Sirius®

ProducttypesConfiguration & Datasheets

A revolutionary floodlighting system for sports and planar lighting with unmatched performance, efficiency and quality of light. The Sirius® high power floodlight scores top marks in terms of lumen output with up to 309,000lm. Thanks to our full-cut-off technology, the impossible becomes possible and light spill is cut off by perfect light focusing. Light immission is < 3% in the vertical axis – with a mere 0% in the horizontal. With a TLCI value of 96 at 5700K, true-to-life colour rendering is guaranteed – for broadcasters this means minimal post-production complexity. The ECGs of the modular driver system enable separate control of the four LED modules – also via DALI/DMX. The Sirius® high-end solution is safeguarded fourfold, and even if one of the ECGs fails the luminaire still generates 75% of its lumen output. We offer Sirius® in three versions with wattages of up to 2000W, up to 1000W and up to 500W.

Sirius® A dream of a floodlight.

Data

Opis žaromet
Svetlobni učinek direktna asimetrična porazdelitev; direktna simetrična porazdelitev
Porazdelitev svetilnosti ECO-RS14; AREA-PL52
Neto svetlobni tok 55860lm do 61784lm
Barvna temperatura 5000K; 5700K
Upravljanje redukcija moči

Specials

Highly efficient thanks to silver reflectors (ECO RS) or glass lenses (AREA PL52) for low energy consumption and operating costs
Extremely powerful with up to 66,000lm with a long service life of up to 100,000 hours and minimal luminous flux degradation for the use of high maintenance factors
With a TLCI value of 96 at 5700K for true-to-life color rendering and minimum post-editing work for broadcasters
DALI ECG integrated into housing, with the cable already pre-assembled with a plug-socket system for time-saving assembly

Configuration & Datasheets

  • luminaire constructed according to modular principle and only available in single components; a complete luminaire consists of: 1x light head (consisting of 2 LED units) + 1x mounting bracket + 1x ECG unit + 1x mounting accessory for ECG unit + if necessary 1x connection box for light head (if ECG unit is mounted remotely); for your individual assembly of a complete floodlight please order the appropriate components separately
  • the ECG unit can be mounted on the mounting bracket or elsewhere (cable length of light head to ECG unit: max. 150m); please order suitable mounting accessory for ECG unit separately, depending on the mounting situation
  • when mounting the ECG unit at another location, please order the connection box for the light head separately
  • with 'DMX' light control: please separately order divisible cable gland for inserting the DMX cable into the ECG unit (DMX cable with pre-assembled RJ45 plug connection)
  • on request also available as RGBW version

Results

Sirius® 500, žaromet, AREA-PL52, asimetrična porazdelitev

Oznaka za naročilo: 5XA7100W5ZS00100XXGTIN (EAN): 4058352448861
Barvna temperaturaBarvni videzTLCIUpravljanje razsvetljavePriključna močSvetlobni izkoristekUpravljanjeMasa (kg)
5700KCRI > 95TLCI ≥ 9655860lm493W113lm/Wredukcija moči, DALI16,0

Sirius® 500, žaromet, AREA-PL52, asimetrična porazdelitev

Oznaka za naročilo: 5XA7100W4ZS00101XXGTIN (EAN): 4058352448847
Barvna temperaturaBarvni videzTLCIUpravljanje razsvetljavePriključna močSvetlobni izkoristekUpravljanjeMasa (kg)
5000KCRI > 90TLCI ≥ 8759785lm493W121lm/Wredukcija moči, DALI16,0

Sirius® 500, žaromet, ECO-RS14, simetrična porazdelitev

Oznaka za naročilo: 5XA7100W5ZS00102XXGTIN (EAN): 4058352448878
Barvna temperaturaBarvni videzTLCIUpravljanje razsvetljavePriključna močSvetlobni izkoristekUpravljanjeMasa (kg)
5700KCRI > 95TLCI ≥ 9661784lm493W125lm/Wredukcija moči, DALI16,0

Sirius® 500, žaromet, AREA-PL52, asimetrična porazdelitev

Oznaka za naročilo: 5XA7100W5ZS00100XXGTIN (EAN): 4058352448861

Barvna temperatura5700K
Barvni videzCRI > 95
TLCITLCI ≥ 96
Upravljanje razsvetljave55860lm
Priključna moč493W
Svetlobni izkoristek113lm/W
Upravljanjeredukcija moči, DALI
Masa (kg)16,0

Sirius® 500, žaromet, AREA-PL52, asimetrična porazdelitev

Oznaka za naročilo: 5XA7100W4ZS00101XXGTIN (EAN): 4058352448847

Barvna temperatura5000K
Barvni videzCRI > 90
TLCITLCI ≥ 87
Upravljanje razsvetljave59785lm
Priključna moč493W
Svetlobni izkoristek121lm/W
Upravljanjeredukcija moči, DALI
Masa (kg)16,0

Sirius® 500, žaromet, ECO-RS14, simetrična porazdelitev

Oznaka za naročilo: 5XA7100W5ZS00102XXGTIN (EAN): 4058352448878

Barvna temperatura5700K
Barvni videzCRI > 95
TLCITLCI ≥ 96
Upravljanje razsvetljave61784lm
Priključna moč493W
Svetlobni izkoristek125lm/W
Upravljanjeredukcija moči, DALI
Masa (kg)16,0

Mandatory accessory

Opisnosilno streme, za 1 LED enoto (1/2 svetlobne glave)EP1 kosMasa (kg)4,7Oznaka za naročilo: 5XA71000XFGTIN (EAN): 4058352357774Show details
