Sirius®

ProducttypesConfiguration & Datasheets

A revolutionary floodlight system for sports and area lighting with unrivaled performance, efficiency and light quality. The high-performance floodlight Sirius® sets records in terms of performance with up to 309,000lm. Thanks to our full cut-off technology, the impossible becomes possible and stray light is cut off through perfect light bundling. The light immission is only < 3% in vertical alignment - in horizontal even 0%. With a TLCI value of 96 at 5,700K, realistic colour rendering is guaranteed - for broadcasters this means minimal post-processing effort. The ECGs of the modular driver system allow the 4 LED modules to be controlled separately – also via DALI/DMX.

A dream of a floodlight

Data

Article floodlight
Lighting effect direct asymmetric distribution; direct symmetric distribution
Light distribution ECO-RS14; AREA-PL52
Net luminous flux 55860lm to 66122lm
Colour temperature 5000K; 5700K
Control power reduction

Specials

Highly efficient thanks to silver reflectors (ECO RS) or glass lenses (AREA PL52) for low energy consumption and operating costs
Extremely powerful with up to 66,000lm with a long service life of up to 100,000 hours and minimal luminous flux degradation for the use of high maintenance factors
With a TLCI value of 96 at 5700K for true-to-life color rendering and minimum post-editing work for broadcasters
DALI ECG integrated into housing, with the cable already pre-assembled with a plug-socket system for time-saving assembly

Configuration & Datasheets

  • on request also available as RGBW version

Results

Sirius® 500, floodlight, AREA-PL52, asymmetric distribution

Order No.: 5XA7100W5ZS00100XXGTIN (EAN): 4058352448861
Colour temperatureColour renderingTLCILuminous fluxConnected loadLuminous efficacyControlWt. (kg)
5700KCRI > 95TLCI ≥ 9655860lm493W113lm/Wpower reduction, DALI16.0

Sirius® 500, floodlight, AREA-PL52, asymmetric distribution

Order No.: 5XA7100W4ZS00101XXGTIN (EAN): 4058352448847
Colour temperatureColour renderingTLCILuminous fluxConnected loadLuminous efficacyControlWt. (kg)
5000KCRI > 90TLCI ≥ 8759785lm493W121lm/Wpower reduction, DALI16.0

Sirius® 500, floodlight, ECO-RS14, symmetric distribution

Order No.: 5XA7100W5ZS00102XXGTIN (EAN): 4058352448878
Colour temperatureColour renderingTLCILuminous fluxConnected loadLuminous efficacyControlWt. (kg)
5700KCRI > 95TLCI ≥ 9661784lm493W125lm/Wpower reduction, DALI16.0

Sirius® 500, floodlight, ECO-RS14, symmetric distribution

Order No.: 5XA7100W4ZS00103XXGTIN (EAN): 4058352448854
Colour temperatureColour renderingTLCILuminous fluxConnected loadLuminous efficacyControlWt. (kg)
5000KCRI > 90TLCI ≥ 8766122lm493W134lm/Wpower reduction, DALI16.0

Sirius® 500, floodlight, AREA-PL52, asymmetric distribution

Order No.: 5XA7100W5ZS00100XXGTIN (EAN): 4058352448861

Colour temperature5700K
Colour renderingCRI > 95
TLCITLCI ≥ 96
Luminous flux55860lm
Connected load493W
Luminous efficacy113lm/W
Controlpower reduction, DALI
Wt. (kg)16.0

Sirius® 500, floodlight, AREA-PL52, asymmetric distribution

Order No.: 5XA7100W4ZS00101XXGTIN (EAN): 4058352448847

Colour temperature5000K
Colour renderingCRI > 90
TLCITLCI ≥ 87
Luminous flux59785lm
Connected load493W
Luminous efficacy121lm/W
Controlpower reduction, DALI
Wt. (kg)16.0

Sirius® 500, floodlight, ECO-RS14, symmetric distribution

Order No.: 5XA7100W5ZS00102XXGTIN (EAN): 4058352448878

Colour temperature5700K
Colour renderingCRI > 95
TLCITLCI ≥ 96
Luminous flux61784lm
Connected load493W
Luminous efficacy125lm/W
Controlpower reduction, DALI
Wt. (kg)16.0

Sirius® 500, floodlight, ECO-RS14, symmetric distribution

Order No.: 5XA7100W4ZS00103XXGTIN (EAN): 4058352448854

Colour temperature5000K
Colour renderingCRI > 90
TLCITLCI ≥ 87
Luminous flux66122lm
Connected load493W
Luminous efficacy134lm/W
Controlpower reduction, DALI
Wt. (kg)16.0

Mandatory accessory

Articlemounting bracket, for 1 LED unit (1/2 luminaire head)PU1 pc.Wt. (kg)4.7Order No.: 5XA71000XFGTIN (EAN): 4058352357774Show details
