Licross® 11
45 years of experience – trunking Made in Germany perfected in our Licross® trunking system. The one-for-all concept offers a variety of luminaire inserts and functional expansion options for maximum flexibility and future compatibility. With its unique 14 cores, the rail system becomes the backbone of the building infrastructure and is ready for a wide range of applications - today and tomorrow. The luminaire inserts offer outstanding lighting technology with up to 209lm/W or low operating costs as well as SITECO-typical optics technology for the best viewing conditions. Various extensions from sensor to cameras and data transmission open up a broad horizon of applications far from lighting, which create additional added value.
Our performance solution: Licross® 11 is our innovative trunking system with maximum efficiency (up to 209lm/W), service life (up to 100,000h) and flexibility
Protected luminaire insert IP54/IP64
Intro to ProductfamilyData
Article luminaire insert
Protection rating IP50; IP54; IP64
Net luminous flux 5500lm to 16110lm
Colour temperature 2700…6500K; 4000K; 5000K; 6500K
Lighting effect direct symmetric extremely narrow distribution; direct symmetric narrow distribution; direct symmetric wide distribution
Specials
Configuration & Datasheets
- Please order Licross® Trunking trunking rail and trunking rail accessories separately.
- with ceiling surface mounting: reducing of maximum allowable ambient temperature of 5°C
- luminaire inserts (AC/DC) suiatble for group and central battery systems according to EN60598-2-22 (even at AC operation)
- With AC/DC luminaire inserts, the power supply can be changed to either mains supply operation L1/L2/L3, emergency supply 1 L´/N´ or emergency supply 2 L´´/N´´ by moving the contacts on the connection block
- with luminaire inserts (AC/DC), luminaires use reduced luminous flux with DC operation (see photometric report for DC operation)
Results
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8680 | 49W | 179lm/W | ON/OFF | -25..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9030 | 49 | 55 | 183lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14460 | 78 | 87 | 186lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9930 | 57W | 174lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15510 | 87W | 178lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 55W | 180lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 16070 | 87W | 184lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8720 | 49W | 180lm/W | ON/OFF | -25..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9070 | 49 | 55 | 184lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14240 | 78 | 87 | 184lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 57W | 175lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15270 | 87W | 175lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15270 | 91W | 168lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15270 | 91W | 168lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15270 | 91W | 168lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10030 | 55W | 181lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15820 | 87W | 181lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 5500 | 34 | 39 | 162lm/W | DALI 2, CLO | -25..+45°C | IP54 | 1500 | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6510 | 40 | 47 | 163lm/W | DALI 2, CLO | -25..+40°C | IP54 | 1500 | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 7910 | 49 | 56 | 161lm/W | DALI 2, CLO | -25..+35°C | IP54 | 1500 | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14500 | 78 | 87 | 187lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15550 | 87W | 178lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 16110 | 87W | 184lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8190 | 49W | 169lm/W | ON/OFF | -25..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8520 | 49 | 55 | 172lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13520 | 78 | 87 | 174lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9370 | 57W | 164lm/W | DALI 2 | -25..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9370 | 61W | 154lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9370 | 61W | 154lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9370 | 61W | 154lm/W | DALI 2 | +5..+35°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected extreme MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9370 | 57W | 164lm/W | DALI 2 | -40..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14500 | 87W | 166lm/W | DALI 2 | -25..+30°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14500 | 91W | 159lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14500 | 91W | 159lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14500 | 91W | 159lm/W | DALI 2 | +5..+30°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected extreme HO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14500 | 87W | 166lm/W | DALI 2 | -40..+40°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9420 | 55W | 170lm/W | ON/OFF Multilumen | -35..+40°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15020 | 87W | 172lm/W | ON/OFF Multilumen | -35..+35°C | IP54 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8680 | 49W | 179lm/W | ON/OFF | -25..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8140 | 49 | 54 | 166lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8140 | 49 | 54 | 166lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9030 | 49 | 55 | 183lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13240 | 76 | 86 | 173lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13240 | 76 | 86 | 173lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14460 | 78 | 87 | 186lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
5000K | CRI > 80 | 8150 | 49 | 54 | 166lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.7 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 57W | 174lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9080 | 57W | 160lm/W | DALI 2 | -25..+40°C | IP64 | 1500 | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9080 | 57W | 160lm/W | DALI 2 | -25..+40°C | IP64 | 1500 | 3.2 |
Licross® 11 Protected extreme MO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9080 | 57W | 160lm/W | DALI 2 | -25..+50°C | IP64 | 1500 | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14140 | 84W | 168lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14140 | 84W | 168lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 3.2 |
Licross® 11 Protected extreme HO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14140 | 84W | 168lm/W | DALI 2 | -25..+45°C | IP64 | 1500 | 3.0 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15510 | 87W | 178lm/W | DALI 2 | -25..+30°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 55W | 180lm/W | ON/OFF Multilumen | -35..+40°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 16070 | 87W | 184lm/W | ON/OFF Multilumen | -35..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8720 | 49W | 180lm/W | ON/OFF | -25..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
5000K | CRI > 80 | 8120 | 48W | 171lm/W | ON/OFF | -35..+45°C | IP64 | 1500 | 3.0 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8180 | 49 | 54 | 167lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8180 | 49 | 54 | 167lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9070 | 49 | 55 | 184lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13270 | 79 | 88 | 169lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.0 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13270 | 79 | 88 | 169lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.1 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14240 | 78 | 87 | 184lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
5000K | CRI > 80 | 8190 | 49 | 54 | 167lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 57W | 175lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 61W | 164lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected extreme MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 57W | 175lm/W | DALI 2 | -40..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9020 | 56W | 160lm/W | DALI 2 | -25..+40°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9020 | 60W | 150lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 3.5 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9020 | 60W | 150lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 3.5 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9020 | 60W | 150lm/W | DALI 2 | +5..+35°C | IP64 | 1500 | 3.5 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9020 | 56W | 161lm/W | DALI 2 | -25..+40°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected extreme MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9020 | 56W | 160lm/W | DALI 2 | -25..+50°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14070 | 86W | 163lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 3.0 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14070 | 90W | 157lm/W | DALI 2 | +5..+30°C | IP64 | 1500 | 3.5 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14070 | 90W | 157lm/W | DALI 2 | +5..+30°C | IP64 | 1500 | 3.5 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14070 | 90W | 157lm/W | DALI 2 | +5..+30°C | IP64 | 1500 | 3.5 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14070 | 86W | 163lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 3.0 |
Licross® 11 Protected extreme HO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14070 | 86W | 163lm/W | DALI 2 | -25..+45°C | IP64 | 1500 | 3.0 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15270 | 87W | 175lm/W | DALI 2 | -25..+30°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15270 | 91W | 168lm/W | DALI 2 | +5..+30°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15270 | 91W | 168lm/W | DALI 2 | +5..+30°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15270 | 91W | 168lm/W | DALI 2 | +5..+30°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected extreme HO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15270 | 87W | 175lm/W | DALI 2 | -40..+40°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
5000K | CRI > 80 | 9030 | 56W | 161lm/W | DALI 2 | -25..+40°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
5000K | CRI > 80 | 14100 | 86W | 164lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 10030 | 55W | 181lm/W | ON/OFF Multilumen | -35..+40°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15820 | 87W | 181lm/W | ON/OFF Multilumen | -35..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected TW, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
2700..6500K | CRI > 80 | 8100 | 57W | 141lm/W | DALI DT8 | -25..+40°C | IP64 | 1500 | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13280 | 76 | 86 | 174lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric extremely narrow distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13280 | 76 | 86 | 174lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP64 | 1500 | 3.1 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14500 | 78 | 87 | 187lm/W | ON/OFF Multilumen, CLOi | -35..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14170 | 84W | 168lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 14170 | 84W | 168lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 15550 | 87W | 178lm/W | DALI 2 | -25..+30°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 16110 | 87W | 184lm/W | ON/OFF Multilumen | -35..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6910 | 43 | 50 | 162lm/W | DALI 2, CLO | -25..+40°C | IP50 | 1500 | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP50, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6910 | 43 | 50 | 162lm/W | DALI 2, CLO | -25..+40°C | IP50 | 1500 | 2.8 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13190 | 78 | 84 | 169lm/W | DALI 2, CLO | -25..+35°C | IP50 | 1500 | 2.8 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP50, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13190 | 78 | 84 | 169lm/W | DALI 2, CLO | -25..+35°C | IP50 | 1500 | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 7690 | 48W | 162lm/W | ON/OFF | -35..+45°C | IP50 | 1500 | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 7680 | 49 | 54 | 157lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP50 | 1500 | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 7680 | 49 | 54 | 157lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP50 | 1500 | 2.8 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 12600 | 79 | 88 | 160lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP50 | 1500 | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 12600 | 79 | 88 | 160lm/W | ON/OFF Multilumen, CLOi | -35..+40°C | IP50 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8470 | 56W | 151lm/W | DALI 2 | -25..+40°C | IP50 | 1500 | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8470 | 60W | 141lm/W | DALI 2 | +5..+35°C | IP50 | 1500 | 4.0 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8470 | 60W | 141lm/W | DALI 2 | +5..+35°C | IP50 | 1500 | 4.0 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8470 | 56W | 151lm/W | DALI 2 | -25..+40°C | IP50 | 1500 | 3.2 |
Licross® 11 Protected extreme MO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8470 | 56W | 151lm/W | DALI 2 | -25..+50°C | IP50 | 1500 | 2.5 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13360 | 86W | 155lm/W | DALI 2 | -25..+35°C | IP50 | 1500 | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13360 | 86W | 155lm/W | DALI 2 | -25..+35°C | IP50 | 1500 | 2.9 |
Licross® 11 Protected extreme HO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 13360 | 86W | 155lm/W | DALI 2 | -25..+45°C | IP50 | 1500 | 3.0 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
5000K | CRI > 80 | 8480 | 56W | 151lm/W | DALI 2 | -25..+40°C | IP50 | 1500 | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
5000K | CRI > 80 | 13380 | 86W | 155lm/W | DALI 2 | -25..+35°C | IP50 | 1500 | 2.9 |
Licross® 11 Protected TW, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
2700..6500K | CRI > 80 | 7740 | 57W | 135lm/W | DALI DT8 | -25..+40°C | IP50 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 5510 | 36 | 41 | 154lm/W | DALI 2, CLO | -25..+45°C | IP50 | 1500 | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6530 | 43 | 50 | 153lm/W | DALI 2, CLO | -25..+40°C | IP50 | 1500 | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6530 | 43 | 50 | 153lm/W | DALI 2, CLO | -25..+40°C | IP50 | 1500 | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 7700 | 51 | 57 | 152lm/W | DALI 2, CLO | -25..+35°C | IP50 | 1500 | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 12430 | 79 | 89 | 157lm/W | DALI 2, CLO | -25..+30°C | IP50 | 1500 | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 12430 | 79 | 89 | 157lm/W | DALI 2, CLO | -25..+30°C | IP50 | 1500 | 3.2 |
Licross® 21 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 5500 | 32 | 38 | 170lm/W | DALI 2, CLO | -25..+45°C | IP54 | 1500 | 2.9 |
Licross® 21 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 6500 | 39 | 46 | 167lm/W | DALI 2, CLO | -25..+45°C | IP54 | 1500 | 2.9 |
Licross® 21 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 8000 | 48 | 58 | 166lm/W | DALI 2, CLO | -25..+40°C | IP54 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
6500K | CRI > 80 | 9680 | 57W | 170lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
6500K | CRI > 80 | 9730 | 57W | 170lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Colour temperature | Colour rendering | Net luminous flux (lm) | Connected load | Pnom (W) begin service life | Pnom (W) end service life | Luminous efficacy | Control | ta | Protection rating | L (mm) | Wt. (kg) |
---|---|---|---|---|---|---|---|---|---|---|---|
4000K | CRI > 80 | 9980 | 57W | 175lm/W | DALI 2 | -25..+35°C | IP64 | 1500 | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD117N485GGTIN (EAN): 4058352928493
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8680 |
Connected load | 49W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 179lm/W |
Control | ON/OFF |
ta | -25..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11CN49XGGTIN (EAN): 4058352928509
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9030 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 55 |
Luminous efficacy | 183lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11CN4EXSGTIN (EAN): 4058352928523
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14460 |
Connected load | |
Pnom (W) begin service life | 78 |
Pnom (W) end service life | 87 |
Luminous efficacy | 186lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11DN495GGTIN (EAN): 4058352928547
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9930 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 174lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11DN4F5SGTIN (EAN): 4058352928561
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15510 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 178lm/W |
Control | DALI 2 |
ta | -25..+30°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11MN495GGTIN (EAN): 4058352928585
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 55W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 180lm/W |
Control | ON/OFF Multilumen |
ta | -35..+40°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP54, AC
Order No.: 51TD11MN4GXSGTIN (EAN): 4058352928608
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 16070 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 184lm/W |
Control | ON/OFF Multilumen |
ta | -35..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD127N485GGTIN (EAN): 4058352928622
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8720 |
Connected load | 49W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 180lm/W |
Control | ON/OFF |
ta | -25..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12CN49XGGTIN (EAN): 4058352928653
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9070 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 55 |
Luminous efficacy | 184lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12CN4EXMGTIN (EAN): 4058352928660
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14240 |
Connected load | |
Pnom (W) begin service life | 78 |
Pnom (W) end service life | 87 |
Luminous efficacy | 184lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12DN495GGTIN (EAN): 4058352928684
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 175lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD12DN495G3CGTIN (EAN): 4058352934623
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 61W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 164lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD12DN495G3SGTIN (EAN): 4058352934647
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 61W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 164lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TD12DN495G3S4GTIN (EAN): 4058352934661
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 61W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 164lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12DN4FXMGTIN (EAN): 4058352928707
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15270 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 175lm/W |
Control | DALI 2 |
ta | -25..+30°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD12DN4FXM3CGTIN (EAN): 4058352934685
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15270 |
Connected load | 91W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD12DN4FXM3SGTIN (EAN): 4058352934708
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15270 |
Connected load | 91W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TD12DN4FXM3S4GTIN (EAN): 4058352934739
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15270 |
Connected load | 91W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12MN4AXGGTIN (EAN): 4058352928721
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 10030 |
Connected load | 55W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 181lm/W |
Control | ON/OFF Multilumen |
ta | -35..+40°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12MN4F5MGTIN (EAN): 4058352928745
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15820 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 181lm/W |
Control | ON/OFF Multilumen |
ta | -35..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12VN455FGTIN (EAN): 4058352749975
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 5500 |
Connected load | |
Pnom (W) begin service life | 34 |
Pnom (W) end service life | 39 |
Luminous efficacy | 162lm/W |
Control | DALI 2, CLO |
ta | -25..+45°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12VN465FGTIN (EAN): 4058352749999
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 6510 |
Connected load | |
Pnom (W) begin service life | 40 |
Pnom (W) end service life | 47 |
Luminous efficacy | 163lm/W |
Control | DALI 2, CLO |
ta | -25..+40°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD12VN475FGTIN (EAN): 4058352750025
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 7910 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 56 |
Luminous efficacy | 161lm/W |
Control | DALI 2, CLO |
ta | -25..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP54, AC
Order No.: 51TD13CN4E5SGTIN (EAN): 4058352928769
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14500 |
Connected load | |
Pnom (W) begin service life | 78 |
Pnom (W) end service life | 87 |
Luminous efficacy | 187lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP54, AC
Order No.: 51TD13DN4F5SGTIN (EAN): 4058352928790
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15550 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 178lm/W |
Control | DALI 2 |
ta | -25..+30°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP54, AC
Order No.: 51TD13MN4GXSGTIN (EAN): 4058352928806
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 16110 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 184lm/W |
Control | ON/OFF Multilumen |
ta | -35..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1B7N48XGGTIN (EAN): 4058352928967
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8190 |
Connected load | 49W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 169lm/W |
Control | ON/OFF |
ta | -25..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BCN485GGTIN (EAN): 4058352918296
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8520 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 55 |
Luminous efficacy | 172lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BCN4D5MGTIN (EAN): 4058352918319
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13520 |
Connected load | |
Pnom (W) begin service life | 78 |
Pnom (W) end service life | 87 |
Luminous efficacy | 174lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BDN49XGGTIN (EAN): 4058352918333
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9370 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 164lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD1BDN49XG3CGTIN (EAN): 4058352938461
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9370 |
Connected load | 61W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 154lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD1BDN49XG3SGTIN (EAN): 4058352938485
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9370 |
Connected load | 61W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 154lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TD1BDN49XG3S4GTIN (EAN): 4058352938508
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9370 |
Connected load | 61W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 154lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected extreme MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BDN49XGEGTIN (EAN): 4058352988909
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9370 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 164lm/W |
Control | DALI 2 |
ta | -40..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BDN4E5MGTIN (EAN): 4058352918357
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14500 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 166lm/W |
Control | DALI 2 |
ta | -25..+30°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD1BDN4E5M3CGTIN (EAN): 4058352938522
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14500 |
Connected load | 91W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 159lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TD1BDN4E5M3SGTIN (EAN): 4058352938553
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14500 |
Connected load | 91W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 159lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TD1BDN4E5M3S4GTIN (EAN): 4058352938560
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14500 |
Connected load | 91W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 159lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected extreme HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BDN4E5MEGTIN (EAN): 4058352988923
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14500 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 166lm/W |
Control | DALI 2 |
ta | -40..+40°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BMN49XGGTIN (EAN): 4058352928981
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9420 |
Connected load | 55W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 170lm/W |
Control | ON/OFF Multilumen |
ta | -35..+40°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 51TD1BMN4FXMGTIN (EAN): 4058352929001
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15020 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 172lm/W |
Control | ON/OFF Multilumen |
ta | -35..+35°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP117N485GGTIN (EAN): 4058352930083
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8680 |
Connected load | 49W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 179lm/W |
Control | ON/OFF |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11CN48XFGTIN (EAN): 4058352210574
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8140 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 54 |
Luminous efficacy | 166lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP11CN48XFDGTIN (EAN): 4058352418376
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8140 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 54 |
Luminous efficacy | 166lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11CN49XGGTIN (EAN): 4058352930106
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9030 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 55 |
Luminous efficacy | 183lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11CN4DXRGTIN (EAN): 4058352265055
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13240 |
Connected load | |
Pnom (W) begin service life | 76 |
Pnom (W) end service life | 86 |
Luminous efficacy | 173lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP11CN4DXRDGTIN (EAN): 4058352418390
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13240 |
Connected load | |
Pnom (W) begin service life | 76 |
Pnom (W) end service life | 86 |
Luminous efficacy | 173lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11CN4EXSGTIN (EAN): 4058352930120
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14460 |
Connected load | |
Pnom (W) begin service life | 78 |
Pnom (W) end service life | 87 |
Luminous efficacy | 186lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11CN58XFGTIN (EAN): 4058352447758
Colour temperature | 5000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8150 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 54 |
Luminous efficacy | 166lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.7 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN495GGTIN (EAN): 4058352930144
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 174lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN49XFGTIN (EAN): 4058352297957
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9080 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 160lm/W |
Control | DALI 2 |
ta | -25..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP11DN49XFDGTIN (EAN): 4058352418413
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9080 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 160lm/W |
Control | DALI 2 |
ta | -25..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected extreme MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN49XFEGTIN (EAN): 4058352447291
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9080 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 160lm/W |
Control | DALI 2 |
ta | -25..+50°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN4EXRGTIN (EAN): 4058352210512
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14140 |
Connected load | 84W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP11DN4EXRDGTIN (EAN): 4058352418444
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14140 |
Connected load | 84W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected extreme HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN4EXREGTIN (EAN): 4058352447314
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14140 |
Connected load | 84W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | -25..+45°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.0 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN4F5SGTIN (EAN): 4058352930175
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15510 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 178lm/W |
Control | DALI 2 |
ta | -25..+30°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11MN495GGTIN (EAN): 4058352930182
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 55W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 180lm/W |
Control | ON/OFF Multilumen |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11MN4GXSGTIN (EAN): 4058352930205
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 16070 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 184lm/W |
Control | ON/OFF Multilumen |
ta | -35..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP127N485GGTIN (EAN): 4058352930229
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8720 |
Connected load | 49W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 180lm/W |
Control | ON/OFF |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP127N58XFGTIN (EAN): 4058352241417
Colour temperature | 5000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8120 |
Connected load | 48W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 171lm/W |
Control | ON/OFF |
ta | -35..+45°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.0 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN48XFGTIN (EAN): 4058352210413
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8180 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 54 |
Luminous efficacy | 167lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP12CN48XFDGTIN (EAN): 4058352418451
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8180 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 54 |
Luminous efficacy | 167lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN49XGGTIN (EAN): 4058352930243
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9070 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 55 |
Luminous efficacy | 184lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN4DXLGTIN (EAN): 4058352265062
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13270 |
Connected load | |
Pnom (W) begin service life | 79 |
Pnom (W) end service life | 88 |
Luminous efficacy | 169lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.0 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP12CN4DXLDGTIN (EAN): 4058352418475
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13270 |
Connected load | |
Pnom (W) begin service life | 79 |
Pnom (W) end service life | 88 |
Luminous efficacy | 169lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.1 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN4EXMGTIN (EAN): 4058352930267
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14240 |
Connected load | |
Pnom (W) begin service life | 78 |
Pnom (W) end service life | 87 |
Luminous efficacy | 184lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12CN58XFGTIN (EAN): 4058352241455
Colour temperature | 5000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8190 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 54 |
Luminous efficacy | 167lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN495GGTIN (EAN): 4058352918494
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 175lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN495G3CGTIN (EAN): 4058352935248
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 61W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 164lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN495G3SGTIN (EAN): 4058352935262
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 61W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 164lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TP12DN495G3S4GTIN (EAN): 4058352935286
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 61W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 164lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected extreme MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN495GEGTIN (EAN): 4058352988954
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 175lm/W |
Control | DALI 2 |
ta | -40..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN49XFGTIN (EAN): 4058352265109
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9020 |
Connected load | 56W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 160lm/W |
Control | DALI 2 |
ta | -25..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN49XF3CGTIN (EAN): 4058352484562
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9020 |
Connected load | 60W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 150lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.5 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN49XF3SGTIN (EAN): 4058352484586
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9020 |
Connected load | 60W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 150lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.5 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TP12DN49XF3S4GTIN (EAN): 4058352676776
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9020 |
Connected load | 60W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 150lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.5 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP12DN49XFDGTIN (EAN): 4058352418499
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9020 |
Connected load | 56W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 161lm/W |
Control | DALI 2 |
ta | -25..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected extreme MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN49XFEGTIN (EAN): 4058352447338
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9020 |
Connected load | 56W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 160lm/W |
Control | DALI 2 |
ta | -25..+50°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN4EXLGTIN (EAN): 4058352210352
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14070 |
Connected load | 86W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 163lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.0 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN4EXL3CGTIN (EAN): 4058352485712
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14070 |
Connected load | 90W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 157lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.5 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN4EXL3SGTIN (EAN): 4058352485736
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14070 |
Connected load | 90W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 157lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.5 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TP12DN4EXL3S4GTIN (EAN): 4058352676790
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14070 |
Connected load | 90W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 157lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.5 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP12DN4EXLDGTIN (EAN): 4058352418512
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14070 |
Connected load | 86W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 163lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.0 |
Licross® 11 Protected extreme HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN4EXLEGTIN (EAN): 4058352447352
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14070 |
Connected load | 86W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 163lm/W |
Control | DALI 2 |
ta | -25..+45°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.0 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN4FXMGTIN (EAN): 4058352918517
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15270 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 175lm/W |
Control | DALI 2 |
ta | -25..+30°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with central self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN4FXM3CGTIN (EAN): 4058352935309
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15270 |
Connected load | 91W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TP12DN4FXM3SGTIN (EAN): 4058352935323
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15270 |
Connected load | 91W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TP12DN4FXM3S4GTIN (EAN): 4058352935354
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15270 |
Connected load | 91W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | +5..+30°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected extreme HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN4FXMEGTIN (EAN): 4058352988961
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15270 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 175lm/W |
Control | DALI 2 |
ta | -40..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN59XFGTIN (EAN): 4058352375587
Colour temperature | 5000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9030 |
Connected load | 56W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 161lm/W |
Control | DALI 2 |
ta | -25..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN5EXLGTIN (EAN): 4058352241554
Colour temperature | 5000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14100 |
Connected load | 86W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 164lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12MN4AXGGTIN (EAN): 4058352930281
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 10030 |
Connected load | 55W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 181lm/W |
Control | ON/OFF Multilumen |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12MN4F5MGTIN (EAN): 4058352930304
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15820 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 181lm/W |
Control | ON/OFF Multilumen |
ta | -35..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected TW, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12TNT8XWGTIN (EAN): 4058352210291
Colour temperature | 2700..6500K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8100 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 141lm/W |
Control | DALI DT8 |
ta | -25..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC
Order No.: 51TP13CN4DXRGTIN (EAN): 4058352265079
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13280 |
Connected load | |
Pnom (W) begin service life | 76 |
Pnom (W) end service life | 86 |
Luminous efficacy | 174lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric extremely narrow distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP13CN4DXRDGTIN (EAN): 4058352418536
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13280 |
Connected load | |
Pnom (W) begin service life | 76 |
Pnom (W) end service life | 86 |
Luminous efficacy | 174lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 3.1 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC
Order No.: 51TP13CN4E5SGTIN (EAN): 4058352930335
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14500 |
Connected load | |
Pnom (W) begin service life | 78 |
Pnom (W) end service life | 87 |
Luminous efficacy | 187lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC
Order No.: 51TP13DN4EXRGTIN (EAN): 4058352210611
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14170 |
Connected load | 84W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP13DN4EXRDGTIN (EAN): 4058352418550
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 14170 |
Connected load | 84W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 168lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC
Order No.: 51TP13DN4F5SGTIN (EAN): 4058352930342
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 15550 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 178lm/W |
Control | DALI 2 |
ta | -25..+30°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected HO, with lever catch, symmetric extremely narrow distribution, IP64, AC
Order No.: 51TP13MN4GXSGTIN (EAN): 4058352930366
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 16110 |
Connected load | 87W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 184lm/W |
Control | ON/OFF Multilumen |
ta | -35..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP50, AC
Order No.: 51TS11VN465FGTIN (EAN): 4058352474884
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 6910 |
Connected load | |
Pnom (W) begin service life | 43 |
Pnom (W) end service life | 50 |
Luminous efficacy | 162lm/W |
Control | DALI 2, CLO |
ta | -25..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP50, AC/DC, operation on group/central battery
Order No.: 51TS11VN465FDGTIN (EAN): 4058352474907
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 6910 |
Connected load | |
Pnom (W) begin service life | 43 |
Pnom (W) end service life | 50 |
Luminous efficacy | 162lm/W |
Control | DALI 2, CLO |
ta | -25..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.8 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP50, AC
Order No.: 51TS11VN4DXRGTIN (EAN): 4058352534762
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13190 |
Connected load | |
Pnom (W) begin service life | 78 |
Pnom (W) end service life | 84 |
Luminous efficacy | 169lm/W |
Control | DALI 2, CLO |
ta | -25..+35°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.8 |
Licross® 11 Protected HO, with lever catch, symmetric narrow distribution, IP50, AC/DC, operation on group/central battery
Order No.: 51TS11VN4DXRDGTIN (EAN): 4058352534786
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13190 |
Connected load | |
Pnom (W) begin service life | 78 |
Pnom (W) end service life | 84 |
Luminous efficacy | 169lm/W |
Control | DALI 2, CLO |
ta | -25..+35°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS127N475FGTIN (EAN): 4058352265048
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 7690 |
Connected load | 48W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 162lm/W |
Control | ON/OFF |
ta | -35..+45°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12CN475FGTIN (EAN): 4058352265123
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 7680 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 54 |
Luminous efficacy | 157lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Order No.: 51TS12CN475FDGTIN (EAN): 4058352418581
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 7680 |
Connected load | |
Pnom (W) begin service life | 49 |
Pnom (W) end service life | 54 |
Luminous efficacy | 157lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.8 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12CN4C5LGTIN (EAN): 4058352298527
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 12600 |
Connected load | |
Pnom (W) begin service life | 79 |
Pnom (W) end service life | 88 |
Luminous efficacy | 160lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Order No.: 51TS12CN4C5LDGTIN (EAN): 4058352418598
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 12600 |
Connected load | |
Pnom (W) begin service life | 79 |
Pnom (W) end service life | 88 |
Luminous efficacy | 160lm/W |
Control | ON/OFF Multilumen, CLOi |
ta | -35..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12DN48XFGTIN (EAN): 4058352210031
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8470 |
Connected load | 56W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 151lm/W |
Control | DALI 2 |
ta | -25..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on R (wire number 6), with self-contained supply, 3h
Order No.: 51TS12DN48XF3SGTIN (EAN): 4058352506189
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8470 |
Connected load | 60W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 141lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 4.0 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC, with self-test function according to 60598-2-22, 2-rod battery, charging phase on L' (wire number 4), with self-contained supply, 3h
Order No.: 51TS12DN48XF3S4GTIN (EAN): 4058352676820
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8470 |
Connected load | 60W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 141lm/W |
Control | DALI 2 |
ta | +5..+35°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 4.0 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Order No.: 51TS12DN48XFDGTIN (EAN): 4058352418611
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8470 |
Connected load | 56W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 151lm/W |
Control | DALI 2 |
ta | -25..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected extreme MO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12DN48XFEGTIN (EAN): 4058352447376
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8470 |
Connected load | 56W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 151lm/W |
Control | DALI 2 |
ta | -25..+50°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.5 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12DN4DXLGTIN (EAN): 4058352265017
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13360 |
Connected load | 86W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 155lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Order No.: 51TS12DN4DXLDGTIN (EAN): 4058352418635
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13360 |
Connected load | 86W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 155lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected extreme HO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12DN4DXLEGTIN (EAN): 4058352447406
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13360 |
Connected load | 86W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 155lm/W |
Control | DALI 2 |
ta | -25..+45°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 3.0 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12DN58XFGTIN (EAN): 4058352375600
Colour temperature | 5000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8480 |
Connected load | 56W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 151lm/W |
Control | DALI 2 |
ta | -25..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12DN5DXLGTIN (EAN): 4058352391624
Colour temperature | 5000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 13380 |
Connected load | 86W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 155lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected TW, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12TNT75WGTIN (EAN): 4058352298558
Colour temperature | 2700..6500K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 7740 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 135lm/W |
Control | DALI DT8 |
ta | -25..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12VN455FGTIN (EAN): 4058352466520
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 5510 |
Connected load | |
Pnom (W) begin service life | 36 |
Pnom (W) end service life | 41 |
Luminous efficacy | 154lm/W |
Control | DALI 2, CLO |
ta | -25..+45°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12VN465FGTIN (EAN): 4058352466537
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 6530 |
Connected load | |
Pnom (W) begin service life | 43 |
Pnom (W) end service life | 50 |
Luminous efficacy | 153lm/W |
Control | DALI 2, CLO |
ta | -25..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Order No.: 51TS12VN465FDGTIN (EAN): 4058352474921
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 6530 |
Connected load | |
Pnom (W) begin service life | 43 |
Pnom (W) end service life | 50 |
Luminous efficacy | 153lm/W |
Control | DALI 2, CLO |
ta | -25..+40°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 2.8 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12VN475FGTIN (EAN): 4058352466551
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 7700 |
Connected load | |
Pnom (W) begin service life | 51 |
Pnom (W) end service life | 57 |
Luminous efficacy | 152lm/W |
Control | DALI 2, CLO |
ta | -25..+35°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC
Order No.: 51TS12VN4CXLGTIN (EAN): 4058352493557
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 12430 |
Connected load | |
Pnom (W) begin service life | 79 |
Pnom (W) end service life | 89 |
Luminous efficacy | 157lm/W |
Control | DALI 2, CLO |
ta | -25..+30°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 11 Protected HO, with lever catch, symmetric wide distribution, IP50, AC/DC, operation on group/central battery
Order No.: 51TS12VN4CXLDGTIN (EAN): 4058352493571
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 12430 |
Connected load | |
Pnom (W) begin service life | 79 |
Pnom (W) end service life | 89 |
Luminous efficacy | 157lm/W |
Control | DALI 2, CLO |
ta | -25..+30°C |
Protection rating | IP50 |
L (mm) | 1500 |
Wt. (kg) | 3.2 |
Licross® 21 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 52TD1BVN455GGTIN (EAN): 4058352979525
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 5500 |
Connected load | |
Pnom (W) begin service life | 32 |
Pnom (W) end service life | 38 |
Luminous efficacy | 170lm/W |
Control | DALI 2, CLO |
ta | -25..+45°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 21 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 52TD1BVN465GGTIN (EAN): 4058352979549
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 6500 |
Connected load | |
Pnom (W) begin service life | 39 |
Pnom (W) end service life | 46 |
Luminous efficacy | 167lm/W |
Control | DALI 2, CLO |
ta | -25..+45°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 21 Protected MO, with lever catch, symmetric wide distribution, IP54, AC
Order No.: 52TD1BVN48XGGTIN (EAN): 4058352979570
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 8000 |
Connected load | |
Pnom (W) begin service life | 48 |
Pnom (W) end service life | 58 |
Luminous efficacy | 166lm/W |
Control | DALI 2, CLO |
ta | -25..+40°C |
Protection rating | IP54 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric narrow distribution, IP64, AC
Order No.: 51TP11DN695GGTIN (EAN): 4058352070246
Colour temperature | 6500K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9680 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 170lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.4 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC
Order No.: 51TP12DN695GGTIN (EAN): 4058352022573
Colour temperature | 6500K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9730 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 170lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
Licross® 11 Protected MO, with lever catch, symmetric wide distribution, IP64, AC/DC, operation on group/central battery
Order No.: 51TP12DN495GDGTIN (EAN): 4069025002518
Colour temperature | 4000K |
---|---|
Colour rendering | CRI > 80 |
Net luminous flux (lm) | 9980 |
Connected load | 57W |
Pnom (W) begin service life | |
Pnom (W) end service life | |
Luminous efficacy | 175lm/W |
Control | DALI 2 |
ta | -25..+35°C |
Protection rating | IP64 |
L (mm) | 1500 |
Wt. (kg) | 2.9 |
