Sirius®
A revolutionary floodlight system for sports and area lighting with unrivaled performance, efficiency and light quality. The high-performance floodlight Sirius® sets records in terms of performance with up to 309,000lm. Thanks to our full cut-off technology, the impossible becomes possible and stray light is cut off through perfect light bundling. The light immission is only < 3% in vertical alignment - in horizontal even 0%. With a TLCI value of 96 at 5,700K, realistic colour rendering is guaranteed - for broadcasters this means minimal post-processing effort. The ECGs of the modular driver system allow the 4 LED modules to be controlled separately – also via DALI/DMX.
A dream of a floodlight
Producttypes
Sirius® 500
Intro to Productfamily
Data
Varetekst lyshode
Lyseffekt direkte asymmetrisk strålende; direkte symmetrisk strålende
Lysfordeling ECO-RS14; AREA-PL52
Netto lysfluks 55860lm til 66122lm
Fargetemperatur 5000K; 5700K
Styring effektreduksjon
Specials
Configuration & Datasheets
- on request also available as RGBW version
Results
Sirius® 500, lyshode, AREA-PL52, asymmetrisk strålende
| Fargetemperatur | Fargegjengivelse | TLCI | Lysfluks | Tilkoblingseffekt | Lysutbytte | Styring | Vekt (kg) |
|---|---|---|---|---|---|---|---|
| 5700K | CRI > 95 | TLCI ≥ 96 | 55860lm | 493W | 113lm/W | effektreduksjon, DALI | 16,0 |
Sirius® 500, lyshode, AREA-PL52, asymmetrisk strålende
| Fargetemperatur | Fargegjengivelse | TLCI | Lysfluks | Tilkoblingseffekt | Lysutbytte | Styring | Vekt (kg) |
|---|---|---|---|---|---|---|---|
| 5000K | CRI > 90 | TLCI ≥ 87 | 59785lm | 493W | 121lm/W | effektreduksjon, DALI | 16,0 |
Sirius® 500, lyshode, ECO-RS14, symmetrisk strålende
| Fargetemperatur | Fargegjengivelse | TLCI | Lysfluks | Tilkoblingseffekt | Lysutbytte | Styring | Vekt (kg) |
|---|---|---|---|---|---|---|---|
| 5000K | CRI > 90 | TLCI ≥ 87 | 66122lm | 493W | 134lm/W | effektreduksjon, DALI | 16,0 |
Sirius® 500, lyshode, AREA-PL52, asymmetrisk strålende
Bestillingsnummer: 5XA7100W5ZS00100XXGTIN (EAN): 4058352448861
| Fargetemperatur | 5700K |
|---|---|
| Fargegjengivelse | CRI > 95 |
| TLCI | TLCI ≥ 96 |
| Lysfluks | 55860lm |
| Tilkoblingseffekt | 493W |
| Lysutbytte | 113lm/W |
| Styring | effektreduksjon, DALI |
| Vekt (kg) | 16,0 |
Sirius® 500, lyshode, AREA-PL52, asymmetrisk strålende
Bestillingsnummer: 5XA7100W4ZS00101XXGTIN (EAN): 4058352448847
| Fargetemperatur | 5000K |
|---|---|
| Fargegjengivelse | CRI > 90 |
| TLCI | TLCI ≥ 87 |
| Lysfluks | 59785lm |
| Tilkoblingseffekt | 493W |
| Lysutbytte | 121lm/W |
| Styring | effektreduksjon, DALI |
| Vekt (kg) | 16,0 |
Sirius® 500, lyshode, ECO-RS14, symmetrisk strålende
Bestillingsnummer: 5XA7100W4ZS00103XXGTIN (EAN): 4058352448854
| Fargetemperatur | 5000K |
|---|---|
| Fargegjengivelse | CRI > 90 |
| TLCI | TLCI ≥ 87 |
| Lysfluks | 66122lm |
| Tilkoblingseffekt | 493W |
| Lysutbytte | 134lm/W |
| Styring | effektreduksjon, DALI |
| Vekt (kg) | 16,0 |
Mandatory accessory
| Bestillingsnummer: 5XA71000XFGTIN (EAN): 4058352357774 | Show details |
