5EA6TEF03

Order No.: 5EA6TEF03
Remember articleRemember article

Article SITECO Service Box
Product name Street Light Control
Protection rating IP54
Weight 3.5kg

Street Light Control, SITECO Service Box, control gear: DALI, control: digital communication interface, Bluetooth 4.0, with system connector: plug/socket, 4-pole, DC, housing, of plastic, dark grey, single-sided rubberized impact protection, SITECO Service Box, control via: SITECO Digital Interface, protection rating (complete): IP54, insulation class (complete): insulation class II (safety insulation), certification: CE, permissible operating ambient temperature for outdoor applications: 0..+50°C, packaging unit: 1 piece

Downloads

Technical product information
Data for applications

Product details

Key data

Product type SITECO Service Box
Product name Street Light Control
Order No. 5EA6TEF03

Lamps

Supplement with ON/OFF switch, with connection cable, battery operation 4x AA

Operating device

Control DALI
Equipment digital communication interface, Bluetooth 4.0

Certificates, Standards

Protection rating IP54
Insulation class insulation class II (safety insulation)
Temperature range (operation) 0..+50°C
Certification, designation CE

Material, Colour

housing plastic, dark grey

Electrical connection

Connection system connector: plug/socket, 4-pole
Battery supply incl. 4x Mignon AA/LR6 batteries
Feature external power supply 5LZ905402 needed

Dimensions, Weight

Weight 3.5kg

Outputs

1x SDI (SITECO Digital Interface)
Connection pin terminal
Feature operational status display

1x status LED
Feature status LED

Software

Required software iQ app

Product type
SITECO Service Box

Product name
Street Light Control

Order No.
5EA6TEF03

Supplement
with ON/OFF switch, with connection cable, battery operation 4x AA

Control
DALI

Equipment
digital communication interface, Bluetooth 4.0

Protection rating
IP54

Insulation class
insulation class II (safety insulation)

Temperature range (operation)
0..+50°C

Certification, designation
CE

housing
plastic, dark grey

Connection
system connector: plug/socket, 4-pole

Battery supply
incl. 4x Mignon AA/LR6 batteries

Feature
external power supply 5LZ905402 needed

Weight
3.5kg

1x SDI (SITECO Digital Interface)

Connection
pin terminal

Feature
operational status display

1x status LED

Feature
status LED

Required software
iQ app
