Nowadays public lighting costs are the biggest part of the energy costs of cities. For this reason the refurbishment of public lighting with efficient solutions is of fundamental significance. It is the cost-effective solution for a long-life street lighting that matches needs to reduce the energy costs and CO2 emissions. Optional Zhaga or NEMA interfaces build the base for intelligent control systems and Smart City applications.

Streetlight 31 A strong concept for top performance. Cost-efficient solution

Streetlight 31 maxi

Intro to Productfamily

Data

Article mast luminaire
Net luminous flux 28000lm to 30000lm
Colour temperature 3000K; 4000K
Lighting effect direct asymmetric wide distribution
Light distribution ST0.8a; ST1.0a
Protection rating IP66
Insulation class insulation class II (safety insulation)

Specials

Long service life of more than 100,000h, also thanks to future-proof product concept and long-life components
Standard light distributions via lens-based technology
Simple mounting thanks to a universal mast flange for spigot size 60/76mm with inclination setting (0°/5°/10°/15° (post-top), 0°/-5°/-10°/-15° (side-entry)) and a separate accessory for 42mm brackets
Smart City ready: Future-proof thanks to two optional Zhaga or NEMA interfaces for state-of-the-art light control, wireless networking and diverse sensors

Configuration & Datasheets

Light distribution

Colour temperature

Control

Smart City

  • mast flange for mast spigot diameter 76mm and 60mm contained in product
  • please order reducer for mast spigot diameter 42mm separately
  • luminaire without pre-assembled connection cable
  • if required, please order 'OSRAM DALI magic' or 'PRH 101 (NFC)' for transmitting the configuration separately

Results

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C42D08QAGTIN (EAN): 4058352468227
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
4000KCRI > 7030000lmST0.8aPlus8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C32D08QAGTIN (EAN): 4058352468203
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
3000KCRI > 7028000lmST0.8aPlus8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E42D08QAGTIN (EAN): 4058352466353
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
4000KCRI > 7030000lmST1.0aPlus8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E32D08QAGTIN (EAN): 4058352466339
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
3000KCRI > 7028000lmST1.0aPlus8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C42N08QAGTIN (EAN): 4058352468234
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
4000KCRI > 7030000lmST0.8aPlus, Nema8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C32N08QAGTIN (EAN): 4058352468210
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
3000KCRI > 7028000lmST0.8aPlus, Nema8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E42N08QAGTIN (EAN): 4058352468241
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
4000KCRI > 7030000lmST1.0aPlus, Nema8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E32N08QAGTIN (EAN): 4058352469194
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
3000KCRI > 7028000lmST1.0aPlus, Nema8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C42T08QAGTIN (EAN): 4058352469187
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
4000KCRI > 7030000lmST0.8aDALI 2.08.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C32T08QAGTIN (EAN): 4058352469170
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
3000KCRI > 7028000lmST0.8aDALI 2.08.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E42T08QAGTIN (EAN): 4058352469217
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
4000KCRI > 7030000lmST1.0aDALI 2.08.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E32T08QAGTIN (EAN): 4058352469200
Colour temperatureColour renderingLuminous fluxLight distributionControlWt. (kg)
3000KCRI > 7028000lmST1.0aDALI 2.08.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C42D08QAGTIN (EAN): 4058352468227

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux30000lm
Light distributionST0.8a
ControlPlus
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C32D08QAGTIN (EAN): 4058352468203

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux28000lm
Light distributionST0.8a
ControlPlus
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E42D08QAGTIN (EAN): 4058352466353

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux30000lm
Light distributionST1.0a
ControlPlus
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E32D08QAGTIN (EAN): 4058352466339

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux28000lm
Light distributionST1.0a
ControlPlus
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C42N08QAGTIN (EAN): 4058352468234

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux30000lm
Light distributionST0.8a
ControlPlus, Nema
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C32N08QAGTIN (EAN): 4058352468210

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux28000lm
Light distributionST0.8a
ControlPlus, Nema
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E42N08QAGTIN (EAN): 4058352468241

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux30000lm
Light distributionST1.0a
ControlPlus, Nema
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E32N08QAGTIN (EAN): 4058352469194

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux28000lm
Light distributionST1.0a
ControlPlus, Nema
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C42T08QAGTIN (EAN): 4058352469187

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux30000lm
Light distributionST0.8a
ControlDALI 2.0
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST0.8a

Order No.: 5XF4C32T08QAGTIN (EAN): 4058352469170

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux28000lm
Light distributionST0.8a
ControlDALI 2.0
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E42T08QAGTIN (EAN): 4058352469217

Colour temperature4000K
Colour renderingCRI > 70
Luminous flux30000lm
Light distributionST1.0a
ControlDALI 2.0
Wt. (kg)8.5

Streetlight 31 maxi, direct asymmetric wide distribution, ST1.0a

Order No.: 5XF4E32T08QAGTIN (EAN): 4058352469200

Colour temperature3000K
Colour renderingCRI > 70
Luminous flux28000lm
Light distributionST1.0a
ControlDALI 2.0
Wt. (kg)8.5

Optional accessory

Articlereducer, spigot size: 76/42mmPU1 pc.Wt. (kg)0.1Order No.: 5XC1008XR14GTIN (EAN): 4058352467794Show details
