59LN201

Order No.: 59LN201
Remember articleRemember article

Article multi-sensor
Product name Siluette 21
Protection rating IP20
Impact resistance ??
Weight 0.1kg

Siluette 21, multi-sensor, installation type: surface-mounted, mains connection: 220..240V, 50/60Hz, housing, length: 149mm, height: 28mm, multi-sensor, protection rating (complete): IP20, insulation class (complete): insulation class II (safety insulation), certification: CE, permissible operating ambient temperature: -20..+60°C, packaging unit: 1 piece

Downloads

Technical product information
Data for applications

Product details

Key data

Product type multi-sensor
Product name Siluette 21
Order No. 59LN201

Certificates, Standards

Protection rating IP20
Insulation class insulation class II (safety insulation)
Temperature range (operation) -20..+60°C
Certification, designation CE

Mounting

Mounting method, mounting location surface-mounted, to the luminaire
Mounting height 3m

Electrical connection

Nominal voltage 220..240V, 50/60Hz

Dimensions, Weight

Length 149mm
Height 28mm
Weight 0.1kg

Inputs

1x HF sensor
Connection HF sensor
Detection range ø10m
Option switching time adjustable between 5 seconds - 30 minutes
Feature for motion detection

1x light sensor
Connection light sensor
Option daylight threshold adjustable from 2..50lx

Product type
multi-sensor

Product name
Siluette 21

Order No.
59LN201

Protection rating
IP20

Insulation class
insulation class II (safety insulation)

Temperature range (operation)
-20..+60°C

Certification, designation
CE

Mounting method, mounting location
surface-mounted, to the luminaire

Mounting height
3m

Nominal voltage
220..240V, 50/60Hz

Length
149mm

Height
28mm

Weight
0.1kg

1x HF sensor

Connection
HF sensor

Detection range
ø10m

Option
switching time adjustable between 5 seconds - 30 minutes

Feature
for motion detection

1x light sensor

Connection
light sensor

Option
daylight threshold adjustable from 2..50lx
