Licross® 21
45 years of experience – trunking Made in Germany perfected in our Licross® trunking system. The one-for-all concept offers a variety of luminaire inserts and functional expansion options for maximum flexibility and future compatibility. With its unique 14 cores, the rail system becomes the backbone of the building infrastructure and is ready for a wide range of applications - today and tomorrow. The luminaire inserts offer outstanding lighting technology for low operating costs as well as SITECO-typical optics technology for the best viewing conditions. Various extensions from sensor to cameras and data transmission open up a broad horizon of applications far from lighting, which create additional added value.
Our core portfolio: Licross® 21 is our trunking system with the highest standards of efficiency (up to 190lm/W), service life (up to 75,000h) and flexibility for your project
Product types
trunking rails and accessories
Recessed luminaire insert IP40/IP54
Opal luminaire insert IP40/IP54
Protected luminaire insert IP54/IP64
Performance luminaire insert IP40/IP54
Silica® luminaire insert IP40
functional insert
emergency lighting luminaire insert IP40
Highbay 21 midi/maxi for Licross® trunking rail
Monsun® 31 for Licross®
Spot 31 for Licross®
Opal luminaire insert IP40/IP54
Intro product family
Key data
Article luminaire insert
Protection rating IP40; IP54
Net luminous flux 2750lm to 22050lm
Colour temperature 3000K; 4000K
Lighting effect direct symmetric diffuse distribution, with ceiling illumination
Special features
A simple path to demand-oriented illumination
Easy to install thanks to the click system
Extremely efficient operation for low energy consumption and operating costs, high luminous flux up to 22050lm for high mounting heights
Configuration & data sheets
- please order Licross® trunking rail or trunking rail accessories separately
- versions with colour temperature 3000K, 5000K or 6500K on request
- with ceiling surface mounting: reducing of maximum allowable ambient temperature of 5°C
Results
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1D7N44XG GTIN (EAN): 4058352055250
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 4400 | 25W | 178lm/W | ON/OFF | -35..+50°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1D7N46XG GTIN (EAN): 4058352055274
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 6200 | 35W | 178lm/W | ON/OFF | -35..+50°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1D7N48XG GTIN (EAN): 4058352055298
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8360 | 48W | 175lm/W | ON/OFF | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DCN485G GTIN (EAN): 4058352056707
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8780 | 50 | 61 | 176lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP54, AC
Order No.: 52TE1DCN4CXM GTIN (EAN): 4058352056714
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 12300 | 68 | 83 | 180lm/W | ON/OFF Multilumen, CLOi | -35..+30°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DDN445G GTIN (EAN): 4058352051955
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 4500 | 26W | 174lm/W | DALI 2 | -25..+45°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DDN46XG GTIN (EAN): 4058352051979
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 6320 | 36W | 175lm/W | DALI 2 | -25..+40°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DDN495G GTIN (EAN): 4058352052006
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9750 | 58W | 168lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP54, AC
Order No.: 52TE1DDN4E5M GTIN (EAN): 4058352052013
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14560 | 85W | 172lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DDV495G GTIN (EAN): 4058352055311
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9500 | 54W | 177lm/W | DALI 2 | -25..+40°C | IP54 | 2250 | 2.2 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DDV4E5G GTIN (EAN): 4058352055335
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14620 | 85W | 171lm/W | DALI 2 | -25..+35°C | IP54 | 2250 | 2.2 |
Licross® 21 recessed opal HO, with spring catch, IP54, AC
Order No.: 52TE1DDV4L2M GTIN (EAN): 4058352055366
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 22050 | 126W | 176lm/W | DALI 2 | -40..+30°C | IP54 | 2250 | 2.2 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DMN46XG GTIN (EAN): 4058352056738
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 6270 | 35W | 179lm/W | ON/OFF Multilumen | -35..+50°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DMN4AXG GTIN (EAN): 4058352056752
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 10420 | 61W | 172lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP54, AC
Order No.: 52TE1DMN4E5M GTIN (EAN): 4058352056776
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14660 | 83W | 176lm/W | ON/OFF Multilumen | -35..+30°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DVN445G GTIN (EAN): 4058352052037
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 4500 | 26 | 30 | 174lm/W | DALI 2, CLO | -25..+45°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DVN465G GTIN (EAN): 4058352052051
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 6500 | 38 | 45 | 172lm/W | DALI 2, CLO | -25..+40°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DVN48XG GTIN (EAN): 4069025071835
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8000 | 47 | 56 | 171lm/W | DALI 2, CLO | -25..+35°C | IP54 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1D7N44XG GTIN (EAN): 4058352055373
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 4400 | 25W | 178lm/W | ON/OFF | -35..+50°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1D7N46XG GTIN (EAN): 4058352055397
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 6200 | 35W | 178lm/W | ON/OFF | -35..+50°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1D7N48XG GTIN (EAN): 4058352055410
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8360 | 48W | 175lm/W | ON/OFF | -35..+40°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DCN485G GTIN (EAN): 4058352056790
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 8780 | 50 | 61 | 176lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP40, AC
Order No.: 52TL1DCN4CXM GTIN (EAN): 4058352056813
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 12300 | 68 | 83 | 180lm/W | ON/OFF Multilumen, CLOi | -35..+30°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDN425G GTIN (EAN): 4069025021724
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 2750 | 16W | 170lm/W | DALI 2 | -25..+50°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDN445G GTIN (EAN): 4058352049891
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 4500 | 26W | 174lm/W | DALI 2 | -25..+45°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDN46XG GTIN (EAN): 4058352049914
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 6320 | 36W | 175lm/W | DALI 2 | -25..+40°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDN495G GTIN (EAN): 4058352049938
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9750 | 58W | 168lm/W | DALI 2 | -25..+35°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP40, AC
Order No.: 52TL1DDN4E5M GTIN (EAN): 4058352049952
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14560 | 85W | 172lm/W | DALI 2 | -25..+30°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDV495G GTIN (EAN): 4058352055434
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9500 | 54W | 177lm/W | DALI 2 | -25..+40°C | IP40 | 2250 | 2.2 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDV4E5G GTIN (EAN): 4069025021748
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14620 | 85W | 171lm/W | DALI 2 | -25..+35°C | IP40 | 2250 | 2.2 |
Licross® 21 recessed opal HO, with spring catch, IP40, AC
Order No.: 52TL1DDV4L2M GTIN (EAN): 4069025021762
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 22050 | 126W | 176lm/W | DALI 2 | -40..+30°C | IP40 | 2250 | 2.2 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DMN46XG GTIN (EAN): 4058352056837
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 6270 | 35W | 179lm/W | ON/OFF Multilumen | -35..+50°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DMN4AXG GTIN (EAN): 4058352056851
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 10420 | 61W | 172lm/W | ON/OFF Multilumen | -35..+40°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP40, AC
Order No.: 52TL1DMN4E5M GTIN (EAN): 4058352056875
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 14660 | 83W | 176lm/W | ON/OFF Multilumen | -35..+30°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DMN36XG GTIN (EAN): 4069025253286
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 3000K | CRI > 80 | 6300 | 37.5W | 168lm/W | ON/OFF Multilumen | -35..+50°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC/DC, operation on group/central battery
Order No.: 52TL1DDN445GD GTIN (EAN): 4069025478658
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 4500 | 26W | 174lm/W | DALI 2 | -25..+45°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC, with self-test function according to EN 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 52TL1DDN495G3S GTIN (EAN): 4069025479532
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9750 | 62W | 158lm/W | DALI 2 | +5..+35°C | IP40 | 1500 | 1.9 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC/DC, operation on group/central battery
Order No.: 52TL1DDN495GD GTIN (EAN): 4069025478672
| Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4000K | CRI > 80 | 9750 | 58W | 168lm/W | DALI 2 | -25..+35°C | IP40 | 1500 | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1D7N44XGGTIN (EAN): 4058352055250
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 4400 |
| Connected load | 25W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 178lm/W |
| Control | ON/OFF |
| ta | -35..+50°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1D7N46XGGTIN (EAN): 4058352055274
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 6200 |
| Connected load | 35W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 178lm/W |
| Control | ON/OFF |
| ta | -35..+50°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1D7N48XGGTIN (EAN): 4058352055298
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 8360 |
| Connected load | 48W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 175lm/W |
| Control | ON/OFF |
| ta | -35..+40°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DCN485GGTIN (EAN): 4058352056707
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 8780 |
| Connected load | |
| Pnom (W) begin service life | 50 |
| Pnom (W) end service life | 61 |
| Luminous efficacy | 176lm/W |
| Control | ON/OFF Multilumen, CLOi |
| ta | -35..+40°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP54, AC
Order No.: 52TE1DCN4CXMGTIN (EAN): 4058352056714
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 12300 |
| Connected load | |
| Pnom (W) begin service life | 68 |
| Pnom (W) end service life | 83 |
| Luminous efficacy | 180lm/W |
| Control | ON/OFF Multilumen, CLOi |
| ta | -35..+30°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DDN445GGTIN (EAN): 4058352051955
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 4500 |
| Connected load | 26W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 174lm/W |
| Control | DALI 2 |
| ta | -25..+45°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DDN46XGGTIN (EAN): 4058352051979
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 6320 |
| Connected load | 36W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 175lm/W |
| Control | DALI 2 |
| ta | -25..+40°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DDN495GGTIN (EAN): 4058352052006
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 9750 |
| Connected load | 58W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 168lm/W |
| Control | DALI 2 |
| ta | -25..+35°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP54, AC
Order No.: 52TE1DDN4E5MGTIN (EAN): 4058352052013
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 14560 |
| Connected load | 85W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 172lm/W |
| Control | DALI 2 |
| ta | -25..+30°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DDV495GGTIN (EAN): 4058352055311
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 9500 |
| Connected load | 54W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 177lm/W |
| Control | DALI 2 |
| ta | -25..+40°C |
| Protection rating | IP54 |
| L (mm) | 2250 |
| Wt. (kg) | 2.2 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DDV4E5GGTIN (EAN): 4058352055335
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 14620 |
| Connected load | 85W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 171lm/W |
| Control | DALI 2 |
| ta | -25..+35°C |
| Protection rating | IP54 |
| L (mm) | 2250 |
| Wt. (kg) | 2.2 |
Licross® 21 recessed opal HO, with spring catch, IP54, AC
Order No.: 52TE1DDV4L2MGTIN (EAN): 4058352055366
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 22050 |
| Connected load | 126W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 176lm/W |
| Control | DALI 2 |
| ta | -40..+30°C |
| Protection rating | IP54 |
| L (mm) | 2250 |
| Wt. (kg) | 2.2 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DMN46XGGTIN (EAN): 4058352056738
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 6270 |
| Connected load | 35W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 179lm/W |
| Control | ON/OFF Multilumen |
| ta | -35..+50°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DMN4AXGGTIN (EAN): 4058352056752
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 10420 |
| Connected load | 61W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 172lm/W |
| Control | ON/OFF Multilumen |
| ta | -35..+40°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP54, AC
Order No.: 52TE1DMN4E5MGTIN (EAN): 4058352056776
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 14660 |
| Connected load | 83W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 176lm/W |
| Control | ON/OFF Multilumen |
| ta | -35..+30°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DVN445GGTIN (EAN): 4058352052037
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 4500 |
| Connected load | |
| Pnom (W) begin service life | 26 |
| Pnom (W) end service life | 30 |
| Luminous efficacy | 174lm/W |
| Control | DALI 2, CLO |
| ta | -25..+45°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DVN465GGTIN (EAN): 4058352052051
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 6500 |
| Connected load | |
| Pnom (W) begin service life | 38 |
| Pnom (W) end service life | 45 |
| Luminous efficacy | 172lm/W |
| Control | DALI 2, CLO |
| ta | -25..+40°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP54, AC
Order No.: 52TE1DVN48XGGTIN (EAN): 4069025071835
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 8000 |
| Connected load | |
| Pnom (W) begin service life | 47 |
| Pnom (W) end service life | 56 |
| Luminous efficacy | 171lm/W |
| Control | DALI 2, CLO |
| ta | -25..+35°C |
| Protection rating | IP54 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1D7N44XGGTIN (EAN): 4058352055373
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 4400 |
| Connected load | 25W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 178lm/W |
| Control | ON/OFF |
| ta | -35..+50°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1D7N46XGGTIN (EAN): 4058352055397
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 6200 |
| Connected load | 35W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 178lm/W |
| Control | ON/OFF |
| ta | -35..+50°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1D7N48XGGTIN (EAN): 4058352055410
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 8360 |
| Connected load | 48W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 175lm/W |
| Control | ON/OFF |
| ta | -35..+40°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DCN485GGTIN (EAN): 4058352056790
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 8780 |
| Connected load | |
| Pnom (W) begin service life | 50 |
| Pnom (W) end service life | 61 |
| Luminous efficacy | 176lm/W |
| Control | ON/OFF Multilumen, CLOi |
| ta | -35..+40°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP40, AC
Order No.: 52TL1DCN4CXMGTIN (EAN): 4058352056813
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 12300 |
| Connected load | |
| Pnom (W) begin service life | 68 |
| Pnom (W) end service life | 83 |
| Luminous efficacy | 180lm/W |
| Control | ON/OFF Multilumen, CLOi |
| ta | -35..+30°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDN425GGTIN (EAN): 4069025021724
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 2750 |
| Connected load | 16W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 170lm/W |
| Control | DALI 2 |
| ta | -25..+50°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDN445GGTIN (EAN): 4058352049891
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 4500 |
| Connected load | 26W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 174lm/W |
| Control | DALI 2 |
| ta | -25..+45°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDN46XGGTIN (EAN): 4058352049914
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 6320 |
| Connected load | 36W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 175lm/W |
| Control | DALI 2 |
| ta | -25..+40°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDN495GGTIN (EAN): 4058352049938
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 9750 |
| Connected load | 58W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 168lm/W |
| Control | DALI 2 |
| ta | -25..+35°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP40, AC
Order No.: 52TL1DDN4E5MGTIN (EAN): 4058352049952
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 14560 |
| Connected load | 85W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 172lm/W |
| Control | DALI 2 |
| ta | -25..+30°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDV495GGTIN (EAN): 4058352055434
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 9500 |
| Connected load | 54W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 177lm/W |
| Control | DALI 2 |
| ta | -25..+40°C |
| Protection rating | IP40 |
| L (mm) | 2250 |
| Wt. (kg) | 2.2 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DDV4E5GGTIN (EAN): 4069025021748
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 14620 |
| Connected load | 85W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 171lm/W |
| Control | DALI 2 |
| ta | -25..+35°C |
| Protection rating | IP40 |
| L (mm) | 2250 |
| Wt. (kg) | 2.2 |
Licross® 21 recessed opal HO, with spring catch, IP40, AC
Order No.: 52TL1DDV4L2MGTIN (EAN): 4069025021762
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 22050 |
| Connected load | 126W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 176lm/W |
| Control | DALI 2 |
| ta | -40..+30°C |
| Protection rating | IP40 |
| L (mm) | 2250 |
| Wt. (kg) | 2.2 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DMN46XGGTIN (EAN): 4058352056837
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 6270 |
| Connected load | 35W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 179lm/W |
| Control | ON/OFF Multilumen |
| ta | -35..+50°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DMN4AXGGTIN (EAN): 4058352056851
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 10420 |
| Connected load | 61W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 172lm/W |
| Control | ON/OFF Multilumen |
| ta | -35..+40°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal HO, with spring catch, IP40, AC
Order No.: 52TL1DMN4E5MGTIN (EAN): 4058352056875
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 14660 |
| Connected load | 83W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 176lm/W |
| Control | ON/OFF Multilumen |
| ta | -35..+30°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC
Order No.: 52TL1DMN36XGGTIN (EAN): 4069025253286
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 6300 |
| Connected load | 37.5W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 168lm/W |
| Control | ON/OFF Multilumen |
| ta | -35..+50°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC/DC, operation on group/central battery
Order No.: 52TL1DDN445GDGTIN (EAN): 4069025478658
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 4500 |
| Connected load | 26W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 174lm/W |
| Control | DALI 2 |
| ta | -25..+45°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC, with self-test function according to EN 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 52TL1DDN495G3SGTIN (EAN): 4069025479532
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 9750 |
| Connected load | 62W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 158lm/W |
| Control | DALI 2 |
| ta | +5..+35°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.9 |
Licross® 21 recessed opal MO, with spring catch, IP40, AC/DC, operation on group/central battery
Order No.: 52TL1DDN495GDGTIN (EAN): 4069025478672
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 80 |
| Net luminous flux (lm) | 9750 |
| Connected load | 58W |
| Pnom (W) begin service life | |
| Pnom (W) end service life | |
| Luminous efficacy | 168lm/W |
| Control | DALI 2 |
| ta | -25..+35°C |
| Protection rating | IP40 |
| L (mm) | 1500 |
| Wt. (kg) | 1.4 |
