Licross® 21

ProducttypesConfiguration & Datasheets

45 years of experience – trunking Made in Germany perfected in our Licross® trunking system. The one-for-all concept offers a variety of luminaire inserts and functional expansion options for maximum flexibility and future compatibility. With a unique 14 cores, the rail system becomes the backbone of the building infrastructure and is ready for a wide range of applications – both today and tomorrow. The luminaire inserts feature outstanding lighting technology for low operating costs as well as SITECO-typical optic technology for top visual conditions. Various expansions from sensors to the UVC air disinfection unit open up a wide horizon of applications which exceed mere lighting and create even more added value.

14 cores and full flexibility are a must-have for tomorrow.

Protected luminaire insert IP50/IP54

Intro to Productfamily

Data

Article luminaire insert
Protection rating IP50; IP54
Net luminous flux 5000lm to 14710lm
Colour temperature 3500K; 4000K; 5000K
ta -25…+35°C; 0…+30°C; +5…+30°C; -35…+40°C; -35…+45°C; -25…+40°C; 0…+40°C; ??
Lighting effect direct symmetric narrow distribution, with ceiling illumination; direct symmetric wide distribution, with ceiling illumination

Specials

High robustness due to chemical resistance and suitability for ambient temperatures up to 40°C over complete service life
Very robust system with protection ratings up to IP50/IK06 whilst high service life of up to 50,000 hours
High luminous flux of up to 15,000lm for demand-oriented illumination of rough environments

Configuration & Datasheets

Lighting effect

Colour temperature

Colour rendering

Control

Rated luminous flux (lm)

UGR

Protection rating

Operating ambient temperature

Emergency light

  • Please order Licross® Trunking trunking rail and trunking rail accessories separately.
  • Versions with colour temperature 3000K, 5000K or 6500K on request.
  • with ceiling surface mounting: reducing of maximum allowable ambient temperature of 5°C

Results

Licross® 21 Protected MO, symmetric narrow distribution

Order No.: 52TD11DN49XFGTIN (EAN): 4058352454893
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80918059W157lm/WDALI 2 -25..+40°CIP5415002.8

Licross® 21 Protected HO, symmetric narrow distribution

Order No.: 52TD11DN4DXRGTIN (EAN): 4058352454923
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801301079W164lm/WDALI 2 -25..+35°CIP5415003.2

Licross® 21 Protected MO, symmetric narrow distribution

Order No.: 52TD11DN59XFGTIN (EAN): 4058352454930
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
5000KCRI > 80907059W155lm/WDALI 2 -25..+40°CIP5415003.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD127N475FGTIN (EAN): 4058352453643
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80769047W164lm/WON/OFF -35..+45°CIP5415002.5

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12CN48XFGTIN (EAN): 4058352453667
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80815049W168lm/WON/OFF Multilumen, CLOi -35..+45°CIP5415002.5

Licross® 21 Protected HO, symmetric wide distribution

Order No.: 52TD12CN4BXLGTIN (EAN): 4058352453681
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801126066W171lm/WON/OFF Multilumen, CLOi -35..+40°CIP5415002.5

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DN49XFGTIN (EAN): 4058352454954
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80922059W158lm/WDALI 2 -25..+40°CIP5415002.9

Licross® 21 Protected HO, symmetric wide distribution

Order No.: 52TD12DN4C5LGTIN (EAN): 4058352454978
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801281079W162lm/WDALI 2 -25..+35°CIP5415003.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DN59XFGTIN (EAN): 4058352454992
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
5000KCRI > 80911059W156lm/WDALI 2 -25..+40°CIP5415002.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DND75FGTIN (EAN): 4058352455012
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 90771061W126lm/WDALI 2 -25..+40°CIP5415002.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DNE75FGTIN (EAN): 4058352455036
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
5000KCRI > 90772061W127lm/WDALI 2 -25..+40°CIP5415003.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12CN475FGTIN (EAN): 4058352454473
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80765049W158lm/WON/OFF Multilumen, CLOi -35..+45°CIP5015003.2

Licross® 21 Protected HO, symmetric wide distribution

Order No.: 52TS12CN4A5LGTIN (EAN): 4058352454497
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801069066W162lm/WON/OFF Multilumen, CLOi -35..+40°CIP5015002.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DN485FGTIN (EAN): 4058352455050
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80867059W148lm/WDALI 2 -25..+40°CIP5015002.8

Licross® 21 Protected HO, symmetric wide distribution

Order No.: 52TS12DN4CXLGTIN (EAN): 4058352455081
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801216079W154lm/WDALI 2 -25..+35°CIP5015003.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DND7XFGTIN (EAN): 4058352455098
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 90724061W119lm/WDALI 2 -25..+40°CIP5015003.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DNE7XFGTIN (EAN): 4058352455111
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
5000KCRI > 90725061W119lm/WDALI 2 -25..+40°CIP5015003.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 51TS12DN495FGTIN (EAN): 4058352409435
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80950061W156lm/WDALI 2 0..+40°CIP5015003.2

Licross® 21 Protected HO, symmetric wide distribution

Order No.: 51TS12DN4E5LGTIN (EAN): 4058352409459
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801471092W161lm/WDALI 2 0..+30°CIP5015003.2

Licross® 21 Protected HO, symmetric narrow distribution, operation on group/central battery

Order No.: 52TD11DN4DXRDGTIN (EAN): 4058352504666
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801301079W164lm/WDALI 2 -25..+35°CIP5415003.2

Licross® 21 Protected MO, symmetric narrow distribution, operation on group/central battery

Order No.: 52TD11DN49XFDGTIN (EAN): 4058352504642
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80918059W157lm/WDALI 2 -25..+40°CIP5415003.2

Licross® 21 Protected HO, symmetric wide distribution, operation on group/central battery

Order No.: 52TD12DN4C5LDGTIN (EAN): 4058352504703
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801281079W162lm/WDALI 2 -25..+35°CIP5415003.2

Licross® 21 Protected MO, symmetric wide distribution, operation on group/central battery

Order No.: 52TD12DN49XFDGTIN (EAN): 4058352504680
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80922059W158lm/WDALI 2 -25..+40°CIP5415002.9

Licross® 21 Protected HO, symmetric wide distribution, operation on group/central battery

Order No.: 52TS12DN4CXLDGTIN (EAN): 4058352504901
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801216079W154lm/WDALI 2 -25..+35°CIP5015003.2

Licross® 21 Protected MO, symmetric wide distribution, operation on group/central battery

Order No.: 52TS12DN485FDGTIN (EAN): 4058352504888
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80867059W148lm/WDALI 2 -25..+40°CIP5015002.8

Licross® 21 Protected MO, symmetric narrow distribution, operation on group/central battery

Order No.: 52TD11VN475FDGTIN (EAN): 4058352522899
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80780049W161lm/WDALI 2, CLO -25..+40°CIP5415003.2

Licross® 21 Protected MO, symmetric narrow distribution

Order No.: 52TD11VN475FGTIN (EAN): 4058352522875
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80780049W161lm/WDALI 2, CLO -25..+40°CIP5415003.2

Licross® 21 Protected MO, symmetric wide distribution, operation on group/central battery

Order No.: 52TS12VN45XFDGTIN (EAN): 4058352522912
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80500032W158lm/WDALI 2, CLO -25..+40°CIP5015002.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12VN45XFGTIN (EAN): 4058352521489
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80500032W158lm/WDALI 2, CLO -25..+40°CIP5015003.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS127N165FGTIN (EAN): 4058352526835
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
3500KCRI > 80651044W148lm/WON/OFF -35..+45°CIP5015003.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD127N165FGTIN (EAN): 4058352525999
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
3500KCRI > 80657042W158lm/WON/OFF -35..+45°CIP5415002.5

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD127N17XFGTIN (EAN): 4058352526019
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
3500KCRI > 80729047W156lm/WON/OFF -35..+45°CIP5415002.5

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DN165FGTIN (EAN): 4058352534182
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
3500KCRI > 80661046W145lm/WDALI 2 -25..+40°CIP5015002.8

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DN18XFGTIN (EAN): 4058352534205
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
3500KCRI > 80821059W140lm/WDALI 2 -25..+40°CIP5015002.8

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DN165FGTIN (EAN): 4058352533260
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
3500KCRI > 80661043W156lm/WDALI 2 -25..+40°CIP5415002.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DN185FGTIN (EAN): 4058352533284
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
3500KCRI > 80874059W149lm/WDALI 2 -25..+40°CIP5415002.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS127N465FGTIN (EAN): 4058352526873
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80651042W157lm/WON/OFF -35..+45°CIP5015003.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD127N465FGTIN (EAN): 4058352526057
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80653039W168lm/WON/OFF -35..+45°CIP5415002.5

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DN46XFGTIN (EAN): 4058352534267
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80661043W154lm/WDALI 2 -25..+40°CIP5015002.8

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DN465FGTIN (EAN): 4058352533345
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80660040W165lm/WDALI 2 -25..+40°CIP5415002.9

Licross® 21 Protected MO, symmetric wide distribution, with self-contained supply

Order No.: 52TD12DN49XF3SGTIN (EAN): 4058352508206
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80922062W148lm/WDALI 23h IP5415004.0

Licross® 21 Protected HO, symmetric wide distribution, with self-contained supply

Order No.: 52TS12DN4CXL3SGTIN (EAN): 4058352505885
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801216083W147lm/WDALI 23h+5..+30°CIP5015004.0

Licross® 21 Protected MO, symmetric wide distribution, with self-contained supply

Order No.: 52TD12DN49XF3CGTIN (EAN): 4058352508183
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80922062W148lm/WDALI 23h IP5415004.0

Licross® 21 Protected HO, symmetric wide distribution, with self-contained supply

Order No.: 52TD12DN4C5L3SGTIN (EAN): 4058352508244
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801281083W154lm/WDALI 23h IP5415004.0

Licross® 21 Protected HO, symmetric wide distribution, with self-contained supply

Order No.: 52TD12DN4C5L3CGTIN (EAN): 4058352508220
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801281083W154lm/WDALI 23h IP5415004.0

Licross® 21 Protected MO, symmetric wide distribution, with self-contained supply

Order No.: 52TS12DN485F3SGTIN (EAN): 4058352508299
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80867062W139lm/WDALI 23h IP5015004.0

Licross® 21 Protected MO, symmetric wide distribution, with self-contained supply

Order No.: 52TS12DN485F3CGTIN (EAN): 4058352508268
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 80867062W139lm/WDALI 23h IP5015004.0

Licross® 21 Protected HO, symmetric wide distribution, with self-contained supply

Order No.: 52TS12DN4CXL3CGTIN (EAN): 4058352508305
Colour temperatureColour renderingNet luminous flux (lm)Connected loadLuminous efficacyControlBattery durationtaProtection ratingL (mm)Wt. (kg)
4000KCRI > 801216083W147lm/WDALI 23h IP5015004.0

Licross® 21 Protected MO, symmetric narrow distribution

Order No.: 52TD11DN49XFGTIN (EAN): 4058352454893

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)9180
Connected load59W
Luminous efficacy157lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.8

Licross® 21 Protected HO, symmetric narrow distribution

Order No.: 52TD11DN4DXRGTIN (EAN): 4058352454923

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)13010
Connected load79W
Luminous efficacy164lm/W
ControlDALI 2
Battery duration
ta-25..+35°C
Protection ratingIP54
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric narrow distribution

Order No.: 52TD11DN59XFGTIN (EAN): 4058352454930

Colour temperature5000K
Colour renderingCRI > 80
Net luminous flux (lm)9070
Connected load59W
Luminous efficacy155lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD127N475FGTIN (EAN): 4058352453643

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)7690
Connected load47W
Luminous efficacy164lm/W
ControlON/OFF
Battery duration
ta-35..+45°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.5

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12CN48XFGTIN (EAN): 4058352453667

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)8150
Connected load49W
Luminous efficacy168lm/W
ControlON/OFF Multilumen, CLOi
Battery duration
ta-35..+45°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.5

Licross® 21 Protected HO, symmetric wide distribution

Order No.: 52TD12CN4BXLGTIN (EAN): 4058352453681

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)11260
Connected load66W
Luminous efficacy171lm/W
ControlON/OFF Multilumen, CLOi
Battery duration
ta-35..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.5

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DN49XFGTIN (EAN): 4058352454954

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)9220
Connected load59W
Luminous efficacy158lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.9

Licross® 21 Protected HO, symmetric wide distribution

Order No.: 52TD12DN4C5LGTIN (EAN): 4058352454978

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)12810
Connected load79W
Luminous efficacy162lm/W
ControlDALI 2
Battery duration
ta-25..+35°C
Protection ratingIP54
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DN59XFGTIN (EAN): 4058352454992

Colour temperature5000K
Colour renderingCRI > 80
Net luminous flux (lm)9110
Connected load59W
Luminous efficacy156lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DND75FGTIN (EAN): 4058352455012

Colour temperature4000K
Colour renderingCRI > 90
Net luminous flux (lm)7710
Connected load61W
Luminous efficacy126lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DNE75FGTIN (EAN): 4058352455036

Colour temperature5000K
Colour renderingCRI > 90
Net luminous flux (lm)7720
Connected load61W
Luminous efficacy127lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12CN475FGTIN (EAN): 4058352454473

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)7650
Connected load49W
Luminous efficacy158lm/W
ControlON/OFF Multilumen, CLOi
Battery duration
ta-35..+45°C
Protection ratingIP50
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected HO, symmetric wide distribution

Order No.: 52TS12CN4A5LGTIN (EAN): 4058352454497

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)10690
Connected load66W
Luminous efficacy162lm/W
ControlON/OFF Multilumen, CLOi
Battery duration
ta-35..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)2.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DN485FGTIN (EAN): 4058352455050

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)8670
Connected load59W
Luminous efficacy148lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)2.8

Licross® 21 Protected HO, symmetric wide distribution

Order No.: 52TS12DN4CXLGTIN (EAN): 4058352455081

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)12160
Connected load79W
Luminous efficacy154lm/W
ControlDALI 2
Battery duration
ta-25..+35°C
Protection ratingIP50
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DND7XFGTIN (EAN): 4058352455098

Colour temperature4000K
Colour renderingCRI > 90
Net luminous flux (lm)7240
Connected load61W
Luminous efficacy119lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DNE7XFGTIN (EAN): 4058352455111

Colour temperature5000K
Colour renderingCRI > 90
Net luminous flux (lm)7250
Connected load61W
Luminous efficacy119lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 51TS12DN495FGTIN (EAN): 4058352409435

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)9500
Connected load61W
Luminous efficacy156lm/W
ControlDALI 2
Battery duration
ta0..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected HO, symmetric wide distribution

Order No.: 51TS12DN4E5LGTIN (EAN): 4058352409459

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)14710
Connected load92W
Luminous efficacy161lm/W
ControlDALI 2
Battery duration
ta0..+30°C
Protection ratingIP50
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected HO, symmetric narrow distribution, operation on group/central battery

Order No.: 52TD11DN4DXRDGTIN (EAN): 4058352504666

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)13010
Connected load79W
Luminous efficacy164lm/W
ControlDALI 2
Battery duration
ta-25..+35°C
Protection ratingIP54
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric narrow distribution, operation on group/central battery

Order No.: 52TD11DN49XFDGTIN (EAN): 4058352504642

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)9180
Connected load59W
Luminous efficacy157lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected HO, symmetric wide distribution, operation on group/central battery

Order No.: 52TD12DN4C5LDGTIN (EAN): 4058352504703

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)12810
Connected load79W
Luminous efficacy162lm/W
ControlDALI 2
Battery duration
ta-25..+35°C
Protection ratingIP54
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution, operation on group/central battery

Order No.: 52TD12DN49XFDGTIN (EAN): 4058352504680

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)9220
Connected load59W
Luminous efficacy158lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.9

Licross® 21 Protected HO, symmetric wide distribution, operation on group/central battery

Order No.: 52TS12DN4CXLDGTIN (EAN): 4058352504901

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)12160
Connected load79W
Luminous efficacy154lm/W
ControlDALI 2
Battery duration
ta-25..+35°C
Protection ratingIP50
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution, operation on group/central battery

Order No.: 52TS12DN485FDGTIN (EAN): 4058352504888

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)8670
Connected load59W
Luminous efficacy148lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)2.8

Licross® 21 Protected MO, symmetric narrow distribution, operation on group/central battery

Order No.: 52TD11VN475FDGTIN (EAN): 4058352522899

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)7800
Connected load49W
Luminous efficacy161lm/W
ControlDALI 2, CLO
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric narrow distribution

Order No.: 52TD11VN475FGTIN (EAN): 4058352522875

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)7800
Connected load49W
Luminous efficacy161lm/W
ControlDALI 2, CLO
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution, operation on group/central battery

Order No.: 52TS12VN45XFDGTIN (EAN): 4058352522912

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)5000
Connected load32W
Luminous efficacy158lm/W
ControlDALI 2, CLO
Battery duration
ta-25..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)2.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12VN45XFGTIN (EAN): 4058352521489

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)5000
Connected load32W
Luminous efficacy158lm/W
ControlDALI 2, CLO
Battery duration
ta-25..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS127N165FGTIN (EAN): 4058352526835

Colour temperature3500K
Colour renderingCRI > 80
Net luminous flux (lm)6510
Connected load44W
Luminous efficacy148lm/W
ControlON/OFF
Battery duration
ta-35..+45°C
Protection ratingIP50
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD127N165FGTIN (EAN): 4058352525999

Colour temperature3500K
Colour renderingCRI > 80
Net luminous flux (lm)6570
Connected load42W
Luminous efficacy158lm/W
ControlON/OFF
Battery duration
ta-35..+45°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.5

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD127N17XFGTIN (EAN): 4058352526019

Colour temperature3500K
Colour renderingCRI > 80
Net luminous flux (lm)7290
Connected load47W
Luminous efficacy156lm/W
ControlON/OFF
Battery duration
ta-35..+45°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.5

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DN165FGTIN (EAN): 4058352534182

Colour temperature3500K
Colour renderingCRI > 80
Net luminous flux (lm)6610
Connected load46W
Luminous efficacy145lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)2.8

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DN18XFGTIN (EAN): 4058352534205

Colour temperature3500K
Colour renderingCRI > 80
Net luminous flux (lm)8210
Connected load59W
Luminous efficacy140lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)2.8

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DN165FGTIN (EAN): 4058352533260

Colour temperature3500K
Colour renderingCRI > 80
Net luminous flux (lm)6610
Connected load43W
Luminous efficacy156lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DN185FGTIN (EAN): 4058352533284

Colour temperature3500K
Colour renderingCRI > 80
Net luminous flux (lm)8740
Connected load59W
Luminous efficacy149lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.9

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS127N465FGTIN (EAN): 4058352526873

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)6510
Connected load42W
Luminous efficacy157lm/W
ControlON/OFF
Battery duration
ta-35..+45°C
Protection ratingIP50
L (mm)1500
Wt. (kg)3.2

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD127N465FGTIN (EAN): 4058352526057

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)6530
Connected load39W
Luminous efficacy168lm/W
ControlON/OFF
Battery duration
ta-35..+45°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.5

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TS12DN46XFGTIN (EAN): 4058352534267

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)6610
Connected load43W
Luminous efficacy154lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP50
L (mm)1500
Wt. (kg)2.8

Licross® 21 Protected MO, symmetric wide distribution

Order No.: 52TD12DN465FGTIN (EAN): 4058352533345

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)6600
Connected load40W
Luminous efficacy165lm/W
ControlDALI 2
Battery duration
ta-25..+40°C
Protection ratingIP54
L (mm)1500
Wt. (kg)2.9

Licross® 21 Protected MO, symmetric wide distribution, with self-contained supply

Order No.: 52TD12DN49XF3SGTIN (EAN): 4058352508206

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)9220
Connected load62W
Luminous efficacy148lm/W
ControlDALI 2
Battery duration3h
ta
Protection ratingIP54
L (mm)1500
Wt. (kg)4.0

Licross® 21 Protected HO, symmetric wide distribution, with self-contained supply

Order No.: 52TS12DN4CXL3SGTIN (EAN): 4058352505885

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)12160
Connected load83W
Luminous efficacy147lm/W
ControlDALI 2
Battery duration3h
ta+5..+30°C
Protection ratingIP50
L (mm)1500
Wt. (kg)4.0

Licross® 21 Protected MO, symmetric wide distribution, with self-contained supply

Order No.: 52TD12DN49XF3CGTIN (EAN): 4058352508183

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)9220
Connected load62W
Luminous efficacy148lm/W
ControlDALI 2
Battery duration3h
ta
Protection ratingIP54
L (mm)1500
Wt. (kg)4.0

Licross® 21 Protected HO, symmetric wide distribution, with self-contained supply

Order No.: 52TD12DN4C5L3SGTIN (EAN): 4058352508244

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)12810
Connected load83W
Luminous efficacy154lm/W
ControlDALI 2
Battery duration3h
ta
Protection ratingIP54
L (mm)1500
Wt. (kg)4.0

Licross® 21 Protected HO, symmetric wide distribution, with self-contained supply

Order No.: 52TD12DN4C5L3CGTIN (EAN): 4058352508220

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)12810
Connected load83W
Luminous efficacy154lm/W
ControlDALI 2
Battery duration3h
ta
Protection ratingIP54
L (mm)1500
Wt. (kg)4.0

Licross® 21 Protected MO, symmetric wide distribution, with self-contained supply

Order No.: 52TS12DN485F3SGTIN (EAN): 4058352508299

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)8670
Connected load62W
Luminous efficacy139lm/W
ControlDALI 2
Battery duration3h
ta
Protection ratingIP50
L (mm)1500
Wt. (kg)4.0

Licross® 21 Protected MO, symmetric wide distribution, with self-contained supply

Order No.: 52TS12DN485F3CGTIN (EAN): 4058352508268

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)8670
Connected load62W
Luminous efficacy139lm/W
ControlDALI 2
Battery duration3h
ta
Protection ratingIP50
L (mm)1500
Wt. (kg)4.0

Licross® 21 Protected HO, symmetric wide distribution, with self-contained supply

Order No.: 52TS12DN4CXL3CGTIN (EAN): 4058352508305

Colour temperature4000K
Colour renderingCRI > 80
Net luminous flux (lm)12160
Connected load83W
Luminous efficacy147lm/W
ControlDALI 2
Battery duration3h
ta
Protection ratingIP50
L (mm)1500
Wt. (kg)4.0
