Licross® 11/21 for local control

ProducttypesConfiguration & Datasheets

Stay flexible: The modular system of Licross® enables any configuration of the sensors according to your individual requirements. Changes in use are also easy for the Licross® sensors, so today's high-bay warehouse can already be a free logistics space tomorrow. Regardless of the application, you will always receive the optimal, economical solution thanks to specialized sensors. At the same time, Licross® sensors are true energy saving miracles: with daylight-dependent control you save up to 20%, with movement-dependent control even up to 80% in energy costs. 45 years of experience – trunking Made in Germany perfected in our Licross® trunking system. The one-for-all concept offers a variety of luminaire inserts and functional expansion options for maximum flexibility and future compatibility. With its unique 14 cores, the rail system becomes the backbone of the building infrastructure and is ready for a wide range of applications - today and tomorrow. The luminaire inserts offer outstanding lighting technology with up to 200lm/W for low operating costs as well as SITECO-typical optics technology for the best viewing conditions. Various extensions from sensor to UVC air disinfection device open up a broad horizon of applications far from lighting, which create additional added value.

Simple standalone solution

Siteco Connect 31 Logistic - for magazines and corridors

Intro to Productfamily

Data

Utstyr master; slave
Varetekst Sensor-Head PR1-M; Sensor-Head PR1-S; Interface MS; Interface MD; Interface S

Specials

Multi-sensor for use in magazines and corridors
Multi-sensor with very high detection quality guarantees reliable detection of large areas with few sensors. With one sensor, up to 800m² can be detected depending on presence
Sensor specially developed for the application. Circular detection area
Master already contains the complete intelligence for room-related lighting control. This reduces complexity and saves space
Basic energy-saving functions such as motion detection, daylight threshold value and fully automatic operation reduce energy costs and CO2 consumption
Inventory light deactivates the sensor function during the inventory period and controls the lights to 100% illuminance
Sensor planning in Relux saves time and gives you the security of planning sensor detection correctly

Configuration & Datasheets

Utstyr

Tillegg

  • ved kontakt med DALI-linje 1 velegnet fra 7-tråds kabling
  • with 14-core wiring, tapping between DALI line 1 and DALI line 2 can be slided tool-free
  • adaption to on-site conditions via 90° rotatable sensor interface
  • for hver utvidelsessensor reduseres antall kontrollerbare HF-er med 3 stykk
  • en sensorenhet består av et sensorhode og et grensesnitt

Results

Licross® Interface, master, koblingsbar

Bestillingsnummer: 56TL1FAMA GTIN (EAN): 4058352400524
VaretekstBruksområdeStyringMontasjehøydeBevegelsens deteksjonsområdeDimensjon (mm)ta
Interface MS PÅ/AV 500x96-20..+50°C

Licross® Interface, master, dimbar

Bestillingsnummer: 56TL1FCMA GTIN (EAN): 4058352373873
VaretekstBruksområdeStyringMontasjehøydeBevegelsens deteksjonsområdeDimensjon (mm)ta
Interface MD DALI 500x96-20..+50°C

Licross® Interface, slave, dimbar

Bestillingsnummer: 56TL1FCSA GTIN (EAN): 4058352373880
VaretekstBruksområdeStyringMontasjehøydeBevegelsens deteksjonsområdeDimensjon (mm)ta
Interface S DALI 2 500x96-20..+50°C

SITECO Connect, slave, dimbar

Bestillingsnummer: 59US1HXSPR1A GTIN (EAN): 4058352363997
VaretekstBruksområdeStyringMontasjehøydeBevegelsens deteksjonsområdeDimensjon (mm)ta
Sensor-Head PR1-Skorridor og magasinDALI 22,5..5mtangential maks. 23x6m95x95-20..+50°C

SITECO Connect, master, koblingsbar, dimbar

Bestillingsnummer: 59US1HXMPR1A GTIN (EAN): 4058352363850
VaretekstBruksområdeStyringMontasjehøydeBevegelsens deteksjonsområdeDimensjon (mm)ta
Sensor-Head PR1-Mkorridor og magasin 2,5..5mmaks. 23x6m95x95-20..+50°C

Licross® Interface, master, koblingsbar

Bestillingsnummer: 56TL1FAMAGTIN (EAN): 4058352400524

VaretekstInterface MS
Bruksområde
StyringPÅ/AV
Montasjehøyde
Bevegelsens deteksjonsområde
Dimensjon (mm)500x96
ta-20..+50°C

Licross® Interface, master, dimbar

Bestillingsnummer: 56TL1FCMAGTIN (EAN): 4058352373873

VaretekstInterface MD
Bruksområde
StyringDALI
Montasjehøyde
Bevegelsens deteksjonsområde
Dimensjon (mm)500x96
ta-20..+50°C

Licross® Interface, slave, dimbar

Bestillingsnummer: 56TL1FCSAGTIN (EAN): 4058352373880

VaretekstInterface S
Bruksområde
StyringDALI 2
Montasjehøyde
Bevegelsens deteksjonsområde
Dimensjon (mm)500x96
ta-20..+50°C

SITECO Connect, slave, dimbar

Bestillingsnummer: 59US1HXSPR1AGTIN (EAN): 4058352363997

VaretekstSensor-Head PR1-S
Bruksområdekorridor og magasin
StyringDALI 2
Montasjehøyde2,5..5m
Bevegelsens deteksjonsområdetangential maks. 23x6m
Dimensjon (mm)95x95
ta-20..+50°C

SITECO Connect, master, koblingsbar, dimbar

Bestillingsnummer: 59US1HXMPR1AGTIN (EAN): 4058352363850

VaretekstSensor-Head PR1-M
Bruksområdekorridor og magasin
Styring
Montasjehøyde2,5..5m
Bevegelsens deteksjonsområdemaks. 23x6m
Dimensjon (mm)95x95
ta-20..+50°C
