086
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9140 |
Tilkoblingseffekt | 56W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 163lm/W |
Styring | DALI 2 |
ta | -25..+40°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM16DN4AXGGTIN (EAN): 4058352930014
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 10110 |
Tilkoblingseffekt | 57W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 177lm/W |
Styring | DALI 2 |
ta | -25..+35°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM16DN4EXLGTIN (EAN): 4058352492109
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 14250 |
Tilkoblingseffekt | 86W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 166lm/W |
Styring | DALI 2 |
ta | -25..+35°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM16DN4FXMGTIN (EAN): 4058352930021
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 15460 |
Tilkoblingseffekt | 87W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 177lm/W |
Styring | DALI 2 |
ta | -25..+30°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM16MN4AXGGTIN (EAN): 4058352930045
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 10160 |
Tilkoblingseffekt | 55W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 184lm/W |
Styring | PÅ/AV multilumen |
ta | -35..+40°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TM16MN4GXMGTIN (EAN): 4058352930069
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 16020 |
Tilkoblingseffekt | 87W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 183lm/W |
Styring | PÅ/AV multilumen |
ta | -35..+35°C |
Kapslingsklasse | IP40 |
L (mm) | 1500 |
Vekt (kg) | 3,1 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS167N48XFGTIN (EAN): 4058352210338
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 8210 |
Tilkoblingseffekt | 48W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 173lm/W |
Styring | PÅ/AV |
ta | -35..+45°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16CN48XFGTIN (EAN): 4058352210857
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 8280 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 40 |
Pnom (W) slutt levetid | 54 |
Lysutbytte | 169lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC/DC, betjening på gruppe / sentralbatteri
Bestillingsnummer: 51TS16CN48XFDGTIN (EAN): 4058352418666
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 8280 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 49 |
Pnom (W) slutt levetid | 54 |
Lysutbytte | 169lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16CN4DXLGTIN (EAN): 4058352265130
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 13440 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 79 |
Pnom (W) slutt levetid | 88 |
Lysutbytte | 171lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC/DC, betjening på gruppe / sentralbatteri
Bestillingsnummer: 51TS16CN4DXLDGTIN (EAN): 4058352418680
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 13440 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 79 |
Pnom (W) slutt levetid | 88 |
Lysutbytte | 171lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16CN68XFGTIN (EAN): 4058352360774
Fargetemperatur | 6500K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 8080 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 49 |
Pnom (W) slutt levetid | 54 |
Lysutbytte | 165lm/W |
Styring | PÅ/AV multilumen, CLOi |
ta | -35..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16DN445FGTIN (EAN): 4058352513651
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 4520 |
Tilkoblingseffekt | 26W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 171lm/W |
Styring | DALI 2 |
ta | -25..+45°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16DN49XFGTIN (EAN): 4058352265093
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9140 |
Tilkoblingseffekt | 56W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 163lm/W |
Styring | DALI 2 |
ta | -25..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Bestillingsnummer: 51TS16DN49XF3CGTIN (EAN): 4058352485767
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9140 |
Tilkoblingseffekt | 60W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 153lm/W |
Styring | DALI 2 |
ta | +5..+35°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 4,0 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Bestillingsnummer: 51TS16DN49XF3SGTIN (EAN): 4058352485798
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9140 |
Tilkoblingseffekt | 60W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 153lm/W |
Styring | DALI 2 |
ta | +5..+35°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 4,0 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Bestillingsnummer: 51TS16DN49XF3S4GTIN (EAN): 4058352676837
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9140 |
Tilkoblingseffekt | 60W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 153lm/W |
Styring | DALI 2 |
ta | +5..+35°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 4,0 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC/DC, betjening på gruppe / sentralbatteri
Bestillingsnummer: 51TS16DN49XFDGTIN (EAN): 4058352418703
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9140 |
Tilkoblingseffekt | 56W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 163lm/W |
Styring | DALI 2 |
ta | -25..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance extreme MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16DN49XFEGTIN (EAN): 4058352447413
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9140 |
Tilkoblingseffekt | 56W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 163lm/W |
Styring | DALI 2 |
ta | -25..+50°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16DN4EXLGTIN (EAN): 4058352265086
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 14250 |
Tilkoblingseffekt | 86W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 166lm/W |
Styring | DALI 2 |
ta | -25..+35°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Bestillingsnummer: 51TS16DN4EXL3CGTIN (EAN): 4058352485804
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 14250 |
Tilkoblingseffekt | 90W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 159lm/W |
Styring | DALI 2 |
ta | +5..+30°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 4,0 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Bestillingsnummer: 51TS16DN4EXL3SGTIN (EAN): 4058352485828
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 14250 |
Tilkoblingseffekt | 90W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 159lm/W |
Styring | DALI 2 |
ta | +5..+30°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 4,0 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Bestillingsnummer: 51TS16DN4EXL3S4GTIN (EAN): 4058352676851
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 14250 |
Tilkoblingseffekt | 90W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 159lm/W |
Styring | DALI 2 |
ta | +5..+30°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 4,0 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC/DC, betjening på gruppe / sentralbatteri
Bestillingsnummer: 51TS16DN4EXLDGTIN (EAN): 4058352418734
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 14250 |
Tilkoblingseffekt | 86W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 166lm/W |
Styring | DALI 2 |
ta | -25..+35°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance extreme HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16DN4EXLEGTIN (EAN): 4058352447437
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 14250 |
Tilkoblingseffekt | 86W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 166lm/W |
Styring | DALI 2 |
ta | -25..+45°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16DN59XFGTIN (EAN): 4058352340493
Fargetemperatur | 5000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9150 |
Tilkoblingseffekt | 56W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 163lm/W |
Styring | DALI 2 |
ta | -25..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16DN69XFGTIN (EAN): 4058352340516
Fargetemperatur | 6500K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9030 |
Tilkoblingseffekt | 57W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 159lm/W |
Styring | DALI 2 |
ta | -25..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC, med batteri, 3h
Bestillingsnummer: 51TS16DN69XF3S4GTIN (EAN): 4058352676875
Fargetemperatur | 6500K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 9030 |
Tilkoblingseffekt | 61W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 149lm/W |
Styring | DALI 2 |
ta | +5..+35°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 4,0 |
Licross® 11 Performance HO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16DN6EXLGTIN (EAN): 4058352389881
Fargetemperatur | 6500K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 14180 |
Tilkoblingseffekt | 88W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 161lm/W |
Styring | DALI 2 |
ta | -25..+30°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance TW, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16TNT8XWGTIN (EAN): 4058352210796
Fargetemperatur | 2700..6500K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 8190 |
Tilkoblingseffekt | 57W |
Pnom (W) start levetid | |
Pnom (W) slutt levetid | |
Lysutbytte | 143lm/W |
Styring | DALI DT8 |
ta | -25..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16VN455FGTIN (EAN): 4058352470503
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 5580 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 34 |
Pnom (W) slutt levetid | 38 |
Lysutbytte | 166lm/W |
Styring | DALI 2, CLO |
ta | -25..+45°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16VN465FGTIN (EAN): 4058352470527
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 6560 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 40 |
Pnom (W) slutt levetid | 46 |
Lysutbytte | 166lm/W |
Styring | DALI 2, CLO |
ta | -25..+40°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
Licross® 11 Performance MO, med spaklås, symmetrisk bredstrålende, AC
Bestillingsnummer: 51TS16VN48XFGTIN (EAN): 4058352466575
Fargetemperatur | 4000K |
---|---|
Fargegjengivelse | CRI > 80 |
Netto lysfluks (lm) | 8100 |
Tilkoblingseffekt | |
Pnom (W) start levetid | 49 |
Pnom (W) slutt levetid | 58 |
Lysutbytte | 164lm/W |
Styring | DALI 2, CLO |
ta | -25..+35°C |
Kapslingsklasse | IP50 |
L (mm) | 1500 |
Vekt (kg) | 3,5 |
