Streetlight SL 31
Nowadays public lighting costs are the biggest part of the energy costs of cities. For this reason the refurbishment of public lighting with efficient solutions is of fundamental significance. It is the cost-effective solution for a long-life street lighting that matches needs to reduce the energy costs and CO2 emissions. Optional Zhaga or NEMA interfaces build the base for intelligent control systems and Smart City applications.
Our basic solution: Streetlight SL 31 is our practical road luminaire as a perfect addition with high efficiency and quality
Streetlight SL 31 micro
Intro to Productfamily
Data
Article mast luminaire
Net luminous flux 4900lm to 5250lm
Colour temperature 3000K; 4000K
Lighting effect direct asymmetric wide distribution
Light distribution ST0.8a; ST1.0a
Protection rating IP66
Insulation class insulation class II (safety insulation)
Specials
Long service life of more than 100,000h, also thanks to future-proof product concept and long-life components
Standard light distributions via lens-based technology
Simple mounting thanks to a universal mast flange (included in delivery) for spigot size 60/76mm with inclination setting (0°/5°/10°/15° (post-top), 0°/-5°/-10°/-15° (side-entry)) and a separate accessory for 42mm brackets
Smart City ready: Future-proof thanks to two optional Zhaga or NEMA interfaces for state-of-the-art light control, wireless networking and diverse sensors
Configuration & Datasheets
- mast flange for mast spigot diameter 76mm and 60mm contained in product
- please order reducer for mast spigot diameter 42mm separately
- luminaire without pre-assembled connection cable
- if required, please order 'OSRAM DALI magic' or 'PRH 101 (NFC)' for transmitting the configuration separately
Results
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a
Order No.: 5XF1C42D08DAGTIN (EAN): 4058352465806
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 4000K | CRI > 70 | 5250lm | ST0.8a | Plus | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a
Order No.: 5XF1C32D08DAGTIN (EAN): 4058352465912
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4900lm | ST0.8a | Plus | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a
Order No.: 5XF1E42D08DAGTIN (EAN): 4058352465998
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 4000K | CRI > 70 | 5250lm | ST1.0a | Plus | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a
Order No.: 5XF1E32D08DAGTIN (EAN): 4058352465967
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4900lm | ST1.0a | Plus | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a
Order No.: 5XF1C42N08DAGTIN (EAN): 4058352467985
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 4000K | CRI > 70 | 5250lm | ST0.8a | Plus, Nema | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a
Order No.: 5XF1C32N08DAGTIN (EAN): 4058352467978
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4900lm | ST0.8a | Plus, Nema | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a
Order No.: 5XF1E42N08DAGTIN (EAN): 4058352467992
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 4000K | CRI > 70 | 5250lm | ST1.0a | Plus, Nema | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a
Order No.: 5XF1E32N08DAGTIN (EAN): 4058352468913
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4900lm | ST1.0a | Plus, Nema | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a, with Smart Interface below and above
Order No.: 5XF1C42T08DAGTIN (EAN): 4058352465936
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 4000K | CRI > 70 | 5250lm | ST0.8a | DALI 2 | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a, with Smart Interface below and above
Order No.: 5XF1C32T08DAGTIN (EAN): 4058352468906
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4900lm | ST0.8a | DALI 2 | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a, with Smart Interface below and above
Order No.: 5XF1E42T08DAGTIN (EAN): 4058352466018
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 4000K | CRI > 70 | 5250lm | ST1.0a | DALI 2 | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a, with Smart Interface below and above
Order No.: 5XF1E32T08DAGTIN (EAN): 4058352465974
| Colour temperature | Colour rendering | Luminous flux | Light distribution | Control | Wt. (kg) |
|---|---|---|---|---|---|
| 3000K | CRI > 70 | 4900lm | ST1.0a | DALI 2 | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a
Order No.: 5XF1C42D08DAGTIN (EAN): 4058352465806
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 5250lm |
| Light distribution | ST0.8a |
| Control | Plus |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a
Order No.: 5XF1C32D08DAGTIN (EAN): 4058352465912
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4900lm |
| Light distribution | ST0.8a |
| Control | Plus |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a
Order No.: 5XF1E42D08DAGTIN (EAN): 4058352465998
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 5250lm |
| Light distribution | ST1.0a |
| Control | Plus |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a
Order No.: 5XF1E32D08DAGTIN (EAN): 4058352465967
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4900lm |
| Light distribution | ST1.0a |
| Control | Plus |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a
Order No.: 5XF1C42N08DAGTIN (EAN): 4058352467985
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 5250lm |
| Light distribution | ST0.8a |
| Control | Plus, Nema |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a
Order No.: 5XF1C32N08DAGTIN (EAN): 4058352467978
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4900lm |
| Light distribution | ST0.8a |
| Control | Plus, Nema |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a
Order No.: 5XF1E42N08DAGTIN (EAN): 4058352467992
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 5250lm |
| Light distribution | ST1.0a |
| Control | Plus, Nema |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a
Order No.: 5XF1E32N08DAGTIN (EAN): 4058352468913
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4900lm |
| Light distribution | ST1.0a |
| Control | Plus, Nema |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a, with Smart Interface below and above
Order No.: 5XF1C42T08DAGTIN (EAN): 4058352465936
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 5250lm |
| Light distribution | ST0.8a |
| Control | DALI 2 |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST0.8a, with Smart Interface below and above
Order No.: 5XF1C32T08DAGTIN (EAN): 4058352468906
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4900lm |
| Light distribution | ST0.8a |
| Control | DALI 2 |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a, with Smart Interface below and above
Order No.: 5XF1E42T08DAGTIN (EAN): 4058352466018
| Colour temperature | 4000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 5250lm |
| Light distribution | ST1.0a |
| Control | DALI 2 |
| Wt. (kg) | 3.6 |
Streetlight SL 31 micro, direct asymmetric wide distribution, ST1.0a, with Smart Interface below and above
Order No.: 5XF1E32T08DAGTIN (EAN): 4058352465974
| Colour temperature | 3000K |
|---|---|
| Colour rendering | CRI > 70 |
| Luminous flux | 4900lm |
| Light distribution | ST1.0a |
| Control | DALI 2 |
| Wt. (kg) | 3.6 |
Mandatory accessory
| Order No.: 5XC10000W12GTIN (EAN): 4058352637265 | Show details |
| Order No.: 5XC10000WR6GTIN (EAN): 4058352641125 | Show details |
Optional accessory
| Order No.: 5XC1008XR12GTIN (EAN): 4058352462508 | Show details |
| Order No.: 5XC1008XR14GTIN (EAN): 4058352467794 | Show details |
