Order No.: 5EA3BGL02

Article sensor
Product name SITECO Connect Wireless
Protection rating IP65
Weight 0.8kg

SITECO Connect WirelessMast Box Motion 2xPIR GPS Low, sensor, communication: 2.4GHz, local mesh radio network, DALI, control: local setting and operation with USB stick, by movement, optionally via radio push button, by time, by timer, by weekday, with radio clock, sensor technology: 2 PIR movement sensors, GPS, automatic adjustment of the DALI dimming curve, optionally adjustable manually, controls one DALI ECG individually or up to 9 DALI ECGs via broadcast, installation type: surface-mounted, installation location: to mast, of plastic, voltage: 230V, voltage type: AC, GPS, radio, 2.4GHz, protection rating (complete): IP65, certification: CE, packaging unit: 1 piece, metal fastening straps not included in delivery

Downloads

Technical product information
Data for applications

Product details


Key data

Product type sensor
Product name SITECO Connect Wireless
Order No. 5EA3BGL02


Control


Certificates, Standards

Protection rating IP65
Temperature range (operation) -25..+80°C
Certification, designation CE


Material, Colour

housing plastic, dark grey


Mounting

Mounting method, mounting location surface-mounted, to mast
Mounting height 0..6m


Electrical connection

Nominal voltage 230V, AC


Dimensions, Weight

Weight 0.8kg

Product type
sensor

Product name
SITECO Connect Wireless

Order No.
5EA3BGL02

Protection rating
IP65

Temperature range (operation)
-25..+80°C

Certification, designation
CE

housing
plastic, dark grey

Mounting method, mounting location
surface-mounted, to mast

Mounting height
0..6m

Nominal voltage
230V, AC

Weight
0.8kg
