59UA3VT

Order No.: 59UA3VT
Remember articleRemember article

Article amplifier
Product name SITECO Connect Audio
Rated input power 120W
Weight 3.6kg

SITECO Connect Audio, amplifier, installation type: for table mounting, desktop mixer power amplifier,mains connection: 100..240V, AC, 50/60Hz, rated input power: 120W, housing, of metal/plastic, coated, black, length: 375mm, width: 210mm, height: 53mm, certification: CE, packaging unit: 1 piece

Downloads

Technical product information
Data for applications

Product details

Key data

System family Licross
Product type amplifier
Product name SITECO Connect Audio
Order No. 59UA3VT

Rated input power

Supplement

Certificates, Standards

Certification, designation CE

Material, Colour

housing metal/plastic, coated, black
Colour specification black

Mounting

Mounting method, mounting location for table mounting

Electrical connection

Nominal voltage 100..240V, 50/60Hz, AC

Dimensions, Weight

Length 375mm
Width 210mm
Height 53mm
Weight 3.6kg

Inputs

MIC -60dBV, LINE -20dBV
Feature MIC/LINE selectable, 2.2kΩ, electronically balanced

MIC -60dBV, LINE -20dBV
Feature MIC/LINE selectable, 2.2kΩ, electronically balanced

LINE -20dBV, 10kΩ
Connection Cinch

LINE -20dBV, 10kΩ
Connection Cinch

System family
Licross

Product type
amplifier

Product name
SITECO Connect Audio

Order No.
59UA3VT

Certification, designation
CE

housing
metal/plastic, coated, black

Colour specification
black

Mounting method, mounting location
for table mounting

Nominal voltage
100..240V, 50/60Hz, AC

Length
375mm

Width
210mm

Height
53mm

Weight
3.6kg

MIC -60dBV, LINE -20dBV

Feature
MIC/LINE selectable, 2.2kΩ, electronically balanced

MIC -60dBV, LINE -20dBV

Feature
MIC/LINE selectable, 2.2kΩ, electronically balanced

LINE -20dBV, 10kΩ

Connection
Cinch

LINE -20dBV, 10kΩ

Connection
Cinch
