5LZ904315

Order No.: 5LZ904315
Remember articleRemember article

Article lighting management components
Product name SITECO Connect
Protection rating IP20
Weight 0.1kg

SITECO Connectcontroller, master, local control - self-sufficient standalone sensors, dimmable, installation type: recessed, installation location: in the ceiling, of plastic, protection rating (complete): IP20, insulation class (complete): insulation class II (safety insulation), certification: CE, voltage: 220..240V, voltage type: AC, 1 x push button input, 1 x service push button, 1 x DALI, packaging unit: 1 piece

Downloads

Technical product information
Data for applications

Product details

Key data

System family SITECO Connect 32
Product type lighting management components
Product name SITECO Connect
Order No. 5LZ904315

Control

Certificates, Standards

Protection rating IP20
Insulation class insulation class II (safety insulation)
Temperature range (operation) -20..+60°C
Certification, designation CE

Material, Colour

housing plastic, pure white (RAL 9010)
Colour specification pure white (RAL 9010)

Mounting

Mounting method, mounting location recessed, in the ceiling
Supplement only suitable for use in indoor areas

Electrical connection

Connection terminal, 2-pole, max. 1.5mm²
Nominal voltage 220..240V, 50/60Hz, AC

Dimensions, Weight

Length 108mm
Width 30mm
Height 21mm
Weight 0.1kg

Inputs

1x push button input
Connection screw terminal, 2-pole, max. 1.5mm²
Feature zero-potential

1x service push button
Option reset

Outputs

1x DALI
Connection screw terminal, 2-pole, max. 1.5mm²
System current DALI current 96mA
Feature DALI, master function, broadcast addressing, max. 32 DALI ECGs

System family
SITECO Connect 32

Product type
lighting management components

Product name
SITECO Connect

Order No.
5LZ904315

Protection rating
IP20

Insulation class
insulation class II (safety insulation)

Temperature range (operation)
-20..+60°C

Certification, designation
CE

housing
plastic, pure white (RAL 9010)

Colour specification
pure white (RAL 9010)

Mounting method, mounting location
recessed, in the ceiling

Supplement
only suitable for use in indoor areas

Connection
terminal, 2-pole, max. 1.5mm²

Nominal voltage
220..240V, 50/60Hz, AC

Length
108mm

Width
30mm

Height
21mm

Weight
0.1kg

1x push button input

Connection
screw terminal, 2-pole, max. 1.5mm²

Feature
zero-potential

1x service push button

Option
reset

1x DALI

Connection
screw terminal, 2-pole, max. 1.5mm²

System current
DALI current 96mA

Feature
DALI, master function, broadcast addressing, max. 32 DALI ECGs
